Installation Manual, Station Software Version 704.01 04/2010 Edition 14 of 60 4.1.3 Embedded software Machine type Subsystem BIOS / A pp lication File name X4I X4 X3 X2 SX1/ SX2 SX4 BIOS AXIALL_0040033F.BHX X X X X Appli…
Installation Manual, Station Software Version 704.01 04/2010 Edition
4 Requirements
4.1 SIPLACE X- and SX-series software components
4.1.1 Station
The station uses one of the following operating system configurations on the machine and Vision
computer(s):
- Microsoft Windows XP Embedded with Service Pack 2
- Microsoft Windows XP Professional (incl. Service Pack 3 and most recent hotfixes)
The machine computer and Vision computer software can optionally be used in one-computer or two-
computer operation.
4.1.2 Machine components
The following versions of other machine components are required for the station software to function
correctly:
SIPLACE station software SIPLACE Vision SIPLACE Pro
Version 704.01 Version 421 Version 8.0
Caution:
The functional statuses of the station computer, Vision computer and SIPLACE Pro software
must be compatible, as specified above. Another configuration is not supported.
13 of 60
Installation Manual, Station Software Version 704.01 04/2010 Edition
14 of 60
4.1.3 Embedded software
Machine type
Subsystem BIOS / Application File name
X4I X4 X3 X2 SX1/
SX2
SX4
BIOS AXIALL_0040033F.BHX X X X X
Application 1 AXIALL_00410338.BHX X X X X
Gantry axes
A364
Application 2 / X, Y AXIALL_00420686.BHX X X X X
BIOS AXIALL_0070000C.BHX X
Application 1 AXIALL_007100A3.BHX X
Gantry axes
not H-gantry
SX-series
Application 2 / X, Y AXIALL_00720686.BHX X
BIOS AXIALL_0080000C.BHX X
Application 1 AXIALL_008100A3.BHX X
Gantry axes
GCU, H-gantry
SX-series
Application 2 / X, Y AXIALL_00820686.BHX X
BIOS AXIALL_0040033F.BHX X X X
Application 1 AXIALL_00410338.BHX X X X
Z- and DP axis
Twin Head
Application 2 / Z, DP AXIALL_00420686.BHX X X X
BIOS AXIALL_0040033F.BHX X X X X
Application 1 AXIALL_00410338.BHX X X X X
Z- and star axis
C&P20A head
Application 2 / star, Z AXIALL_00420686.BHX X X X X
BIOS VHSAXD_00400104.HEX X X X X
DP axis
C&P20A head
Application 1 VHSAXD_00410307.HEX X X X X
BIOS AXIALL_0060000C.BHX X X
Application 1 AXIALL_006100A3.BHX X X
Z- and star axis
HCU
CPP head
Applikation 2 / star, Z AXIALL_00620686.BHX X X
BIOS CPPAXD_00100124.BHX X X X X X X
Application 1 CPPAXD_0011013F.BHX X X X X X X
DP axis
CPP head
Application 2 CPPAXD_00120115.BHX X X X X X X
BIOS WPCAXI_0040033F.BHX X
Application 1 WPCAXI_00410322.BHX X
WPC5 / WPC6
feed axis
Application 2 WPCAXI_00420496.BHX X
BIOS WPCAXI_0040033F.BHX X
Application 1 WPCAXI_00410322.BHX X
WPC5 / WPC6
lift axis
Application 2 WPCAXI_00420496.BHX X
Installation Manual, Station Software Version 704.01 04/2010 Edition
15 of 60
Machine type
Subsystem BIOS / Application File name
X4I X4 X3 X2 SX1/
SX2
SX4
BIOS TWIHED_001003D2.BHX X X X
Twin Head
2 processors
Application 1 TWIHED_0011020A.BHX X X X
BIOS TWIHED_003003D2.BHX X X X
Twin Head
1 processor
Application 1 TWIHED_00310210.BHX X X X
BIOS VHSHED_001003D2.BHX X X X X
C&P20A head
Application 1 VHSHED_00116609.BHX X X X X
BIOS CPPHED_001003D2.BHX X X X X
CPP head
Application 1 CPPHED_00116609.BHX X X X X
BIOS CPPSZD_0100102.BHX X X X X X X
CPP head
Z-bottom
Application CPPSZD_0110104.BHX X X X X X X
BIOS CPPAVA_00000105.BHX X X X X X X
CPP head
valve cluster
Application CPPAVA_00010129.BHX X X X X X X
BIOS
COMTAB_00500200.BHX
COMTAB_00600007.BHX
X
X
X
X
X
X
X
X
Changeover table
(X-table)
Application 1
COMTAB_00510436.BHX
COMTAB_00610127.BHX
X
X
X
X
X
X
X
X
BIOS COMTAB_00800007.BHX X X
Changeover table
SX-series
Application 1 COMTAB_00810127.BHX X X
BIOS TAPCUT_00300102.BHX X X X X
Tape cutter
X-series
Application 1 TAPCUT_0031010B.BHX X X X X
BIOS CONVEY_00600307.HEX X X X X
PCB conveyor
X-series
Application 1 CONVEY_00610744.HEX X X X X
BIOS CONVEY_00700100.BHX X
PCB conveyor
SX1/SX2
Application 1 CONVEY_00710209.BHX X
BIOS CONVEY_00800100.BHX X
PCB conveyor
SX4
Application 1 CONVEY_00810209.BHX X
BIOS IOMODU_00100340.BHX X X X X
Main distributor/
subdistributor
X-series
Application 1 IOMODU_001103C6.BHX X X X X
BIOS IOMODU_00300002.BHX X
Main distributor/
subdistributor
SX1/SX2
Application 1 IOMODU_00310031.BHX
X
