- 4 -

⑦ Regarding the component verification system (CVS) to check the resistance value,

electrostatic capacity, polarity, etc. of the component before production, a new type is

prepared. It can check a minute component such as a 0402 component, and can check

up to six components at the same time if their size is larger than or equal to that of a 1005

component. This feature shortens the checking time.

High Flexibility

① Program data created with a conventional CX, FX or KE-series mounter can be loaded to

these mounters.

② Combination with the production support system allows you to create a production line

including an existing mounter model and to create a production program for the entire line

with the client side of production support system.

③ An idle transport can be operated at a state of freeing the servomotors for heads and

client X/Y axis.

Operability

① Displaying the graphics in rich facilitated an ease of operating the data inputs

② Key operations can be made easier by using a touch panel.

③ Provided with an option of feeder position indicator (FPI), the stocked components run out

or warns that the number of the remaining components is below the regulated number

with lighting the corresponding LED. This feature indicates which feeder is to be

replaced. (Option)

④ In addition to display the language (English, Japanese and Chinese) the display can be

switched in real time.

⑤ Installing a USB port permits using a memory unit such as USB flash memory.

This allows you to move a production program more easily.

⑥ The database sharing with two or more machines becomes possible by enabling the

external PC to edit the "Component database" that recorded data for the sizes of

components and the vision recognition data.

High Maintainability

① The maintainability has been enhanced by displaying the screens of pick-up frequencies

per nozzle and of X/Y axis traveling distances to call a checking time, in addition to the

hour meter (energized hours).

② Protecting the passwords has hierarchically stratified the maintenance levels to increase

a degree of freedom in setting the machines.

③ A head filter is installed in the upper part of the head to facilitate replacement.

Response to the safety standards

① The machine marked with Europe CE directive is added to the line-up.

Environment and energy saving

① Power consumption has been reduced by 25% by adopting AC servomotor and ball screw

control for the axis control compared with the former machine. The energy efficiency has been

thus improved. (Compared with KE-2080)

- 5 -

3.

System Configuration Table

○: Equipped as standard ●: Option -: No setting

Machine style

KE-3010 KE-3020V KE-3020VR

Basic configuration

Head unit

○

Laser recognition head (LNC60)

○*11

Laser recognition head (LNC61)/Placement monitor

●*1*12

-

Laser recognition head (LNC62)/Placement monitor

-

●*1*12

IC head (CDS)

-

○

-

IC head (FMLA)

-

○

Offset collection camera (OCC L)

○

Offset collection camera (OCC R)

-

○

Height measuring unit (HMS)

○

Bad mark reader (BMR)

●*1

Multi-code reader

●*1

Vision recognition unit

●*1

○

MNVC

●*1 *2

○

Component recognition camera

（

VCS

）

●*1 *2

○

Standard camera

●*1

○

High-resolution camera

●*1

Power supply unit

○

Emergency stop button

○

ATX power supply (with UPS function)

○

Electrical leakage breaker

●*1

I/O control unit

○

Motor control unit

○

X-Y control unit

○

Interior/exterior finish and equipment

○

Signal light (with buzzer)

○

Mini signal light

●*1

Super foot

●*1

Caster

●*1 *3

Pneumatic device piping system

○

Air regulator

○

Vacuum pump

○

Main line filter

-

PWB conveyor unit

○

Placement station

○

Shape reference

○

Pin reference

●*1 *4

Auto PWB width adjustment unit

●*1

L-Wide PWB

●*1 *5

Longer-sized board

●*1

Light for recognizing solder

●*1

Component quantity management

●*1

Operation system

○

Liquid crystal display (with touch panel)

○

Mouse

○

Keyboard

○

SSD

○

LAN port Ethernet

○

USB port

○

Rear-side operation unit

●*1

- 6 -

Machine style

KE-3010 KE-3020V KE-3020VR

HOD

●*1

DVD/CD-ROM drive (USB)

●

FD drive (USB)

●

Equipment device

Feeder float sensor

○

Automatic tool change unit (ATC)

○

Large-shape component scrap box

-

○

Flexible calibration system

（

FCS

）

○

FCS adjustment jig

●

Feeder position indicator (FPI)

●*1

SOT direction inspection table

●*1

Component verification (CVS)

●*1

Coplanarity

●*1 *6

●*1

Ionizer

●*1

Fluxer: Type 2 (To be attached on the main unit)

●*1*13*14

Simplified load control

●*1

Solder print recognition placement position correction

●*1

Bottom view type multi-code reader

●*1

Production support system

Component database

○*7

External programing unit (EPU)

●

Floor productivity operating system

Production support system

・

IS

●

・

IS Lite

●

・

JaNets

●

Production management system

・

IFS-NX

●

White list type anti-virus software

●*1

Feeder bank (Mechanical type)

Mechanical feeder bank (fixed type)

○

Mechanical feeder bank (trolley type)

●*1

Trolley for mechanical feeder

●*1

Intelli trolley(RFID) for mechanical feeder

●*8

Connector bracket

●*1

IC collection belt unit

●

Component supply unit

- Tape feeder/bulk feeder

- Stick feeder / Stacked stick feeder

●

*8

●*8

●

*8

●*8

●

*8

●*8

Tray supply unit

- MTC

*14

- MTS

- DTS

- Tray holder

●*8 *9 ●*8 *9 ●*8 *9

Fluxer: Type 3 (To be attached on a bank/rear side only)

●*1*13

Rotary-type solder transfer device

(To be attached on a bank/front side only)

●*1*13 ●*1*13 ●*1*13

Tape reel mounting base

●

Tape cutter

●

Trash box

●

Wafer supply unit

Multi-die server (DF01)

●*15
