2-5 2.3. PC 2.3.1. 2.3.1.1. Software SM421 MMI Software 2.3.2. 2.3.2.1. Hardware W indows XP Embedd ed CPU Intel Pent ium™ 4/ 3.2E MC68040 (VME) Hitachi HDD 80G B, IDE DDR SDRAM 51…
Samsung Component Placer SM421 Introduction
2-4
<TRANS SPECIFICATION>
1. Capacity: 5.0 KVA
2. Frequancy: 50/60Hz
3. Phase: 3φ
4. Connection: Y-Y
5. Rated primary voltage: 200/208/220/240/380/415 VAC
Rated primary voltage: 6.96 A
6. Secondary #1: 1φ 220-2 KVA
Secondary #2: 3φ 220-3 KVA
: 4.7 KVA
: 50 / 60 Hz
�
C/S�
2-5
2.3. PC
2.3.1.
2.3.1.1. Software
SM421 MMI Software
2.3.2.
2.3.2.1. Hardware
Windows XP Embedded
CPU Intel Pentium™ 4/ 3.2E
MC68040 (VME)
Hitachi HDD 80GB, IDE
DDR SDRAM 512MB(3200)
USB Port (USB Memory)
Keyboard: Mini Keyboard (86 Key)
Mouse: Optimical mouse (Microsoft )
2.3.2.2. Display
Monitor: 12 inch TFT LCD (1024 x 768)
Samsung Component Placer SM421 Introduction
2-6
2.4. XY-
2-1. XY-
区
分
格
注
X: AC Servo + Ball Screw
Y: AC Servo + Ball Screw (Twin)
750 W
1000 W * 2
X 1:1 , Y 1:1
± 0.01 mm
X: 3.2 µm/pulse
Y: 3.0 µm/pulse
X-
758 mm
752 mm
H/W Limit
S/W Limit
Y-
995 mm
989 mm
H/W Limit
S/W Limit
1.8 m/sec, 3G
1.8 m/sec, 3G
X
Y
2.5. Head
2-2. Head
6 Nozzle 1 Nozzle
Head
30 mm
8mm, 12mm, 16mm
AC Servo motor + Belt & LM Motor: 30W
96 mm
Stopper to stopper
0.005 mm/pulse
Z
± 0.01 mm
Micro stepping motor +
Belt & Pulley
Head 1/2, 3/4, 5/6 Pair
Unlimited°
0.014 °/pulse
R
± 0.03 °
AC servo motor + Belt & CamMotor: 50 W
0.018
˚
/pulse
Swing
Mirror
0.02˚
Clamping
Taper clamp + Ball
Head
Nozzle holder
Clamping
ball
