INPUT OUTPU T LOOP ADRS CC ADRS ＮＡＭＥ LOOP ADRS CC ADRS ＮＡＭＥＬｏｏｐ３ＡＤＤ 0 128 NOZZLE CHANGE 1 OPEN SENSOR Ｌｏｏｐ３ＡＤＤ 0 320 REAR PANEL ENABLE LED ５ 1 129 NOZZLE CHANGE 1 CLOSE SENSOR ４ 1 321 FEEDER EXCHANGE LED(REAR) 2 12A H…

INPUT OUTPU

LOOP ADRS CC ADRS ＮＡＭＥ LOOP ADRS CC ADRS ＮＡＭＥ

Ｌｏｏｐ２ＡＤＤ 0 0A8 BATCH EXCHANGE DISPLAY B IN Ｌｏｏｐ２ＡＤＤ 0 2A0 NOT USED

５ 1 0A9 BATCH EXCHANGE DISPLAY C IN ４ 1 2A1 NOT USED

2 0AA CART B PRESENCE 2 2A2 NOT USED

3 0AB CART C PRESENCE 3 2A3 NOT USED

4 0AC CART B UNLOCK SENSOR 4 2A4 NOT USED

5 0AD CART B LOCK SENSOR 5 2A5 NOT USED

6 0AE CART C UNLOCK SENSOR 6 2A6 NOT USED

7 0AF CART C LOCK SENSOR 7 2A7 NOT USED

ＡＤＤ 0 0B0 H-AXIS INTERLOCK TIMING ＡＤＤ 0 2B0 NOT USED

６ 1 0B1 FAN ALARM ６ 1 2B1 NOT USED

2 0B2 AIR PRESSURE SENSOR 2 2B2 ZA OPEN

3 0B3 ENABLING SW 3 2B3 ZA CLOSE

4 0B4 ARROW KEY ↑ 4 2B4 ZB OPEN

5 0B5 ARROW KEY → 5 2B5 ZB CLOSE

6 0B6 ARROW KEY ↓ 6 2B6 NOT USED

7 0B7 ARROW KEY ← 7 2B7 NOT USED

ＡＤＤ 0 0B8 ＯＮＳＷＡＤＤ 0 2B8 SIGNAL TOWER(RED)

７ 1 0B9 HIGH SW ７ 1 2B9 SIGNAL TOWER(YELLOW)

2 0BA

FEEDER EXCHANGE COMPLETE(F)

2 2BA SIGNAL TOWER(GREEN)

3 0BB SERVO SW 3 2BB

COUPLING SIGNAL RIGHT OUTPUT

4 0BC START SW(FRONT) 4 2BC HIGH SW LAMP

5 0BD ＳＴＯＰＳＷ 5 2BD FEEDER EXCHANGE LED(FRONT)

