This section shows the different versions/configuration codes and the ordering numbers. • Section OMV technical data on page 40, specify the technical data for OMV for each shaft type. • In section OMV function diagrams …
This section shows the different versions/configuration codes and the ordering numbers.
•
Section OMT technical data, specify the technical data for OMT for each shaft type.
•
In section OMT function diagrams, the diagram for each motor size is shown.
•
See OMT dimensions for outer main dimensions for the different OMT motor types.
Technical Information
OMT and OMV Orbital Motors
OMT versions and code numbers
©
Danfoss | September 2021 BC152886483862en-000801 | 37
This section shows the different versions/configuration codes and the ordering numbers.
•
Section OMV technical data on page 40, specify the technical data for OMV for each shaft type.
•
In section OMV function diagrams on page 45, the diagram for each motor size is shown.
•
See OMV dimensions on page 53 for outer main dimensions for the different OMV motor types.
OMV versions and code numbers
OMV standard motors
Mounting flange: Standard 4 hole flange
Spigot diameter Ø160 mm [6.30 in]
Bolt circle
diameter
Ø200 mm [7.89 in]
Shaft Main Port size Drain Port size Check valve European
version
US version Main type
designation
Conf. code
Cyl. Ø50 mm G 1 G 1/4 Yes Yes - OMV A1
Splined 2.125 in G 1 G 1/4 Yes Yes - OMV A2
Tapered 60 mm G 1 G 1/4 Yes Yes - OMV A3
Cyl. 2.25 in 1 5/16-12 UN 9/16-18 UNF Yes - Yes OMV A4
Splined 2.125 in 1 5/16-12 UN 9/16-18 UNF Yes - Yes OMV A5
Tapered 2.25 in 1 5/16-12 UN 9/16-18 UNF Yes - Yes OMV A6
Code numbers OMV Standard 4 hole flange
Conf. code Displacement
315 400 500 630 800
A1 151B3100 151B3101 151B3102 151B3103 151B3104
A2 151B3105 151B3106 151B3107 151B3108 151B3109
A3 151B3110 151B3111 151B3112 151B3113 151B3114
A4 151B2150 151B2151 151B2152 151B2153 151B2154
A5 151B2155 151B2156 151B2157 151B2158 151B2159
A6 151B2160 151B2161 151B2162 151B2163 151B2164
Mounting flange: OMV SAE-C flange
Spigot diameter Ø127 mm [5.00 in]
Bolt circle diameter Ø161.9 mm [6.37 in]
Shaft Main Port size Drain Port size European version US version Check valve Main type designation Conf. code
Cyl. 2.25 in 1 5/16-12 UN 9/16-18 UNF - Yes Yes OMV B1
Splined 2.125 in 1 5/16-12 UN 9/16-18 UNF - Yes Yes OMV B2
Code numbers OMV - SAE-C flange
Conf. code Displacement
315 400 500 630 800
B1 151B2183 151B2184 151B2185 151B2186 151B2187
B2 151B2188 151B2189 151B2190 151B2191 151B2192
Technical Information
OMT and OMV Orbital Motors
OMV versions and code numbers
38 |
©
Danfoss | September 2021 BC152886483862en-000801
Mounting flange: OMV Wheel
Spigot diameter Ø180 mm [7.09 in]
Bolt circle
diameter
Ø224 mm [8.82 in]
Shaft Main Port size Drain Port size Check valve European
version
US version Main type
designation
Conf. code
Cyl. Ø50 mm G 1 G 1/4 Yes Yes - OMVW C1
Splined 2.125 in G 1 G 1/4 Yes Yes - OMVW C2
Tapered 2.25 in 1 5/16-12 UN 9/16-18 UNF Yes - Yes OMVW C3
Code numbers OMVW
Conf. code Displacement
315 400 500 630 800
C1 151B3115 151B3116 151B3117 151B3118 151B3119
C2 151B3120 151B3121 151B3122 151B3123 151B3124
C3 151B2170 151B2171 151B2172 151B2173 151B2174
Mounting flange: OMV Short
Spigot diameter Ø140 mm [5.51 in]
Bolt circle
diameter
Ø180 mm [7.09 in]
Shaft Main Port size Drain Port size Check valve European
version
US version Main type
designation
Conf. code
No output shaft G 1 G 1/4 Yes Yes - OMVS D1
Code numbers OMVS
Conf. code Displacement
315 400 500 630 800
D1 151B3125 151B3126 151B3127 151B3128 151B3129
OMV features
Features available (options):
•
Speed sensor
•
Motor with tacho connection
•
Viton shaft seal
•
Painted
•
Ultra short
Technical Information
OMT and OMV Orbital Motors
OMV versions and code numbers
©
Danfoss | September 2021 BC152886483862en-000801 | 39
