1-5 1.2.3. 1-4. Specification (XY : mm, θ : ° ) Chip 0402 XY : ± 0.05 , : ± 5.0 , Cp ≥ …
Samsung Component Placer SM421 Introduction
1-4
1-2.
(Vision
)
Components
(Options)
FOV25mm Mega Pixel Camera
FOV16mm Mega Pixel Camera
Chips
0603~22mm 0402 ~ 14mm
IC,
Connector
22mm ,
Lead Pitch : 0.5mm
14mm ,
Lead Pitch : 0.4mm
BGA,
CSP
17mm ,
Ball Pitch : 0.75mm
14mm ,
Ball Pitch : 0.65mm
Maximum
Height
12mm
1.2.2.2. Stage Vision
1-3.
(Vision
)
Components
(Options)
Standard
FOV45mm
FOV35mm
Chips
42.0mm , Lead Pitch: 0.4mm
.
32.0mm , Lead Pitch : 0.3mm
.
Connector 55~75mm()
– MFOV
,
Lead Pitch: 1.0mm
IC,
Connector
42~55mm, Lead Pitch : 0.8mm
.(MFOV
)
32~42mm, Lead Pitch : 0.5mm
.(MFOV
)
42~55mm, Lead Pitch : 0.65mm
.(MFOV
)
42.0mm , Ball Pitch : 1.0mm
.
32.0mm , Ball Pitch: 0.5mm
.
BGA
42~55mm, Ball Pitch : 1.0mm
. (MFOV
)
42~55mm, Ball Pitch: 1.0mm
(MFOV
)
Maximum
Height
15mm
MFOV()54.0mmBGA75.0mm
ConnectorPitch
(Local Agent)
1-5
1.2.3.
1-4.
Specification (XY: mm, θ: °)
Chip 0402 XY : ±0.05 , : ±5.0 , Cp≥1.0FOV16mm (Flying)
Chip 0603 XY : ±0.08 , : ±5.0 , Cp≥1.0FOV25mm (Flying)
Chip 1005 XY : ±0.10 , : ±5.0 , Cp≥1.0
FOV25mm (Flying)
QFP100 0.5 P
XY : ±0.06 , : ±0.25 , Cp≥
1.0
FOV 35, 45mm (Stage)
QFP168 0.3 P XY : ±0.03 , : ±0.2 , Cp≥1.0FOV 35mm (Stage)
QFP256 0.4 P XY : ±0.05 , : ±0.1 , Cp≥1.0FOV 35, 45mm (Stage)
FOV 35mm (Stage)
MFOV
QFP304 0.5 P
XY : ±0.06 , : ±0.1 , Cp≥1.0
FOV 45mm (Stage)
FOV25mm (Flying)
BGA256 1.0 P
XY : ±0.10 , : ±0.4 , Cp≥1.0
FOV 35, 45mm (Stage)
BGA 12mm 0.5 P XY : ±0.06 , : ±0.3 , Cp≥1.0FOV 35, 45mm (Stage)
FOV25mm (Flying)
BGA 17mm 0.75 P XY : ±0.10 , : ±0.4 , Cp≥1.0
FOV 35, 45mm (Stage)
FOV 35mm (Stage)
MFOV
BGA 52mm 1.27 P XY : ±0.10 , : ±0.3 , Cp≥1.0
FOV 45mm (Stage)
Connector 75mm 1.27 P
XY : ±0.18 , : ±0.25 , Cp≥
1.0
FOV 45mm (Stage)
MFOV
R
Samsung Component Placer SM421 Introduction
1-6
1.2.4.
PCB
Nozzle
1.2.4.1.
: 1608 chip
IPC
1.2.4.1.1.
1-5.
SM421
Chip 21,000 CPH (1608)
15,000 CPH (SOP16)
IPC(Pick Up)
5,500 CPH (QFP100)
IC
5,500 CPH (BGA256)
IPC(Pick Up)
(1 msec ).
PCB
