TABLE OF CONTENTS
Scienscope is an industrial (NDT) solution provider committed to the best price to performance ratio we can offer.
In business since 1994, Scienscope has served all manufacturing areas in North America through a network of techni-
cal sales representatives and distributors. Our mission is to provide the most innovative and cost-effective solutions
for our customers’ inspection problems. We are continuously developing new products and software to meet your
needs.
INTRODUCTION
The Scienscope inspection division is the core of our business. Our product line extends from benchtop magnifi-
ers, stereo zoom microscopes, video inspection systems, video recognition systems to video measurement systems
and measurement software. As well, Scienscope manufactures industrial cabinet-style micro focus X-Ray machines.
We can give you a demo on-site or online, don’t hesitate to contact your local representatives or Scienscope directly for details.
Please visit our website www.scienscope.com for more product information and contacts. We appreciate the opportunity to do
business with your company. Let us know how we can help.
2 ELZ Series
4 ELZ Binocular Systems
6 SSZ-II Series
8 SSZ-II Binocular Systems
10 NZ Series
12 NZ Series Binocular Systems
14 E-Series(CMO)
16 E-SeriesMicroscopeConguration
17 E-SeriesCongurationChart
18 E-Series 20° Systems
19 E-Series 0° - 45° Systems
20 VersaCam (CC-HDMI-CD2)
21 SmartCam-Ultra AF (CC-SMART-4K-AF)
22 SSZ-II Trinocular Systems
23 NZ Trinocular Systems
24 E-Series 20° Trinocular Systems
25 E-Series 0°- 45° Trinocular Systems
Our microscopes are perfect for a wide range of applications:
Electronics
Medical Devices
Automotive
semiconductors
Plastics
Aerospace
Micro-Stamping
Precision Machining
Perfect for doing:
Macro Documentation
Measuring
Inspection and Documentation
Sharing your work remotely
2 3
ELZ SERIES
COMPACT & COST EFFECTIVE
The ELZ microscope series is designed for entry-level users or companies that require good
quality on a budget. High-performance optics and small package deliver a great scope at a
very affordable price.
The quality of Scienscope’s stereo zoom microscope series and optical design provides
high-quality images with more outstanding flatness. The coatings on lens surfaces provide
clear, bright, and high-contrast views of your most challenging applications.
• Quality construction and optics
• Variety of accessories
• Cost-effective
• Great started microscope
Data Sheet / ELZ Body Specs
FEATURES
Upgrades available on eyepieces,
objectives, lenses, light sources
,and many other microscope parts
allow flexible adaptation to your
changing workflow.
Microscope Body Zoom Range 0.7X - 3X
Magnication 7X-30X (w/10X eyepiece
Zoom Ratio 1:4.3
Field of View 31.4mm - 7.3mm (w/ 10X eyepieces
Work Distance 100MM
Dioptric Adjustment ±5
Interpupillary Adjustment 46 - 76mm
Eyepieces Inclination 60°
Microscope Ring Mount Diameter 76mm
Based on NZ series microscope
construction, the ELZ surpasses
many competitors in the compact
category.
Anti-mold and air-tight sealed
body design eliminates the need
for regular maintenance and
adds additional reliability in most
working environments.
UPGRADABLE SYSTEMMAINTENANCE - FREE HIGH QUALITY OPTICS
ELZ Binocular Optical Specs
Objective
Lens
EyepiecesEyepieces
Working
Distance
10x10x 15x15x 20x20x
MAGMAG
FOVFOV ( (mm)mm)
MAGMAG
FOVFOV ( (mm)mm)
MAGMAG
FOVFOV ( (mm)mm)
0.5X 3.5x- 15x 66.9- 15 5.3x- 22.5x 4.6-11 7x-30x 36-8.3 177mm
Default 7x-30x 31.4-7.3 10.5x-45x 22.9-5.3 14x-60x 17.9x4.1 100mm
2x 14x-60x 16-3.7 21x-90x 11.4 - 8 28z - 120x 9-6 26mm
COMPACT PERFORMANCE
Optical Magnication Formula
* Included in standard package
Total Magnication = (Mag. of Eyepieces) X (Mag. of the objective zoom range on body) X ( Mag/ of objective lens)
