- 46 - (3) T ray feeders N ame Dedicated bank ty pes The number of feeder s available o n the front sid e The number of feeder s available o n the rear si de T otal number of feeder s available The number of slo ts occup…

100%1 / 79
- 45 -
6.2. Maximum Number of Feeders Available on a Mounter
(1) Mechanical feeders
Name
The number of
feeders available
on the front side
The number
of feeders
available on
the rear side
Total number
of feeders
available
The number
of slots
occupied
Mounting
pitch
8 mm tape feeder 40 40 80 (80 types) 2 17.0 mm
12 mm tape feeder
26 26 52 3 25.5 mm
16 mm tape feeder
26 26 52 3 25.5 mm
24 mm tape feeder
20 20 40 4 34.0 mm
32 mm tape feeder
16 16 32 5 42.5 mm
32 mm paper adhesive
tape feeder
16 16 32 5 42.5 mm
44 mm tape feeder 10 10 20 8 68.0 mm
56 mm tape feeder 10 10 20 8 68.0 mm
72 mm tape feeder 8 8 16 10 85.0 mm
Stick feeder type N 26 26 52 3 25.5 mm
Stick feeder type W 13 13 26 6 51.0 mm
Stack stick feeder
(Note 1)
5 ― 5 8 68.0 mm
Bulk feeder
40 ― 40 2 17.0 mm
Note 1: The number of feeders that can be installed on the front side is up to five.
(
2) Electric feeders
Name
The number of
feeders
available on the
front side
The number
of feeders
available on
the rear side
Total number
of feeders
available
The number
of lanes
occupied
(*1)
Mounting
pitch
4 mm tape feeder
40
40
80 (80 types)
1
17.0 mm
8 mm tape feeder
40
40
80 (80 types)
1
17.0 mm
8 mm double lane tape
feeder
(*2)
40 40 80 (160 types) 1 17.0 mm
12 mm tape feeder
40 40 80 1 17.0 mm
16 mm tape feeder
20 20 40 2 34.0 mm
24 mm tape feeder
20 20 40 2 34.0 mm
32 mm tape feeder
13 13 26 3 51.0 mm
44 mm tape feeder
13 13 26 3 51.0 mm
56 mm tape feeder
10 10 20 4 68.0 mm
72 mm tape feeder (*3)
6 6 12 5 85.0 mm
88 mm tape feeder (*3)
5 5 10 6 102.0 mm
Stick feeder type N (*4)
20 20 40 2 34.0 mm
Stick feeder type W (*4)
13 13 26 3 51.0 mm
*1: One lane occupied by electric feeders is mostly equivalent to two slots occupied by mechanical feeders.
*2: To use an 8 mm double lane tape feeder, be sure to use a tape reel attaching platform for electric feeder.
*3: Since five lanes on each side of the bank, left and right are not to be used, the number of lanes shown in
the table above can be used.
*4: Attach the RF_ETF_Attachment when Stick feeders are used by a feeder trolley (RF)
- 46 -
(3) Tray feeders
Name
Dedicated
bank types
The number
of feeders
available on
the front side
The number
of feeders
available on
the rear side
Total number
of feeders
available
The number
of slots
occupied
Tray holder
Full type
Mechanical
bank
― 2 2 42
Electric bank
―
2 2 42
Half type
Mechanical
bank
―
4 4 21
Electric bank
―
4 4 21
DTS（TR1SNR）
Mechanical
bank
―
1(2-sheets) 1(2-sheets) 48
DTS（TR1EB）(Note 4) Electric bank ― 1(2-sheets) 1(2-sheets) 48
MTS (TR5SNX)
Mechanical/
combined bank
― 1(40-stages) 1(40-stages) 80
MTS (TR5DNX) (TR7DN)
Mechanical
combined bank
―
1
(40-stages )
(Note 2)
1(40-stages
(Note 2)
80
MTC (TR6SNV),
(TR6SXLX) (Note 1)
Mechanical/ele
ctric combined
bank
― ―
1(20-stages)
―
MTC (TR6DNV)
(TR6DXLX) (Note 1)
Mechanical/ele
ctric combined
bank
― ―
1(30-stages)
(Note 3)
―
Note 1 : TR6DXLX/6SXLX is dedicated to the XL specification.
Note 2 : 40 sheets of 20 types in the nonstop mode
Note 3 : 30 sheets of 15 types in the nonstop mode
(4) Wafer supply unit
Name
The number of
feeders available
on the front side
The number
of feeders
available on
the rear side
Total number
of feeders
available
The number
of slots
occupied
Multi-die server (DF01) ― 1 (10 stages) 1 (10 stages) 80
See Section 6.8 “Multi-die Server” for details.
- 47 -
6.3. Tape Feeder
6.3.1. Tape feeder for mechanical bank
(1) CTFR
1) List of specifications
Product
code
Tape type
Feeding pitch
Number of
pins
posting
Diameter of
a reel
Typical component
type
Paper Embossed
CF03HPR
○
－
2mm
Two
φ180 mm
0603
CF05HPR
○ －
1005
CF08HER
－ ○
Two-terminal diode
CF081PR
○ －
4m
m
1608, 2012, 3216
CF081ER
－ ○
SOT
CF8L1PR
○ －
φ180 t
o φ380
mm
1608, 2012, 3216
CF8L1ER
－ ○
SOT
CN05HPR
○
－
2mm
One
φ180mm
1005
CN08HER
－
○
Two-terminal diode
CN081CR
○ ○
4m
m
1608, 2012, 3216
CN8L1CR
○ ○
φ180 t
o φ380
mm
1608, 2012, 3216
* For a tape feeder designed for both paper and emboss, contact our sales person.
* The component size and tape specifications conform to JIS C0806-3:1999 and IEC 60286-3:2007.
* The RFID correspondence of the tape feeder is necessary for using the RFID function of the production
management system.
2) Common specifications
1
Outer
dimensions
C*0***R
L=602mm, H=208m, W=16.2mm
C*8L1*R
L=683mm, H=431mm, W=16.5mm
2
Mass
C*0***R
1.2 kg (Excluding a reel)
C*8L1*R
1.9 kg (Excluding a reel)
3
Component transport method
Ratchet drive system
3) O
ptions
① Bar code tag
This tag is used to paste a bar code mark onto the rear edge of a tape feeder.
Even after you install a tape feeder on the feeder bank, the pasted bar code can
be read easily.
② R
FID tag mounting kit
By adding a RFID tag to a CTFR type of tape feeder in use, you can conduct a
feeder management with the production management system.
