SAMSUNG TECHWIN 55 J7066231A LOCKER SLIDE PIN-2 1 SM1-MF32-025-04 56 J7066277A LOCKER-56 1 SM1-MF56-025 57 J7065310A SPROCKET FIXING SCREW 1 TF44-024 58 J7066135A BALL PLUNGE COVER 1 SM1-MF32-072 59 J7066136A BALL PLUNGE…
SAMSUNG TECHWIN
26
J9065234A
CLAMP SWITEH CABLE ASS'Y
1 SM1-MF32-051
30
J7165303A
MAIN FRAME
1
SM1-MF32-001-01
31
J7066164A
SWING LEVER SHAFT
2
SM1-MF32-008-01
32
J7065978A
INSTALL GUIDE
1
SM1-MF08-040
33
J7066186A
TAPE GUIDE SHAFT
2 SM1-MF32-020
34
J7066137A T LINK STOPPER 4 SM1-MF32-030-06
35
J7066285A TAPE GUIDE MOUNT-56 1 SM1-MF56-021
36
J7065992A BOTTOM LOC PIN 1 SM1-MF08-056
37
J7065944A
V LOC PIN
1 SM1-MF08-002
38
J7065948A
LOCATION FLANGE
1 SM1-MF08-056
39
J7066159A
LIMIT SHAFT
1 SM1-MF32-007-07
40
J7066157A
STOP PAWL SPRING
1 SM1-MF32-005
41
J7066155A
STOP PAWL SPRING PIN
1
SM1-MF32-045
42
J7066158A Y ECCENTRIC PIN 1
SM1-MF32-006
43
J7066211A
T LINK SPRING
1
SM1-MF32-065
44
J7066219A
T LINK 4 SHAFT
1 SM1-MF32-030-08
45
J7066210A
T LINK 1 SHAFT
1
SM1-MF32-030-03
46
J7066208A
T LINK PIN
1
SM1-MF32-030-04
47
J7066169A
PITCH FIXED SCREW
1
SM1-MF32-009-01
48
J7066168A
PITCH SCREW
2 SM1-MF32-060
49
J7066024A
CAUPLING BRACKET-1
1 SM1-MF08-090
50
J7066138A
CABLE COVER
1 SM1-MF32-048
51
J7066291A
MAIN COVER-56
1
SM1-MF56-044
52
J7066140A
LOCKER SPRING
1 SM1-MF32-025-02
53
J7066276A
MAIN BLOCK-56
1 SM1-MF56-043
54
J7066230A
LOCKER SLIDE PIN-1
1
SM1-MF32-025-03
56mm SM Tape Feeder (Front, Rear)
NO. PART NO. PART NAME TYPE REMARKQ'TY
G - 4
SAMSUNG TECHWIN
55
J7066231A
LOCKER SLIDE PIN-2
1
SM1-MF32-025-04
56
J7066277A
LOCKER-56
1 SM1-MF56-025
57
J7065310A
SPROCKET FIXING SCREW
1
TF44-024
58
J7066135A
BALL PLUNGE COVER
1
SM1-MF32-072
59
J7066136A
BALL PLUNGE SPRING
1
SM1-MF32-073
60
J7066134A
BALL PLUNGE PIN
1 SM1-MF32-071
61
J7066289A
GRIP ROLLER-56
1 SM1-MF56-038-01
62
J7066133A CYL BLOCK SPRING PIN 2 SM1-MF32-070
63
J7066292A MAIN COVER-1-56 1 SM1-MF56-044-01
64
J7066288A
VINTL ROLLER-56
1 SM1-MF56-038
65
POTHO SENSOR
1
66
J7066275A
PIN MOUNT-56
3 SM1-MF56-023
67
J7066166A
PITCH FIXED PLATE
1 SM1-MF32-009
68
J7066287A
ROLLER SHAFT-56
2
SM1-MF56-037
69
J7066290A TAPE LOADER-56 1
SM1-MF56-039
70
J7066326A
CABLE COVER-1
1
SM1-MF32-048-01
71
J7165307A
SUB FRAME
1 SM1-MF32-024
72
J7066327A
T LINK 6 SPRING
1
SM1-MF32-065-01
73
MICRO S/W
1
74
J7066182A
PAWL LEVER PIN
3
SM1-MF32-075-02
75
J7066180A
REEL PLATE
1 SM1-MF32-016
76
J7066199A
UPPER I/G PLATE SPRING
1 SM1-MF32-028-06
77
J7066183A
REWIND SPRING PIN
2 SM1-MF32-069
78
J7265171A
PCB COVER
1
SM1-MF32-077
79
PCB BOARD
1
80
J7066316A
STOPPER OUTTER PIN
1 SM1-MF32-014
81
J7066073A
REEL PLATE SHAFT
1
SM1-MF12-134
56mm SM Tape Feeder (Front, Rear)
NO. PART NO. PART NAME TYPE REMARKQ'TY
G - 5
SAMSUNG TECHWIN
82
J7066181A
T LEVER PIN
1 SMS1-MF32-016-03
83
J7065131A
DAMPER
1 TF12-N226
84
J7066317A
DAMPER SHAFT
1
SM1-MF32-035
85
J7066315A
DAMPER WASHER
1
SM1-MF32-034
86
J7066184A
PCB SUPPORT PIN
4
SM1-MF32-042
86
J7066184A
PCB SUPPORT PIN
4 SM1-MF32-042
87
J6711249A COUPLER PLUG 1
KS-4-M5-SA34268KR
88
J7066025A
COUPLER BKT2
1 SM1-MF08-091
90
J1301023 E-RING
5M3
91
J1301149 E-RING
2M4
92
J1301303 E-RING
6M5
93
1301226 C RING
1 M12
94
C RING
1 M17
95
J1301304
HEX NUT 2 M4
96
J6025500050
HEX NUT
2M5
97
J6044400050 STAR WASHER
3
M4
98
PLAIN WASHER
4
M3
99
J6004201050 BUTTON HEAD CAP SCREW
4
M2*10
100
J1301225 SPRING WASHER
3M4
101
J600530065
BUTTON HEAD CAP SCREW
12
M3*6
102
J6006300650 FLAT HEAD CAP SCREW
7
M3*6
103
J6007301238
FLAT HEAD CAP SCREW
3
M3*12
104
J6010300438
SET SCREW
2 M3*5
105
BUTTON HEAD SOCKET SCREW
3 M4*8
106
J1301225
SPRING WASHER
3M4
107
BUTTON HEAD SOCKET SCREW
3
M4*15
56mm SM Tape Feeder (Front, Rear)
NO. PART NO. PART NAME TYPE REMARKQ'TY
G - 6
