P-310-004(1_2).pdf - 第41页

Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 340 0914F1 15 MGCA TCH_BRACKET 2 109140512U-010 341 0914F1 1G MG_CA TCH_UKE_R 2 109140512U-01 1 342 221AA030 ROHS_HEX-SCT 28 M5L12 109140512U-012 343 221HA005 W ASHER 32 S…

Fig. A1

型式 



MODEL

1007-003

SIGMA-G5

Fig. A1

MODEL

Fig. A1-4 SIGMA-G5SD

UNIT-12

UNIT-10

UNIT-11-2

UNIT-13-1

Key No. PART No. PART NAME Q’ty

REMARKS

NOTE

340 0914F115 MGCATCH_BRACKET 2 109140512U-010

341 0914F11G MG_CATCH_UKE_R 2 109140512U-011

342 221AA030 ROHS_HEX-SCT 28 M5L12 109140512U-012

343 221HA005 WASHER 32 SW5 109140512U-013

344 221HA105 WASHER 28 FW5 109140512U-014

345 0914F11V NAME_PLATE_G5 1 109140512U-015

347 221AA029 ROHS_HEX-SCT 4 M5L10 109140512U-017

348 221HA303 ROHS_WASHER 4 SW5 109140512U-018

356 221AA044 ROHS_HEX-SCT 6 M6L20 109140512U-026

357 221HA006 WASHER 6 SW6 109140512U-027

358 221HA106 WASHER 4 FW6 109140512U-028

359 221HA304 ROHS_WASHER 2 BW6 109140512U-029

360 221AA057 ROHS_HEX-SCT 10 M8L25 109140512U-030

361 221HA007 WASHER 10 SW8 109140512U-031

362 221HA107 WASHER 10 FW8 109140512U-032

377 221AA045 ROHS_HEX-SCT 4 M6L25 1091400708-007

378 221HA006 WASHER 4 SW8 1091400708-008

379 221HA106 WASHER 4 FW8 1091400708-009

382 221AA033 ROHS_HEX-SCT 1 M5L25 1091400708-012

383 221AA031 ROHS_HEX-SCT 1 M5L16 1091400708-013

394 216A0334 COLLAR 4 1091400304-004

395 221CA010 SET_SCREW 4 SET M6L6 1091400304-005

396 0914B10D BRACKET 2 1091400304-006

3A2 221AA030 ROHS_HEX-SCT 14 M5L12 1091400304-012

3A3 221HA005 WASHER 14 SW5 1091400304-013

3A4 221HA303 ROHS_WASHER 14 BW5 1091400304-014

3B3 221AA077 ROHS_HEX-SCT 4 M12L30 1091400304-023

3B4 221HA009 WASHER 4 SW12 1091400304-024

3B5 221HA209 ROHS_WASHER 4 FWS12 1091400304-025

SIGMA-G5SA

SIGMA-G5SB

SIGMA-G5SC

SIGMA-G5SD

1104-004

Fig. A1

SIGMA-G5

Fig. A1

MODEL

Fig. A1-4

MEMO