6 0BE FRONT PANEL ENABLE SW 6 2BE ＳＴＡＲＴＬＥＤ

7 0BF ＲＥＳＥＴＳＷ 7 2BF FRONT PANEL ENABLE LED

ＡＤＤ 0 0E8 BUZZER OFF SW 1 ＡＤＤ 0 2E0

BATCH EXCHANGE DISPLAY B LED

Ｄ 1 0E9 BUZZER OFF SW 2 Ｃ 1 2E1

BATCH EXCHANGE DISPLAY C LED

2 0EA WIDTH ADJ. INTERLOCK (RIGHT) 2 2E2 LIGHT CURTAIN LIGHT OFF

3 0EB WIDTH ADJ. INTERLOCK (LEFT) 3 2E3 VACUUM VALVE

4 0EC BAD MARK 4 2E4 VACUUM OFF VALVE

5 0ED THRMAL TRIP 5 2E5 STOPPER DOWN VALVE

6 0EE NOT USED 6 2E6 EXHAUST AIR VALVE

7 0EF COVER OPEN(OUTSIDE) 7 2E7 NOT USED

ＡＤＤ 0 0F0 PARTS CHANGE INTERLOCK(F) ＡＤＤ 0 2F0 NOT USED

Ｅ 1 0F1 PARTS CHANGE INTERLOCK(R) Ｅ 1 2F1 NOT USED

2 0F2 NOT USED 2 2F2 LOADER RECEIVE

3 0F3 NOT USED 3 2F3 TABLE-1 RECEIVE

4 0F4 NOT USED 4 2F4 TABLE-1 RUNNING

5 0F5 NOT USED 5 2F5 UNLOADER RECEIVE

6 0F6 NOT USED 6 2F6 NOT USED

7 0F7 NOT USED 7 2F7 NOT USED

ＡＤＤ 0 0F8 NOT USED ＡＤＤ 0 2F8 NOZZLE CHANGE 1 OPEN VALVE

Ｆ 1 0F9 NOT USED Ｆ 1 2F9

NOZZLE CHANGE 1 CLOSE VALVE

2 0FA NOT USED 2 2FA START SIGNAL

3 0FB NOT USED 3 2FB H-AXIS INTERLOCK TIMING

4 0FC NOT USED 4 2FC STOPPER UP VALVE

5 0FD NOT USED 5 2FD SUPPORT UP VALVE

6 0FE NOT USED 6 2FE SUPPORT DOWN VALVE

7 0FF NOT USED 7 2FF MANUAL MODE SIGNA

INPUT OUTPU

LOOP ADRS CC ADRS ＮＡＭＥ LOOP ADRS CC ADRS ＮＡＭＥ

Ｌｏｏｐ３ＡＤＤ 0 128

NOZZLE CHANGE 1 OPEN SENSOR

Ｌｏｏｐ３ＡＤＤ 0 320 REAR PANEL ENABLE LED

５ 1 129

NOZZLE CHANGE 1 CLOSE SENSOR

４ 1 321 FEEDER EXCHANGE LED(REAR)

2 12A H-AXIS ORIGIN 2 322 START LED(REAR)

3 12B S-AXIS ORIGIN 3 323 DISCARD BLOW

4 12C RIGHT RAIL INLET PCB DETECT 1 4 324 PCB LIGHTING RING

5 12D

RIGHT RAIL OUTLET PCB DETECT 2

5 325 PCB LIGHTING SPOT

6 12E COUPLING SIGNAL RIGHT INPUT 6 326 EMPTY PARTS(REAR)

7 12F EMERGENCY STOP 7 327 NOT USED

ＡＤＤ 0 130 STAGE ARRIVAL PCB DETECT 3 ＡＤＤ 0 330 NOT USED

６ 1 131 SUPPORT UPPER LIMIT ６ 1 331 NOT USED

2 132 SUPPORT LOWER LIMIT 2 332 BUZZER 1

3 133 STOPPER UPPER LIMIT 3 333 BUZZER 2

4 134 REAR PANEL ENABLE SW 4 334 VACUUM DETECTION RESET

5 135

FEEDER EXCHANGE COMPLETE(R)

5 335 SUPPLY LIGHTING RING

6 136 START SW(REAR) 6 336 SUPPLY LIGHTING SPOT

7 137 MANUAL MODE WELD CHECK 7 337 CAMERA CHANGE OUPUT

ＡＤＤ 0 138 VACUUM CH1-1 ＡＤＤ 0 338 BLOW VALVE 1

７ 1 139 VACUUM CH2 ７ 1 339 BLOW VALVE 2

2 13A VACUUM CH1-2 2 33A BLOW VALVE 3

3 13B NOT USED 3 33B BLOW VALVE 4

4 13C NOT USED 4 33C BLOW VALVE 5

5 13D NOT USED 5 33D BLOW VALVE 6

6 13E NOT USED 6 33E BLOW VALVE 7

7 13F NOT USED 7 33F BLOW VALVE 8

ＡＤＤ 0 168 ＦＡＮＡＬＡＲＭ（ＸＹＤＲＩＶＥＲ）ＡＤＤ 0 360 SIGNAL TOWER OUTPUT(RED)

