Get the most out of

your machine

AGILIS SMART BINS

Increase your ﬂexibility and eciency by preload-

ing material in Agilis Smart Bins. An electronic label,

attached to the front of the bin, communicates with

the MYCenter SW via a radio base station. The result

is intuitive paperless kitting guidance - right in front

of you.

Agilis Bins for ecient o-line preparation.

LRA for even the largest tape reels.

Even with the industry’s most agile feeder systems, there are times when

standard solutions won’t suce. Should you have special feeder requirements,

we can help build a solution to ﬁt your application. From magazine and stick

positioner alterations to a specially designed range of accessories, we do

everything we can to help you get more out of your feeders and equipment.

AGILIS

Typical components 01005 up to PLCC20

Tape widths

(no. of feeders in

magazine)

8 mm (max 16 pcs)

12, 16 mm (max 8 pcs)

Tape depth 2.5 mm (width 8)

10.5 mm (width 12 and 16)

Tape material Plastic, paper, metal

Reel size 180 mm (7”), 330 mm (13”)

SPECIFICATIONS

TWM

Tray table size Capacity

One module 2 JEDEC trays

(1 with T-Series or 500T2 Inline)

Two modules 5 JEDEC trays

(4 with T-Series or 500T2 Inline)

Three modules 7 JEDEC trays

(5 with T-Series or 500T2 Inline)

AGILIS STICK MAGAZINE

Stick pallet types ASP10 and ASP1028, remov-

able with ID and barcode

Max stick capacity 16 pcs of 10 mm positions

Typical components SOIC, DPAK, PLCC, connectors

Max component length 50 mm

Max stick width Machine dependent

Max 160 mm

Max stick height ASP10 10.5 mm

Max stick height

ASP1028

10.5 mm in pos. 1–8

28.5 mm in pos. 9–16

(1) Including tray.

(2) Max component height 33 mm (1.3”) with pallets removed from positions above.

(3) Max component height 40 mm (1.6”) with pallets removed from positions above.

(1) Including handle.

TRAY EXCHANGER TEX

Pallet capacity 32 narrow pallets or 16 wide pallets

Replenishing

time

Less than 1 minute, 32 trays, includ-

ing automatic barcode scanning

Dimensions Height: 1 361 mm (53.6”)

Width: 534 mm (211”)

Depth over all: 1 683 mm (66.3”)

(1)

Depth to machine front: 587 mm

(23.2”)

(1)

Power

requirements

100–250V, max 2.2kVA

TEX PALLET

Type Max tray size

Max component

height

(1)

Narrow pallet

JEDEC

W: 143 mm (5.6”) x

L: 323 mm (12.7”)

8 mm (0.3”)

(2)

Narrow pallet

with spring

W: 143 mm (5.6”) x

L: 337 mm (13.3”)

16 mm (0.7”)

(3)

Narrow

pallet

W: 143 mm (5.6”) x

L: 337 mm (13.3”)

16 mm (0.7”)

(3)

Wide pallet

W: 300 mm (11.8”) x

L: 337 mm(13.3”)

16 mm (0.7”)

(3)

Agilis patent information

The Agilis feeder system is protected by, amongst others:

US Patents No. 6,631,870; 6,773,542; 6,782,606; 6,869,040; 6,948,541; 7,096,571; 7,228,620 and 7,713,376

European Patents No. 1,147,697; 1,149,523; 1,298,977; 1,624,742 and 1,381,265

Chinese Patents No. 99814931.4; 2002 817086.5; 2004 80037277.6; 2005 10004269.8 and 2007 10135918.7

Japanese Patents No. 4,205,581; 4,237,621; 4,370,058; 4,463,862; 4,486,259 and 4,550,065

Korean Patents No. 646,909 and 796,842

US Patent No. Design 462,694

German Patent No. Design 401 09 691

French Patent No. Design 01 6612

Japanese Patent No. Design 1 146 822

and other intellectual property rights including other patents and pending patent applications related to feeder technology.

AGILIS FLEX

Typical components 0402 to LEDs, large PLCCs

and connectors

Tape widths 8, 12 mm (max 8 pcs)

16, 24 mm (max 5 pcs)

32 mm (max 4 pcs)

44 mm (max 3 pcs)

56, 72 mm (max 2 pcs)

88, 104, 120, 136, 152 mm

(max 1 pcs)

Tape depth 15 mm pockets with

Flex Bin, 22 mm pockets

with LRA (optional)

Tape material Plastic, paper

Reel size 180 mm (7”) to 330 mm

(13”), larger reels on LRA

(optional)

A wide range of snap-in stick positioners available.

Handle short tape clips with the Tape Clip Magazine.

The Generic Feeder Interface available for special applications.

LARGE-REEL ATTACHMENT

The optional large-reel attachment extends your

feeding capability up to 24” tape reels, for tape

widths ranging from 8 mm to 152 mm. Available

for Agilis and Agilis Flex.

STICK POSITIONING

A variety of positioners are available to suit standard

and non-standard components. A positioner axes

a stick in the stick magazine and positions the com-

ponent in the pick-up position. Mycronic can also

custom-design positioners upon request for odd

and unusual components.

TAPE CLIP MAGAZINE

Minimize production costs by using the Tape Clip

Magazine to handle short tape clips. With its width

adjustment capability, dierent combinations of

tape sizes can be ﬁtted alongside each other in the

magazine. The Tape Clip Magazine is available in two

sizes, with a maximum capacity of 5 and 11 pieces of

8 mm tape, respectively.

GENERIC FEEDER INTERFACE

The Generic Feeder Interface (GFI) is just one

example of Mycronic’s customized solutions. The

GFI enables you to connect and run various special

applications as well as third-party feeders from the

magazine slot in a Mycronic machine. More informa-

tion about this possibility is available upon request.
