PREVENTIVE MAINTENANCE
MONTHLY MAINTENANCE
33.46 Technical Reference Manual Chapter Issue 6 Oct 06
Summary/Remarks
Signed: Date:
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 6 Oct 06 Technical Reference Manual 33.47
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Figure 33-1 Rising Table
A
Tooling (clean)
Manual Tooling Plate (clean)
View on Rear of Rising Table
Transport Rail Drive Belt
Rising Table Drive Belt
Rising Table Ballscrew
Transport Rail Ballscrew
(in 2 positions)
Rising Table Motor
Linear Bearing Block
(in 4 positions)
View on Arrow A
Sensor Vane
Vertical Linear Bearing Guide Rails
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
33.48 Technical Reference Manual Chapter Issue 6 Oct 06
Figure 33-2 Paste Dispenser
View on Rear of Print Carriage
Linear Bearing Guides
Paste Drip Tray
Home Sensor
Home Vane
Paste Dispenser Drive Belt