Ｄ 1 169 ＦＡＮＡＬＡＲＭ（ＴＲＡＹＤＲＩＶＥＲ）Ｃ 1 361

SIGNAL TOWER OUTPUT(YELLOW)

2 16A ＦＡＮＡＬＡＲＭ（ＲＥＳＥＲＶＥ） 2 362 SIGNAL TOWER OUTPUT(GREEN)

3 16B

PARTS WASTES BOX CHECK SENSOR

3 363 IPC RIGHT DOWN

4 16C IPC RIGHT LOWER LIMIT 4 364 IPC LEFT DOWN

5 16D IPC RIGHT UPPER LIMIT 5 365 NOT USED

6 16E IPC LEFT LOWER LIMIT 6 366 NOT USED

7 16F IPC LEFT UPPER LIMIT 7 367 NOT USED

ＡＤＤ 0 170 NOT USED ＡＤＤ 0 370 NOT USED

Ｅ 1 171 NOT USED Ｅ 1 371 NOT USED

2 172 NOT USED 2 372 GROUP EMPTY P.C.B.

3 173 NOT USED 3 373 LOADER RAIL EMPTY P.C.B.

4 174 NOT USED 4 374 COUT UP SIGNAL

5 175 NOT USED 5 375 MACHINE EMPTY P.C.B.

6 176 NOT USED 6 376 ＥＪＥＣＴＥＲＯＮ/ＯＦＦ

7 177 NOT USED 7 377 COUNT UP SIGNAL

ＡＤＤ 0 178 NOT USED ＡＤＤ 0 378 VACUUM VALVE 1

Ｆ 1 179 NOT USED Ｆ 1 379 VACUUM VALVE 2

2 17A NOT USED 2 37A VACUUM VALVE 3

3 17B NOT USED 3 37B VACUUM VALVE 4

4 17C NOT USED 4 37C VACUUM VALVE 5

5 17D NOT USED 5 37D VACUUM VALVE 6

6 17E NOT USED 6 37E VACUUM VALVE 7

7 17F NOT USED 7 37F VACUUM VALVE 8

INPUT OUTPU

LOOP ADRS CC ADRS ＮＡＭＥ LOOP ADRS CC ADRS ＮＡＭＥ

Ｌｏｏｐ４ＡＤＤ 0 1A8 EMPTY PARTS RESET 2^0 Ｌｏｏｐ４ＡＤＤ 0 3A0 FEEDER(F) EXCHANGE

５ 1 1A9 EMPTY PARTS RESET 2^1 ４ 1 3A1 FEEDER(F) STANDBY

2 1AA EMPTY PARTS RESET 2^2 2 3A2 EMPTY P.C.B.

