ELZ-PK1 Systems on post stands with choice of lighting
Package Contents
Packages with Lighting Options
ELZ-PK2 Systems on track stands with choice of lighting
ELZ-PK3 Systems onarticulating arms with choice of lighting
Package Contents
Packages with Lighting Options
ELZ-PK5D Systems on dual arm boom stands with choice of lighting
• ELZ Stereo Zoom Binocular, 10x eyepieces
• Eye guards
• Single arm boom stand with 76mm e-arm
• 0.5x auxiliary lens
•
Choice of lighting
ELZ-PK5S-AN (Fiber optic annular ring light guide)
ELZ-PK5S-R3E (New super-bright low-profile LED ring light)
ELZ-PK5S-R3 (New high intensity LED ring light with polarizer)
ELZ-PK5S-E1 (Quadrant compact LED ring light)
Package Contents
Packages with Lighting Options
• ELZ Stereo Zoom Binocular
• 10x eyepieces
• Dual arm boom stand with 76mm e-arm
• 0.5x auxiliary lens
•
Choice of lighting
ELZ-PK2-AN (Fiber optic annular ring light guide)
ELZ-PK2-R3E (New super-bright low-profile LED ring light)
ELZ-PK2-R3 (New high intensity LED ring light with polarizer)
ELZ-PK2-E1 (Quadrant compact LED ring light)
4 5
• ELZ Stereo Zoom Binocular
• 10x eyepieces
• ErgoPost Stand with 76mm focus rack
•
Choice of lighting
ELZ BINOCULAR SYSTEMS
ELZ-PK1-AN (Fiber optic annular ring light guide)
ELZ-PK1-R3E (New super-bright low-profile LED ring light)
ELZ-PK1-R3 (New high intensity LED ring light with polarizer)
ELZ-PK1-E1 (Quadrant compact LED ring light)
Package Contents
Packages with Lighting Options
• ELZ Stereo Zoom Binocular
• 10x eyepieces
• ErgoTrack Stand with 76mm focus rack
•
Choice of lighting
ELZ-PK2-AN (Fiber optic annular ring light guide)
ELZ-PK2-R3E (New super-bright low-profile LED ring light)
ELZ-PK2-R3 (New high intensity LED ring light with polarizer)
ELZ-PK2-E1 (Quadrant compact LED ring light)
Package Contents
Packages with Lighting Options
• ELZ Stereo Zoom Binocular
• 10x eyepieces
• Articulating arm with 76mm focus rack
• 0.5x auxiliary lens
•
Choice of lighting
ELZ-PK3-AN (Fiber optic annular ring light guide)
ELZ-PK3-R3E (New super-bright low-profile LED ring light)
ELZ-PK3-R3 (New high intensity LED ring light with polarizer)
ELZ-PK3-E1 (Quadrant compact LED ring light)
v
6 7
SSZ-II SERIES
PROVEN PERFORMANCE
With long-term reliability and customer satisfaction in mind, we have redesigned the SSZ-II
series Stereo Zoom Microscopes. We have retained the core quality and technology while
improving the ergonomics, optics, and performance. We are confident that you will
experience the same long-term dependability and enjoy the new features and benefits.
The SSZ series is the cornerstone of the Scienscope stereo zoom microscope line. The compact
and durable design, incorporating the Greenough optical system, delivers exceptional flatness
and depth of field and clarity, and accurate color. Over 15 years of continued customer satis-
faction, the SSZ has remained Scienscope’s most popular microscope.
• Quality construction and optics
• Variety of accessories
• Highest customer satisfaction
• True trinocular
Data Sheet / SSZ-II Body Specs
FEATURES
Precision CNC machine parts assem-
bled to the leading industry standards
extend the microscope’s life and lower
service and maintenance costs.
Microscope Body Zoom Range 0.67X - 4.5X
Magnication 6.7X-45X (w/10X eyepieces)
Zoom Ratio 1:6.7
Field of View 32.8mm - 4.9mm (w/ 10X eyepieces)
Work Distance 100MM
Dioptric Adjustment ±5
Interpupillary Adjustment 50-76mm
Eyepieces Inclination 45°
Microscope Ring Mount Diameter 76mm
View HD images in real-time on an HD
LCD monitor and capture images to an
SD card or connect to a computer via
USB to capture images, annotate, and
draw with the included software.
High eye-point eyepieces and ergo-
nomically located zoom control make
for one of the most comfortable
user experiences of any non-parallel
zoom system.
