LED Pairing / Sof tware Version Descript ion Ausgabe 05/2015 Edition 11 6 New Features in SIPLACE LED Pairing 6.1 Wildcard Character ' *' as Reference Designator The '*' wildcard ch aracter can be use…

LED Pairing / Software Version Description Ausgabe 05/2015 Edition

NOTICE

Further Information

Detailed information about the user interface and work flows can be found in the User

Guide and Online Help for SIPLACE LED Pairing.

The brightness class is displayed in the Setup-Editor in SIPLACE Pro Desk.

In SIPLACE Setup Center, the barcode labels for LEDs have to be extended by the barcode

fragment Brightness Class. Additionally to the component name, SIPLACE Setup Center also

checks the brightness class for LEDs during the setup verification.

Detailed information can be found in the User Guides or Online Helps for SIPLACE Pro and

SIPLACE Setup Center.

LED Pairing / Software Version Description Ausgabe 05/2015 Edition

6 New Features in SIPLACE LED Pairing

6.1 Wildcard Character '*' as Reference Designator

The '*' wildcard character can be used as reference designator in the LED matrix file.

6.2 Creating a Partial Setup

Multiple recipes can be selected in the Production view, whereupon SIPLACE LED Pairing

generates one download recipe for each selected recipe. If the selected recipes have the same

recipe template, SIPLACE LED Pairing will create one common setup for the download recipes.

Optionally, a partial setup may be created out of it via a new button. All components that are not

required in the download recipes will then be removed from the setup together with their feeders.

6.3 Transferring Changes to Original Placement Lists

SIPLACE LED Pairing creates copies of the placement lists. If errors are detected in the data

during placement, the user usually corrects them only in the copy.

In order to transfer such changes controlled to the original placement lists, it is now possible to start

the Difference Editor in SIPLACE LED Pairing via a new button in the Production view.

The relevant placement lists are displayed for comparison and the correction can be performed in

the Difference Editor.

LED Pairing / Software Version Description Ausgabe 05/2015 Edition

7 Restrictions

– Due to the optimization strategy, additional placement positions are generated in the template

job. Hence, the simulated optimization results are not as good as the real ones. Solely the

optimization results of the download recipes comply with the usual prediction accuracy, as they

do not contain any additional placement positions anymore.

– Only the component shape is evaluated to unite the series resistors in placeholder groups. This

means, that the series resistors of a placeholder group refer to the same component shape. It

is assumed that all components which have to be exchanged against each other have the

same component shape.

– It is not possible to exchange components in waffle-pack tray carrier.

– Series resistors and LEDs must be located in the same SIPLACE Pro folder.
