SAMSUNG TECHWIN 20 1 AIR CYLINDER 1 C2J016-01-IJ1420 2 AIR CYLINDER Rod 3 J7066173A CYL BLOCK 1 SM1-MF32-013-01 4 J7066171A SPACE CYLINDER 1 SM1-MF32-033-06 5 J7066172A SPACE CYLINDER WASHER 1 SM1-MF32-033-07 6 SHAFT CYL…
SAMSUNG TECHWIN
17
1
J7066154A
STOP PAWL
1
SM1-MF32-004
2
J7066156A
STOP PAWL PIN
1
SM1-MF32-066
18
1
J2500469A PAWL LEVER 1 TF12-150K
18
1
J2500469A PAWL LEVER 1 TF12-150K
2
J7065786A
FORMING BRACKET BUSH
1 TF12-N210
3
J7065788A
GEAR SHAFT-1
1 TF08-103KA
4
J2500448A
PLANET GEAR
1 TF08-100K
5
J1301023
E RING 3
1
6
J6601105A
ONE WAY BEARING
1
HF0406(KFA)
19
1
STOPPER INNER
1
TF12-N218
2
J7065800A
STOPPER OUT RATCHET
1
TF12-N225
3
J7065795A
STOPPER IN PIN 1
2
TF12-N220
4
J7065798A
STOPPER OUT PIN
1 TF12-N223
5
J7065797A
STOPPER IN BUSH
1
TF12-N222
6 STOPPER OUTTER 1 TF12-N219
21
1
J7066319A
T LINK 5
1 SM1-MF32-032
2
J7066320A
SW BLOCK
1 SM1-MF32-059
3
J7066321A
SW BLOCK PIN
2
SM1-MF32-064
24mm SM-1 Tape Feeder Sub Ass'y
NO. PART NO. PART NAME TYPE REMARKQ'TY
Upper I/G Plate Ass'y - (J9065240A)
Reel Stopper Ass'y - (J9065205A)
T Link 5 Ass'y - (J9065297A)
Stop Pawl Rivet Ass'y - (J9065225A)
Upper I/G Plate Ass'y - (J9065240A)
D - 19
SAMSUNG TECHWIN
20
1
AIR CYLINDER
1 C2J016-01-IJ1420
2
AIR CYLINDER Rod
3 J7066173A CYL BLOCK 1 SM1-MF32-013-01
4 J7066171A SPACE CYLINDER 1 SM1-MF32-033-06
5 J7066172A SPACE CYLINDER WASHER 1 SM1-MF32-033-07
6
SHAFT CYLINDER
1
7 J7066314A CYL BLOCK BUSH 1 SM1-MF32-033-05
8
C RING 5
2
9 J7066170A PITCH CONTROL PLATE 1 SM1-MF32-011
10 J7066167A PITCH CONTROL PIN 1 SM1-MF32-046
Cylinder Ass'y - (J9065286A)
24mm SM-1 Tape Feeder Sub Ass'y
NO. PART NO. PART NAME TYPE REMARKQ'TY
D - 20
SAMSUNG TECHWIN
1
J9065235A
TAPE GUIDE 32 S ASS'Y
1
SM1-MF32-019-03
J9065252A
TAPE GUIDE 32 L ASS'Y SM1-MF32-019-03
2
J9065221A
SPROCKET SHAFT 32 ASS'Y
1
SM1-MF32-002
3
J9065222A
PUSHER LEVER RIVET ASS'Y
1
SM1-MF32-007
4
J9065226A
PUSHER LEVER LINK ASS'Y
1 SM1-MF32-007-09
5
J9065244A MAIN LEVER ASS'Y 1 SM1-MF32-033
6
J9065228A LINK MIDDLE RIVET ASS'Y 1 SM1-MF32-007-09
7
J9065242A T LINK 2 ASS'Y 1 SM1-MF32-030
8
J9065227A
SWING LEVER ASS'Y
1 SM1-MF32-008-03
9
J9065241A
VINYL LINK RIVET ASS'Y
1 SM1-MF32-029-01
10
J9065229A
FEEDING SPRING ASS'Y
1 SM1-MF32-074-01
11
J9065245A
REWIND SPRING ASS'Y
1 SM1-MF32-068-01
12
J9065237A VINYL LEVER ASS'Y 1
SM1-MF32-027-01
13
J9065233A
HANDLE LED PCB ASS'Y
1
SM1-MF32-036-01 (IT EXCLUSIVE)
J9065296A
HANDLE LED PCB ASS'Y
1
SM1-MF32-036-01 (NON IT EXCLUSIVE)
14
J9065243A
T LINK 6 ASS'Y
1
SM1-MF32-032-01
15
J9065246A
VINYL SWITEH ASS'Y
1 SM1-MF32-053
16
J9065287A
REEL ARM PLATE RIVET ASS'Y
1
SM1-MF32-015-01
17
J9065225A
STOP PAWL RIVET ASS'Y
1
SM1-MF32-004-01
18
J9065240A
UPPER I/G PLATE ASS'Y
1
SM1-MF32-075-01
19
J9065205A
REEL STOPPER ASS'Y
1 SM1-MF12-213
20
J9065297A
T LINK 5 ASS'Y
1 SM1-MF32-032-02
21
J9065286A
CYLINDER ASS'Y
1 SMS1-MF032-012
22
J9065224A
SPROCKET BLOCK 32 ASS'Y
1
SM1-MF32-003-01
23
J9065223A
SPROCKET BUSH ASS'Y
1 SM1-MF32-002-08
24
J9065219A
PROBER CABLE ASS'Y
1 SM1-MF32-050 (IT EXCLUSIVE)
J9065219A
PROBER CABLE ASS'Y
1 SM1-MF32-050-1(NON IT EXCLUSIVE)
32mm SM Tape Feeder (Front, Rear)
NO. PART NO. PART NAME TYPE REMARKQ'TY
E - 3