3 1AB EMPTY PARTS RESET 2^3 3 3A3 NOT USED

4 1AC EMPTY PARTS RESET 2^4 4 3A4 NOT USED

5 1AD EMPTY PARTS RESET 2^5 5 3A5

MANUAL SETTING TRAY SIGNAL TOWER

6 1AE

EMPTY PARTS LAMP OFF COMMAND

6 3A6 TRAY PARTS EXCHANGE LED

7 1AF TRAY B EMPTY PARTS RESET 7 3A7 NOT USED

ＡＤＤ 0 1B0 THICKNESS DATA 2^0 ＡＤＤ 0 3B0 NOT USED

６ 1 1B1 THICKNESS DATA 2^1 ６ 1 3B1 NOT USED

2 1B2 THICKNESS DATA 2^2 2 3B2 FEEDER(R) EXCHANGE

3 1B3 THICKNESS DATA 2^3 3 3B3 TZA EXCHANGE

4 1B4 THICKNESS DATA 2^4 4 3B4 TZB EXCHANGE

5 1B5 THICKNESS DATA 2^5 5 3B5 FEEDR(R) STANDBY

6 1B6 THICKNESS DATA 2^6 6 3B6 TZA STANDBY

7 1B7 THICKNESS DATA 2^7 7 3B7 TZB STANDBY

ＡＤＤ 0 1B8 THICKNESS DATA 2^8 ＡＤＤ 0 3B8 TRAY A EXCHANGE COMPLETE

７ 1 1B9 THICKNESS ERROR ７ 1 3B9 TRAY A EXCHANGE POS. MOVE

2 1BA THICKNESS END 2 3BA TRAY A SIGNAL TOWER

3 1BB ZC CLOSE LIMIT 3 3BB TZA-AXIS BRAKE

4 1BC ZC OPEN LIMIT 4 3BC TRAY B EXCHANGE COMPLETE

5 1BD ZD CLOSE LIMIT 5 3BD TRAY B EXCHANGE POS. MOVE

6 1BE ZD OPEN LIMIT 6 3BE TRAY B SIGNAL TOWER

7 1BF TRAY PARTS EXCHANGE SWITCH 7 3BF TZB-AXIS BRAKE

ＡＤＤ 0 1E8 TRAY A EXCHANGE COMPLETE ＡＤＤ 0 3E0 SPEED 2^0(LOADER)

Ｄ 1 1E9 TRAY A EXCHANGE POS. MOVE Ｃ 1 3E1 SPEED 2^1(LOADER)

2 1EA TRAY A SAFETY INPUT 2 3E2 SPEED 2^2(LOADER)

3 1EB TZA,TWA INTERLOCK 3 3E3 DIRECTION(LOADER)

4 1EC FEEDER(F) INTERLOCK 4 3E4 SERVO ON(LOADER)

5 1ED FEEDER(R) INTERLOCK 5 3E5 ALARM CLEAR(LOADER)

6 1EE TZA-AXIS BRAKE INPUT 6 3E6 NOT USED

7 1EF TRAY A EXCHANGE POSITION 7 3E7 NOT USED

ＡＤＤ 0 1F0 TRAY B EXCHANGE COMPLETE ＡＤＤ 0 3F0 NOT USED

Ｅ 1 1F1 TRAY B EXCHANGE POS. MOVE Ｅ 1 3F1 NOT USED

2 1F2 TRAY B SAFETY INPUT 2 3F2 SPEED 2^0(UNLOADER)

3 1F3 TZB,TWB INTERLOCK 3 3F3 SPEED 2^1(UNLOADER)

4 1F4 TZA INTERLOCK 4 3F4 SPEED 2^2(UNLOADER)

5 1F5 TZB INTERLOCK 5 3F5 DIRECTION(UNLOADER)

6 1F6 TZB-AXIS BRAKE INPUT 6 3F6 SERVO ON(UNLOADER)

7 1F7 TRAY B EXCHANGE POSITION 7 3F7 ALARM CLEAR(UNLOADER)

ＡＤＤ 0 1F8 COVER OPEN(FRONT) ＡＤＤ 0 3F8

EMPTY PARTS DISPLAY RESET 2^0

Ｆ 1 1F9

FEEDER SEATING DETECT(FRONT)

Ｆ 1 3F9

EMPTY PARTS DISPLAY RESET 2^1

2 1FA FEEDER SEATING DETECT(REAR) 2 3FA

EMPTY PARTS DISPLAY RESET 2^2

3 1FB COVER OPEN(REAR) 3 3FB

EMPTY PARTS DISPLAY RESET 2^3

4 1FC LEFT RAIL INLET PCB DETECT 4 4 3FC

EMPTY PARTS DISPLAY RESET 2^4

5 1FD

LEFT RAIL OUTLET PCB DETECT 5

5 3FD

EMPTY PARTS DISPLAY RESET 2^5

6 1FE NOZZLE PRESENCE 6 3FE

EMPTY PARTS DISPLAY COMMAND

7 1FF COUPLING SIGNAL LEFT INPU

7 3FF TRAY B EMPTY PARTS DISPLA
