1 15V6C061121 COVER 1 2 KXF077XAA00 EJECTOR ZM131M-J5LZ 1 3 KXF04M4AA00 PLUG Hexagon socket head plug 1/8 2 4 KXF09BAAA00 VALVE SY5120-5MZ-C8-F2 1 5 KXF02CSAA00 JOINT KQP-08 1 6 KXF03U2AA00 TUBE TU0604B(5m) 1 7 KXF08JGAA…

1 15V6C061121 COVER 1

2 KXF077XAA00 EJECTOR ZM131M-J5LZ 1

3 KXF04M4AA00 PLUG Hexagon socket head plug 1/8 2

4 KXF09BAAA00 VALVE SY5120-5MZ-C8-F2 1

5 KXF02CSAA00 JOINT KQP-08 1

6 KXF03U2AA00 TUBE TU0604B(5m) 1

7 KXF08JGAA00 JOINT KQH08-00 1

9 KXF08JHAA00 TUBE TCU0805B-1(1m) 1

10 KXF02T0AA00 JOINT M-5ALU-6 2

11 KXF02BXAA00 JOINT KQL06-01S 1

12 KXF00ZCAA00 SPEED-CONTROLLER AS2201F-01-06S 1

13 KXF00X6AA00 REGULATOR AR1000-M5B-X507 1

15 KXF073PAA00 TUBE TU0805B(5m) 1

16 KXF08JKAA00 JOINT KQS08-01S 1

17 KXF02D4AA00 JOINT KQS06-01S 1

19 KXF0114AA00 REGULATOR AWM2000-02BDG 1

20 KXF02E1AA00 JOINT KQV06-02S 1

21 KXF02T4AA00 JOINT M-5AU-6 1

22 KXF02BFAA00 JOINT KQH12-02S 1

23 15V6C081450 TUBE TU1208B(0.1m) 1

24 KXF03U8AA00 TUBE TU0604BU(1m) 1

番号

ＭＯ機番

ユニット名称

ｸﾘｰﾑ半田自動供給機能:SP22P-M

UNIT NAME

PART NUMBER

品番部品名型式数量ﾗﾝｸ備考

Automatic cream solder supply functio

PART LIST

MODULE NUMBER

パーツリスト

15V6C0M0000

2-C

UNIT NUMBER

ユニットＮｏ.

PART NAME TYPE Q'TY RANK REMARKS

− −10 06 0001−（）
