E-SERIES MICROSCOPE CONFIGURATION CHART

Minimum required components that comprise a binocular

microscope system:

• Eyepieces

• Binocular Head

• Zoom Body

• Objective Lens

E-Series Microscopes configured as a binocular system with 0°-45° Tilting

Head.

E-Series

Binocular Conguaration

Minimum required components that comprise a trinocular

microscope system:

• Eyepieces

• Binocular Head

• Video Splitter

• Video Coupler

• Zoom Body

• Objective Lens

• Digital Camera

E-Series Microscopes configured as a trinocular system with optional video

splitter video coupler and CMOS Camera.

E-Series

Trinocular Conguaration

18 19

E-SERIES 20° BINOCULAR SYSTEMS

Package Contents

• E-Series 20° Binocular Head

• 10x Eyepieces (Pair)

• 1:6 Zoom Body (0.8x-5x)

• 1x Objective Lens

Packages with Lighting Options

CMO-PK2 (Dual LED Illuminated Track Stand

with reflected and transmitted light)

Package Contents

Packages with Lighting Options

• E-Series 20° Binocular Head

• 10x Eyepieces (Pair)

• 1:6 Zoom Body (0.8x-5x)

• 1x Objective Lens

• Dual focus ergo-track stand with stage

•

Choice of lighting

CMO-PK2-AN (Fiber optic annular ring light

guide)

CMO-PK2-R3E (New super-bright low-profile

LED ring light)

Package Contents

Packages with Lighting Options

• E-Series 20° Binocular Head

• 10x Eyepieces (Pair)

• 1:6 Zoom Body (0.8x-5x)

• 0.5x Achromatic objective Lens

•

Choice of lighting

CMO-PK3-E1 (Quadrant compact LED ring light)

CMO-PK3-R3E (NEW high intensity LED ring

light)

Package Contents

Packages with Lighting Options

• E-Series 20° Binocular Head

• 10x Eyepieces (Pair)

• 1:6 Zoom Body (0.8x-5x)

• 0.5x Achromatic objective Lens

• LED illuminator

• 76mm focus mount

•

Choice of lighting

CMO-PK5S-AN (Fiber optic annular ring light

guide)

CMO-PK5S-R3E (New super-bright low-profile

LED ring light)

CMO-PK5S-E1 (Quadrant compact LED ring

light)

Package Contents

Packages with Lighting Options

• E-Series 20° Binocular Head

• 10x Eyepieces (Pair)

• 1:6 Zoom Body (0.8x-5x)

• 0.5x Achromatic objective Lens

• LED illuminator

• 76mm focus mount

•

Choice of lighting

CMO-PK5D-AN (Fiber optic annular ring light

guide)

CMO-PK5D-R3E (New super-bright low-profile

LED ring light)

CMO-PK5D-E1 (Quadrant compact LED ring

light)

Package Contents

• E-Series 0°-45° Tilting Head

• 10x Eyepieces (Pair)

• 1:6 Zoom Body (0.8x-5x)

• 1x Objective Lens

Packages with Lighting Options

CMO-PK2E (Dual LED Illuminated Track Stand

with reflected and transmitted light)

Package Contents

Packages with Lighting Options

• E-Series 0°-45° Tilting Head

• 10x Eyepieces (Pair)

• 1:6 Zoom Body (0.8x-5x)

• 1x Objective Lens

• Dual focus ergo-track stand with stage

•

Choice of lighting

CMO-PK2E-AN (Fiber optic annular ring light guide)

CMO-PK2E-R3E (New super-bright low-profile

LED ring light)

Package Contents

Packages with Lighting Options

• E-Series 0°-45° Tilting Head

• 10x Eyepieces (Pair)

• 1:6 Zoom Body (0.8x-5x)

• 0.5x Achromatic objective Lens

•

Choice of lighting

CMO-PK3-E1-E (Quadrant compact LED ring light)

CMO-PK3-R3E-E (NEW high intensity LED ring

light)

Package Contents

Packages with Lighting Options

• E-Series 0°-45° Tilting Head

• 10x Eyepieces (Pair)

• 1:6 Zoom Body (0.8x-5x)

• 0.5x Achromatic objective Lens

• LED illuminator

• 76mm focus mount

•

Choice of lighting

CMO-PK5S-AN-E (Fiber optic annular ring light

guide)

CMO-PK5S-R3E-E (New super-bright low-profile

LED ring light)

