SMT Software Engineering Group
IM Operations
YAMAHA MOTOR CO., LTD.
MDOC-SOFT50111 The Procedure of System Software Install YAMAHA ENGLISH. 11/16
YG Series
Depend on the disk size different language set will be installed.
The latest YG machine has 1024[MB] FLASH DISK and Multi Language.
List 3.7 YG Series - Multi Language
Default Language Language set
English English / Japanese / Chinese / Korean
Japanese English / Japanese / Chinese / Korean
List 3.8 YG Series - Limited Language
Default Language Language set
English English / Chinese
Japanese English / Japanese
YS Series
List 3.9 YS Series
Default Language Language set
English English / Japanese / Chinese / Korean
Japanese English / Japanese / Chinese / Korean
SMT Software Engineering Group
IM Operations
YAMAHA MOTOR CO., LTD.
MDOC-SOFT50111 The Procedure of System Software Install YAMAHA ENGLISH. 12/16
YSM Series
List 3.10 YSM Series
Default Language Language set
English English / Japanese / Chinese / Korean
* If you need YSM Series System in languages other than English, set a language through the following
procedure.
1. Create a system in English.
2. Install a machine application.
3. Start the machine application, and select a language from [Machine] – [Setting] – [Machine
Information] – [Option Setting] – [Message]
4. Click the [Setup] – [System backup] – [Restore] button to restore the System Backup.
SMT Software Engineering Group
IM Operations
YAMAHA MOTOR CO., LTD.
MDOC-SOFT50111 The Procedure of System Software Install YAMAHA ENGLISH. 13/16
7) Check and Execute Installation
Confirm the drive of the FLASH DISK and the default language, if OK, check the [Determine] box.
(When “Determine” is marked, the [Execute] button will appear.)
Click the [Execute] button, and Installation will start.
At first “Write”, then “Compare” will be executed.
It will take about 20 minutes.
Figure 3.9 Check [Determine] box
Figure 3.10 Click the [Execute] button to start.
The drive of FLASH DISK
Default Language
