Type OMV 315 OMV 400 OMV 500 OMV 630 OMV 800 L Max. mm [in] 216 [8.50] 223 [8.78] 231 [9.09] 242 [9.53] 256 [10.08] L 1 * mm [in] 22.0 [0.866] 29.0 [1.142] 37.0 [1.457] 47.5 [1.870] 61.5 [2.421] L 2 mm [in] 160 [6.30] 16…

100%1 / 67
OMV standard flange - US version
Ø160.000 [6.2992]
Ø159.937 [6.2967]
Ø146.3 [5.760]
Ø145.7 [5.736]
Ø90 [3.54]
Ø88 [3.46]
39.4 [1.551]
38.6 [1.520]
2 [0.08]x45˚
24.6 [0.969]
23.4 [0.921]
33˚
R1.6 [0.063]
max. 76 [2.99]
Ø200.4 [7.890]
Ø199.6 [7.858]
40 [1.57]
60 [2.36]
11 [0.43]20 [0.79]
max. 77 [3.03] max. 83 [3.27]
69 [2.72]
77 [3.03]
R16 [0.63]
Ø18 [0.71]
max. 181.3 [7.14]
max. 181.3 [7.14]
151-890.12.22
25.3 [0.996]
24.7 [0.972]
25.3 [0.996]
24.7 [0.972]
120 [4.72]
max. 149 [5.87]
L
L
1
L
2
L
3
C
D
C: Drain connection 9⁄16 - 18 UNF; 13 mm [0.51 in] deep O-ring boss port
D: 1 5⁄16 - 12 UN; 19 mm [0.75 in] deep O-ring boss port
Technical Information
OMT and OMV Orbital Motors
OMV dimensions
58 |
©
Danfoss | September 2021 BC152886483862en-000801
Type OMV 315 OMV 400 OMV 500 OMV 630 OMV 800
L
Max.
mm [in] 216 [8.50] 223 [8.78] 231 [9.09] 242 [9.53] 256 [10.08]
L
1
*
mm [in] 22.0 [0.866] 29.0 [1.142] 37.0 [1.457] 47.5 [1.870] 61.5 [2.421]
L
2
mm [in] 160 [6.30] 167 [6.57] 175 [6.89] 186 [7.32] 200 [7.87]
Weight kg [lb] 31.8 [70.1] 32.6 [71.9] 33.5 [73.9] 34.9 [76.9] 36.5 [80.5]
*
The gearwheel set is 3.5 mm [0.138 in] wider across the rollers than the L1 dimensions
Output shaft Cyl. 2.25 in Splined 2.125 in Tapered 2.25 in
L
3
mm [in] 82 [3.23] 100 [3.94]
Technical Information
OMT and OMV Orbital Motors
OMV dimensions
©
Danfoss | September 2021 BC152886483862en-000801 | 59
OMV SAE-C flange - US version
Ø127.00 [5.000]
Ø126.95 [4.998]
71.0 [2.795]
81.5 [3.209]
Ø162.3 [6.390]
Ø161.5 [6.358]
max. 147 [5.79]
151-1485.11
Ø17.7 [0.697]
Ø17.3 [0.681]
max. 77 [3.03]
max. 83 [3.27]
16.1 [0.634]
13.7 [0.539]
13.8 [0.543]
13.2 [0.520]
21.0 [0.827]
19.6 [0.772]
max. 76 [2.99]
max. 147 [5.79]
85.5 [3.366]24.0 [0.945]
max. 121 [4.76]
max. 149 [5.87]
25 [0.98]25 [0.98]
R16 [0.63]
L
L
1
L
2
L
3
D
C
C: Drain connection 9⁄16 - 18 UNF; 13 mm [0.51 in] deep O-ring boss port
D: 1 5⁄16 - 12 UN; 19 mm [0.75 in] deep O-ring boss port
Technical Information
OMT and OMV Orbital Motors
OMV dimensions
60 |
©
Danfoss | September 2021 BC152886483862en-000801
