Error ID ltem Description
800101 Auto Noz. Bypass Started Nozzle down error(L)
800102 Auto Noz. Bypass Started Nozzle down error(H)
800103 Auto Noz. Bypass Started Handling err-cont:
800104 Auto Noz. Bypass Started Decreasing of comp.handling rate
800105 Auto Noz. Bypass Started Selected nozzle position error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
800201 Auto Head Bypass Started Communication error.
800202 Auto Head Bypass Started Head origin error.
800203 Auto Head Bypass Started Overtime head origin error. Set ct:3(fixed value)
800204 Auto Head Bypass Started Unselected nozzle drop. Set ct:2(fixed value)
800205 Auto Head Bypass Started
CAM position.
800206 Auto Head Bypass Started Origin Return Action.
800207 Auto Head Bypass Started Motor Out of Control
800208 Auto Head Bypass Started Current Overload.
800209 Auto Head Bypass Started Motor not connected.
800210 Auto Head Bypass Started Solenoid not connected.
800211 Auto Head Bypass Started Power line warning.
800212 Auto Head Bypass Started Power line error.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0307-004 2-156 AGS01ETRP
Error ID ltem Description
800213 Auto Head Bypass Started Driver temperature warning.
800214 Auto Head Bypass Started Driver temperature error.
800215 Auto Head Bypass Started EEPROM error.
800216 Auto Head Bypass Started Sensor error.
800217 Auto Head Bypass Started Head cam position return action not complete.(Not CAM ORI-
GIN position)
800218 Auto Head Bypass Started Head Driver communication time out.
800219 Auto Head Bypass Started Nozzle change action not complete.(Not CAM ORIGIN posi-
tion)
800220 Auto Head Bypass Started Cam position self-check warning.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
800301 Warning: Decreasing of Comp. Nozzle message rate
Hdlg. Rate(For Noz.)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
800401 Warning: Decreasing of Comp. Feeder message rate
Hdlg. Rate(For Fdr.)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0307-004 2-157 AGS01ETRP
Error ID ltem Description
800501 Alternated Feeder Carriage Axis Comp. Missing(sensor)
800502 Alternated Feeder Carriage Axis Comp. Vertical(sensor)
800503 Alternated Feeder Carriage Axis Comp. Missing(recog.)
800504 Alternated Feeder Carriage Axis Comp. Recog. Error
800505 Alternated Feeder Carriage Axis Shortage of component
800506 Alternated Feeder Carriage Axis Start recovery mode.
800507 Alternated Feeder Carriage Axis Comp. Thickness(sensor)
800508 Alternated Feeder Carriage Axis Comp. Pickup Diff.(recog.)
800509 Alternated Feeder Carriage Axis Comp. Reverse(recog.)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
800601 Alternated Feeder Carriage Axis Comp. Missing(sensor)
800602 Alternated Feeder Carriage Axis Comp. Vertical(sensor)
800603 Alternated Feeder Carriage Axis Comp. Missing(recog.)
800604 Alternated Feeder Carriage Axis Comp. Recog. Error
800605 Alternated Feeder Carriage Axis Shortage of component
800606 Alternated Feeder Carriage Axis Start recovery mode.
800607 Alternated Feeder Carriage Axis Comp. Thickness(sensor)
800608 Alternated Feeder Carriage Axis Comp. Pickup Diff.(recog.)
800609 Alternated Feeder Carriage Axis Comp. Reverse(recog.)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0307-005 2-158 AGS01ETRP
