17 Clear product management with ofine progr amming Intuitive software operation with t ouch-screen surface Clear product management with ofine pr ogramming Parameter tr ansparency through module groupings Easy adaptio…
1.
2.
3.
4.
5.
6.
ViCON
Vision
1. Alarms
The top area of the screen gives you a clear
overview where you can view, interpret and
edit alarm messages.
4. Machine view
The machine view offers an overview of the
modular construction of your system, the
current loading situation and the status of the
process zones.
2. Favourites bar
In the favourites bar you can view selected
values. This then appears on the main screen
and on every page in the dened position.
5. Options
Machine options can be set depending on the
system equipment. For this there are up to ten
different options available for your manufac-
turing process.
3. Status bar
Colour-contrasting markings in the status
bar provide you with information on the
operating mode of the system.
6. Display area
The display area shows you all prole
parameter actual values, e.g. temperature
and lters.
16
17
Clear product management with ofine programming
Intuitive software operation with touch-screen surface
Clear product management with ofine programming
Parameter transparency through module groupings
Easy adaption due to favourites bar
Multilingual software
Innovative software
User-friendly and easy operation
With the ViCON Rehm offers straightforward software for
the Vision-Series, boasting intuitive operation with its touch-
screen surface.
All messages, commands and parameters can be viewed
at one glance on the main screen using machine view. With
a number of features including a freely congurable favour-
ites bar, the structured grouping of parameters or individual
process tracking and documentation ViCON provides you with
optimum assistance in your production processes.
While developing the software Rehm experts have rened
many aspects including product management. The creation
of new products or the copying of certain properties in parallel
with production on the machine is enabled. The parameters
for new creations are directly selectable, meaning that the
production sequence can progress faster and without any
disruption.
As well as that, you can immediately recognise which action
mode the system is in from the operating status. The operat-
ing status and alarm messages can be evaluated quickly and
reliably.
Another plus of the ViCON is dening user administration.
Through the assignment of specic user roles each user has
exactly those rights activated that he or she needs for opera-
tion and work on the system – without any rigid hierarchy.
Vision-Series | Software
18
Industry 4.0
Intelligent Software Solutions
Software solutions from Rehm allow the reliable control and monitoring of systems from
the VisionX-Series.
The software components are consisting of monitoring tools and various modules, each of
which completes its own individual task. Master software compiles the data and evaluates it,
for instance in order to keep the specied parameters constant for the respective manufactur-
ing prole. The modular system can be assembled into individualized packages and matched
to the customer’s respective requirements. Custom tailored master software is available for
each system type.
4.0
Industry
