2. Cover Section
2-2. Door
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE1-M1351-02 COVER(1) 1
2 LE1-M1352-04 COVER(2) 1
3 LE1-M1357-05 COVER(7) 1
4 LE1-M135B-03 STAY 3
5 LE1-M135F-02 STAY(C1) 1
6 LE1-M135H-01 BRKT,PULL 1
7 LE1-M1367-04 BRKT,MAGNET 2
8 90990-47J011 PULL 1
9 LE1-M135N-03 PIVOT HINGE(1) 1
10 LE1-M135P-03 PIVOT HINGE(2) 1
11 LE1-M135R-04 PIVOT HINGE(3) 1
12 LE1-M135S-03 PIVOT HINGE(4) 1
13 LE1-M135V-02 BRACKET 3
14 LE1-M1361-02 LEVER(1) 3
15 LE1-M1362-02 LEVER(2) 3
16 LE1-M1363-01 BUSH 6
17 LE1-M1364-01 LEVER(3) 3
18 LE1-M1365-10 SHAFT 2
19 LE1-M136G-00 STAY 1
20 LE1-M136H-00 SPACER 3
21 LE1-M136J-00 SPACER 3
22 LE1-M136K-00 SHAFT 3
23 LE1-M136L-00 KEEPER 6
24 90990-51J003 HINGE 3
25 LE1-M13A7-01 SPRING 6
26 90990-28J117 WASHER,PLAIN 6
27 90990-31J026 BOLT SHOULDER 8
28 LE1-M13AB-10 HINGE PIN 3
29 LE1-M13AC-10 SPRING 1
30 LE1-M13AD-10 SPRING 1
31 90990-28J118 WASHER,PLAIN 3
32 90990-53J003 BEARING(OILLESS) 6
33 90990-53J002 BEARING(OILLESS) 8
34 90990-53J008 BEARING(OILLESS) 6
35 90990-28J119 WASHER,PLAIN 2
36 90990-28J129 WASHER,PLAIN 6
37 90990-28J134 WASHER,PLAIN 2
38 90990-52J002 MAGNET CATCH 2
39 LE1-M13AN-00 SPRING 6
40 90990-28J133 WASHER,PLAIN 23
41 90990-01J039 BOLT,HEX.SOCKET HEAD 23
42 91317-03006 BOLT HEX.SOCKET HEAD 42 M3X6
43 91314-04008 BOLT HEX.SOCKET HEAD 13 M4X8
44 91317-04006 BOLT HEX.SOCKET HEAD 6 M4X6
45 91317-04008 BOLT HEX.SOCKET HEAD 14 M4X8
46 91314-06010 BOLT HEX.SOCKET HEAD 3 M6X10
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
47 98907-04006 SCREW BINDING HEAD 18
48 98704-04008 SCREW FLAT HEAD 6
49 98707-08014 SCREW FLAT HEAD 2
50 92907-03200 WASHER PLAIN 4
51 92990-04400 WASHER EXTL. TOOTHED 9
6
3. Moving-axis Section
3-1. X-axis (A,D TABLE)
5
24
29
35
22
15
3
12
9
10
6
26
25
2
11
11
13
30
21
33
14
32
16
31
7
23
8
1
21
27
26
26
28
17
34
18
22
20
19
34
15
4
27
5
24
29
35
22
15
3
12
9
10
6
26
25
2
11
11
13
30
21
33
14
32
16
31
7
23
8
1
21
27
26
26
26
28
17
34
18
22
20
19
34
15
4
27
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE1-M220A-01 BRACKET,LINEAR(A) 1
2 LE1-M220B-01 BRACKET,LINEAR(B) 1
3 LE1-M2211-02 SLIDE PLATE(1) 1
4 LE1-M2212-02 SLIDE PLATE(2) 1
5 LE1-M2213-01 STAY(1) 1
6 LE1-M2214-00 STAY(2) 2
7 LE1-M2215-01 BRACKET 1
8 LE1-M2216-01 BRACKET,HN 1
9 90990-43J016 PIN 1
10 90990-43J017 PIN 1
11 90990-43J018 PIN 2
12 99480-04012 PIN,PARALLEL 8
13 LE1-M22H2-01 ROBOT AXIS1L 1
14 LE1-M2203-00 NUT 2
15 LE1-M2217-00 PLATE,SENSOR 2
16 LE1-M2218-00 PLATE 2
17 LE1-M2219-00 PANEL 1
18 LE1-M221A-00 PLATE 1
19 LE1-M66MV-01 HNS XOR+ASSY 1
20 LE1-M66MU-01 HNS XOR-ASSY 1
21 90990-01J037 BOLT,HEX.SOCKET HEAD 6
22 91317-03006 BOLT HEX.SOCKET HEAD 16 M3X6
23 91317-04006 BOLT HEX.SOCKET HEAD 2 M4X6
24 91317-04014 BOLT HEX.SOCKET HEAD 2 M4X14
25 91317-04020 BOLT HEX.SOCKET HEAD 4 M4X20
26 91317-05014 BOLT HEX.SOCKET HEAD 8 M5X14
27 91317-05016 BOLT HEX.SOCKET HEAD 6 M5X16
28 91317-05018 BOLT HEX.SOCKET HEAD 3 M5X18
29 91317-05020 BOLT HEX.SOCKET HEAD 4 M5X20
30 91317-06016 BOLT HEX.SOCKET HEAD 4 M6X16
31 98704-03006 SCREW FLAT HEAD 2
32 98707-03007 SCREW FLAT HEAD 4
33 91304-03600 NUT, HEXAGON 2
34 91314-03006 BOLT HEX.SOCKET HEAD 6 M3X6
35 91314-04008 BOLT HEX.SOCKET HEAD 2 M4X8
7
3. Moving-axis Section
3-2.
Y-axis (C,B TABLE)
7
10
11
5
8
2
1
6
10
12
4
13
9
3
2
15
14
7
10
11
5
8
2
1
6
10
12
4
13
9
3
2
15
14
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE1-M22AB-00 LINEAR GUIDE 1
2 99480-06020 PIN PARALLEL 2
3 LE1-M26H2-01 ROBOT AXIS2L 1
4 LE1-M2611-00 BRKT,SENSOR(F) 1
5 LE1-M2612-00 BRKT,SENSOR(R) 1
6 LE1-M2613-00 PLATE,SENSOR(F) 1
7 LE1-M2614-00 PLATE,SENSOR(R) 1
8 LE1-M2615-00 PLATE,NUT 1
9 LE1-M2616-01 PLATE 1
10 91317-03006 BOLT HEX.SOCKET HEAD 2 M3X6
11 91317-04008 BOLT HEX.SOCKET HEAD 2 M4X8
12 91317-04018 BOLT HEX.SOCKET HEAD 12 M6X25
13 91317-06025 BOLT HEX.SOCKET HEAD 8 M4X19
14 LE1-M66MT-00 HNS. YOR+.ASSY 1
15 LE1-M66MS-00 HNS. YOR-.ASSY 1
