6
OPTIONS FOR COMPONENT / PCB HANDLING
OPTIONS TO APPLY / REMOVE MEDIA
BOARD HOLDER CLAMPS / FINGERS
PCB Holder Clamps, Fingers and End
Stop can be used to rmly and accurately
locate the PCB in the Board Holder.
1 = Board Holder Clamp -10mm (2 pcs.)
(n)
2 = Borad Holder Clamp ONYX 21
(set of 4 pcs.) (o)
3 = Board End Stop (1 pce.) (p)
4 = Board Holder Finger (1 pce.) (m)
DIP FLUXER KIT FASET1
Fluxer Kit with a range of uxer plates for
various uxing applications.
See separate data sheet.
SITE CLEANING SYSTEM
This non-contact Site Cleaning System is
used to remove solder and ux residues
before placing a new component.
This option tracks the board surface
using non-contact vacuum control for
adjusting the Z height except when
installed on the ONYX 21 where the Z
height is constant.
Various suction tip forms are available on
request.
Order no.:
See on rear side
Order no.:
50.21.022 50.24.620 50.25.120 50.29.120
Order no.:
50.21.045 50.24.671 50.25.167 50.29.195
TIME / PRESSURE DISPENSER
To dispense solder paste, ux, adhesive
epoxy, underll or other uids.
PASTE ON DEVICE QFN
Used to screen solder paste onto the
underside of a component.
DIP FLUXER KIT
Fluxer Kit with Fluxer Plate Holder and
Squeegee.
Fluxer Plates with different depths are
available on request.
Kit contents:
1 = Fluxer Plate Holder
2 = Squeegee
Other accessories:
3 = Fluxer Plate (specify depth)
4 = Tray Plate for Bridge Tray (k)
Order no.:
50.21.036 50.24.663 50.25.159 50.29.183
Order no.:
50.29.104
Order no.:
50.21.029 50.24.660 50.25.156 50.29.181
1 23 4
1
2
3
4
7
OPTIONS TO APPLY / REMOVE MEDIA
OPTIONS FOR MACHINE / SOFTWARE
REBALLING TOOL
For reballing components. With the
precision and high level of automation
with the ONYX 29 BGA components can
be tted again with solder balls.
DIRECT VIEW CAMERA
Enables real time monitoring of the
machine process. The Camera is either
on an articulated arm that is table
mounted or on a machine mounted
holder. An LED light is available.
FUME EXTRACTION
The Fume Extraction System is mounted
to the machine head to collect the fumes
emitted during machine processes for
extraction by an external ltering system
(not included).
Order no.:
50.29.188
Order no.:
50.21.005 50.24.617 50.25.117 50.29.117
Order no. with machine holder:
50.24.651 50.25.141 50.29.161
Order no. with folding arm:
50.21.038 50.24.665 50.25.161 50.29.187
Order no. illumination:
50.21.009 50.24.644 50.25.144 50.29.144
ADVANCED SOFTWARE ACCESS
Providing extended Software Access
including explanation and training with
practical examples of:
• conguration and calibration of
peripherals
• creation and editing process lists
• multiple image / assembly
programming
TRACEABILITY LICENSE
A Traceability License can be provided
for management report documentation
and quality control.
MACHINE BENCH ESD
Machine Benche with ESD surfaces and
monitor stands are available for all ONYX
models to provide a rigid and stable
platform for the machine.
Order no. machine bech:
50.21.031 50.24.618 50.25.118 50.29.174
Order no. support bench:
50.21.032 50.24.639 50.25.139 50.29.139
Order no.:
50.21.047 50.24.635 50.25.124 50.29.107
Order no.:
50.32.190
8
ACCESSORIES
Accessories Legend ONYX 21
Order no.
ONYX 24
Order no.
ONYX 25
Order no.
ONYX 29
Order no.
Insertion Tool rectangular for Components 6 - 47 mm a) AU6LGA47R
Insertion Tool rectangular 6 - 47 mm, incl. Adaptor Plate for
Tray Bridge
b) - - - 50.29.194
Universal Pickup Frame, for Components up to 60mm - 50.21.050 50.24.675 50.25.172 50.29.198
Adaptor Plate 45 ° for Insertion Tool c) 50.21.046 50.24.672 50.25.168 50.29.196
Adaptor Plate 50 x 100mm to 41 x 41 mm d) 50.21.048 50.24.673 50.25.169 -
Adaptor Plate for Nozzle Changer e) - - - 50.29.193
Adaptor Plate for Bridge Tray f) - - - 50.29.122
Tray Plate for Bridge Tray g) - - - 50.29.119
Component Reject Bin h) - - - 50.29.136
Board Holder Finger i) 50.21.026 50.24.659 50.25.155 50.29.180
Board Holder Clamp -10 mm j) 50.21.034 50.24.662 50.25.158 50.29.165
Board Holder Clamp k) 50.21.015 - - -
Board End Stop l) 50.21.035 50.24.653 50.25.142 50.29.164
Board Support Extension m) 50.21.039 50.24.666 50.25.162 50.29.189
Warm-up Nozzle standard n) 22.15.214
Warm-up Nozzle for Nozzle Changer o) - - - 22.15.215
Additional Network Card p) 17.00.138