BUILD TO LASTUSER FRIENDLY - ERGONOMICHD CAMERA OPTIONS
SSZ-II Binocular Optical Specs
Objective
Lens
EyepiecesEyepieces
Working
Distance
10x10x 20x20x
MAGMAG
FOVFOV ( (mm)mm)
MAGMAG
FOVFOV ( (mm)mm)
0.3X 2x- 13.5x 109.5- 16.3 4x- 27x 59.7- 8.9 287mm
0.4X 2.7x- 18x 82.1- 12.2 5.4x- 36x 35.8- 5.3 217mm
* 0.5X 3.4x- 22.5x 65.7- 9.8 6.7x- 45x 35.8- 5.3 177mm
0.75X 5x- 33.8x 43.8- 6.5 10.1x- 67.5x 23.9- 3.6 117mm
* Default (1X) 6.7x- 45x 32.8- 4.9 13.4x- 90x 17.9- 2.7 100mm
1.5X 10.1x- 67.5x 21.9- 3.3 20.1x- 135x 11.9- 1.8 47mm
2x 13.4x- 90x 16.4- 2.4 26.8x- 180x 9- 1.3 26mm
PROVEN PERFORMANCE
Optical Magnication Formula
* Included in standard package
Total Magnication = (Mag. of Eyepieces) X (Mag. of objective zoom range on body) X ( Mag/ of objective lens)
SSZ-II BINOCULAR
SSZ-II TRINOCULAR
SZ-PK1 Systems on post stands with choice of lighting
Package Contents
Packages with Lighting Options
SZ-PK2 Systems on track stands with choice of lighting
SZ-PK3 Systems on articulating arms with choice of lighting
SZ-PK5S Systems on single arm boom stands with choice of lighting
Package Contents
Packages with Lighting Options
SZ-PK5D Systems on dual arm boom stands with choice of lighting
• SSZ-II Stereo Zoom Binocular, 10x eyepieces
• Eye guards
• Single arm boom stand with 76mm e-arm
• 0.5x auxiliary lens
•
Choice of lighting
SZ-PK5S-AN (Fiber optic annular ring light guide)
SZ-PK5S-R3E (New super-bright low-profile LED ring light)
SZ-PK5S-R3 (New high intensity LED ring light with polarizer)
SZ-PK5S-E1 (Quadrant compact LED ring light)
Package Contents
Packages with Lighting Options
• SSZ-II Stereo Zoom Binocular
• 10x eyepieces
• Dual arm boom stand with 76mm e-arm
• 0.5x auxiliary lens
•
Choice of lighting
SZ-PK5D-AN (Fiber optic annular ring light guide)
SZ-PK5D-R3E (New super-bright low-profile LED ring light)
SZ-PK5D-R3 (New high intensity LED ring light with polarizer)
SZ-PK5D-E1 (Quadrant compact LED ring light)
8 9
• SSZ-II Stereo Zoom Binocular
• 10x eyepieces
• ErgoPost Stand with 76mm focus rack
•
Choice of lighting
SSZ-II BINOCULAR SYSTEMS
SZ-PK1-AN (Fiber optic annular ring light guide)
SZ-PK1-R3E (New super-bright low-profile LED ring light)
SZ-PK1-R3 (New high intensity LED ring light with polarizer)
SZ-PK1-E1 (Quadrant compact LED ring light)
Package Contents
Packages with Lighting Options
• SSZ-II Stereo Zoom Binocular
• 10x eyepieces
• ErgoTrack Stand with 76mm focus rack
•
Choice of lighting
SZ-PK2-AN (Fiber optic annular ring light guide)
SZ-PK2-R3E (New super-bright low-profile LED ring light)
SZ-PK2-R3 (New high intensity LED ring light with polarizer)
SZ-PK2-E1 (Quadrant compact LED ring light)
Package Contents
Packages with Lighting Options
• SSZ-II Stereo Zoom Binocular
• 10x eyepieces
• Articulating arm with 76mm focus rack
• 0.5x auxiliary lens
•
Choice of lighting
SZ-PK3-AN (Fiber optic annular ring light guide)
SZ-PK3-R3E (New super-bright low-profile LED ring light)
SZ-PK3-R3 (New high intensity LED ring light with polarizer)
SZ-PK3-E1 (Quadrant compact LED ring light)
Packages with HEAVY DUTY articulating arm
with 15” vertical post Options
SZ-PK3FX-AN (Fiber optic annular ring light guide)
SZ-PK3FX-R3E (New super-bright low-profile LED ring light)
SZ-PK3FX-R3 (New high intensity LED ring light with polarizer)
SZ-PK3FX-E1 (Quadrant compact LED ring light)
SZ-PK3FX Systems on heavy duty articulating arms with choice of lighting
Package Contents
• SSZ-II Stereo Zoom Binocular
• 10x eyepieces
• HEAVY DUTY articulating arm with 15” vertical
post and 76mm focus moun
• 0.5x auxiliary lens