CMO-PK5S-E1-E (Quadrant compact LED ring

light)

Package Contents

Packages with Lighting Options

• E-Series 0°-45° Tilting Head

• 10x Eyepieces (Pair)

• 1:6 Zoom Body (0.8x-5x)

• 0.5x Achromatic objective Lens

• LED illuminator

• 76mm focus mount

•

Choice of lighting

CMO-PK5D-R3E-E (New super-bright low-profile

LED ring light)

CMO-PK5D-E1-E (Quadrant compact LED ring

light)

E-SERIES 0°- 45° BINOCULAR SYSTEMS

20 21

VersaCam (CC-HDmI-CD2)

Excellent HDMI camera with Direct/USB output and 1080p

Resolution. Very Fast refresh rate on Live Video at 60 Frames

Per Second Sensor. Digital Zoom for increasing magnification.

Image Capture and Movie Capture built into camera on SD Card

(No Computer Required). Compatible with all Scienscope Lenses

and Microscope including Macro Lens (CC-97-LN1) and Micro Zoom

(MZ7A-Zoom). Two USB Ports allow connection to a computer or

network. Video Image Express Measurement Software is a great

addition.

CAMERA FEATURES USING HDMI CONNECTION

• On-screen control bar and setting menu

• Image and video capture to SD card

• Split-screen live image/captured image comparison (picture in picture)

• Image and video gallery / Image and video review

• Wireless mouse control

CAMERA FEATURES USING USB 2.0 CONNECTION

• Image and video capture using Windows 10 camera app

• Image and video capture using the included software

• Annotation and drawing tools on live captured images

• • Upgrade software with FOV measurement tools Upgrade software with FOV measurement tools

Camera

Features

1080p

Resolution

HDMI

Live Image

USB 2.0 or 3.0

Connection/Capture

SD Card

Capture

USB Thumb

Drive Capture

WIFI Transmitter

& Connection

Live

Annotation

AutoFocus

Measurement

Data Export

Integrated FOV

Measurement

Live Image/

Capture Image

Compare

DXF

Overlay

Onscreen

Reticle

Digital Caliper/

Counting Grid

Live Image

Processing

Digital

Zoom

Settings

Export & Import

SmartCam-Ultra

(CC-SMART-4K-AF)

l l l l l l l l l l l l l l l l l l

VersaCam

(CC-HDMI-CD2)

l l l l l l l l

smartCam-ultra aF (CC-smart-4K-aF)

The SmartCam-Ultra AF from Scienscope is our most

advanced 4k resolution camera. It features a vivid 4K image to a

live monitor (HDMI) or 8.2 Megapixel image via USB 3.0 and WiFi

to a computer. Includes a host of onboard image processing and

measurement tools accessible using a mouse connected to the

camera via its onboard software. Capture images to SD card, USB

Flash drive, USB 3.0, and WiFi.

Measure anything using the onboard field of view measuring tools,

DXF overlay, or multi-line

generator. Export your measurement data and images with measured objects!

4K HDMI, 8.2 MP USB 3.0, and WiFi Camera w/ AutoFocus

Featured with all Package 12 Microscope configurations (PK12)

CAMERA FEATURES USING HDMI CONNECTION

• Live measurement and annotation tools

• Image and video capture to SD card or USB Flash drive

• Split-screen live image/captured image comparison

• Image and video gallery / Image and video review

• Export measurement data to SD card or USB Flash

• Wireless mouse control

CAMERA FEATURES USING USB 3.0 OR WIFI CONNECTION

• Image and video capture using Windows 10 camera app

• Measure and annotate using included WiFi and USB 3.0 software

• Image and video capture using the included software

• Directly email or print images

• Export measurement data

SPECS

• 4k (3840 x 2160 @ 60 fps) HDMI

• 8.2 Megapixel (3840 x 2160 @ 60 fps) USB 3.0 and WiFi

—

Easy to use live annotation tools! Easy to use live annotation tools!

Make notes and capture the image!Make notes and capture the image!

1080p HDMI and 2 MP USB 2.0 Camera

Featured with all Package 10 Microscope configurations (PK10)

SPECS

• 1080p HD (1920x1080 @ 60 fps) HDMI

• 2 Megapixel (1920x1080 @ 30 fps) USB 2.0

—

Comes loaded with image enhancement, capture Comes loaded with image enhancement, capture

comparison, and memory management tools.comparison, and memory management tools.
