SAMSUNG TECHWIN 30 J7165303A MAIN FRAME 1 SM1-MF32-001-01 31 J7066164A SWING LEVER SHAFT 2 SM1-MF32-008-01 32 J7065978A INSTALL GUIDE 1 SM1-MF08-040 33 J7066186A TAPE GUIDE SHAFT 2 SM1-MF32-020 34 J7066137A T LINK STOPPE…
SAMSUNG TECHWIN
1
J9065248A
TAPE GUARD 24 ASS'Y
1
SM1-MF24-019-03
2
J9065247A
SPROCKET SHAFT 24 ASS'Y
1
SM1-MF24-002
3
J9065222A
PUSHER LEVER RIVET ASS'Y
1
SM1-MF32-007
4
J9065226A
PUSHER LEVER LINK ASS'Y
1 SM1-MF32-007-09
5
J9065244A MAIN LEVER ASS'Y 1 SM1-MF32-033
6
J9065228A LINK MIDDLE RIVET ASS'Y 1 SM1-MF32-007-09
7
J9065242A T LINK 2 ASS'Y 1 SM1-MF32-030
8
J9065227A
SWING LEVER ASS'Y
1 SM1-MF32-008-03
9
J9065241A
VINYL LINK RIVET ASS'Y
1 SM1-MF32-029-01
10
J9065229A
FEEDING SPRING ASS'Y
1 SM1-MF32-074-01
11
J9065245A
REWIND SPRING ASS'Y
1 SM1-MF32-068-01
12
J9065237A VINYL LEVER ASS'Y 1
SM1-MF32-027-01
13
J9065233A
HANDLE LED PCB ASS'Y
1
SM1-MF32-036-01 (IT EXCLUSIVE)
J9065296A
HANDLE LED PCB ASS'Y
1
SM1-MF32-036-01 (NON IT EXCLUSIVE)
14
J9065243A
T LINK 6 ASS'Y
1
SM1-MF32-032-01
15
J9065246A
VINYL SWITEH ASS'Y
1 SM1-MF32-053
16
J9065287A
REEL ARM PLATE RIVET ASS'Y
1
SM1-MF32-015-01
17
J9065225A
STOP PAWL RIVET ASS'Y
1
SM1-MF32-004-01
18
J9065240A
UPPER I/G PLATE ASS'Y
1
SM1-MF32-075-01
19
J9065205A
REEL STOPPER ASS'Y
1 SM1-MF12-213
20
J9065297A
T LINK 5 ASS'Y
1 SM1-MF32-032-02
21
J9065286A
CYLINDER ASS'Y
1 SMS1-MF032-012
22
J9065219A
PROBER CABLE ASS'Y
1 SM1-MF32-050 (IT EXCLUSIVE)
J9065219A
PROBER CABLE ASS'Y
1 SM1-MF32-050-1(NON IT EXCLUSIVE)
23
J9065219A
INDEXING SENSOR CABLE ASS'Y
1
SM1-MF32-049
24
J9065234A
CLAMP SWITEH CABLE ASS'Y
1 SM1-MF32-051
24mm SM-1 Tape Feeder (Front, Rear)
NO. PART NO. PART NAME TYPE REMARKQ'TY
D - 3
SAMSUNG TECHWIN
30
J7165303A
MAIN FRAME
1
SM1-MF32-001-01
31
J7066164A
SWING LEVER SHAFT
2
SM1-MF32-008-01
32
J7065978A
INSTALL GUIDE
1
SM1-MF08-040
33
J7066186A
TAPE GUIDE SHAFT
2 SM1-MF32-020
34
J7066137A T LINK STOPPER 4 SM1-MF32-030-06
35
J7066245A TAPE GUIDE MOUNT-24 1 SM1-MF24-021
36
J7065992A BOTTOM LOC PIN 1 SM1-MF08-056
37
J7065944A
V LOC PIN
1 SM1-MF08-002
38
J7065948A
LOCATION FLANGE
1 SM1-MF08-056
39
J7066159A
LIMIT SHAFT
1 SM1-MF32-007-07
40
J7066157A
STOP PAWL SPRING
1 SM1-MF32-005
41
J7066155A
STOP PAWL SPRING PIN
1
SM1-MF32-045
42
J7066158A Y ECCENTRIC PIN 1
SM1-MF32-006
43
J7066211A
T LINK SPRING
1
SM1-MF32-065
44
J7066219A
T LINK 4 SHAFT
1 SM1-MF32-030-08
45
J7066210A
T LINK 1 SHAFT
1
SM1-MF32-030-03
46
J7066208A
T LINK PIN
1
SM1-MF32-030-04
47
J7066169A
PITCH FIXED SCREW
1
SM1-MF32-009-01
48
J7066168A
PITCH SCREW
2 SM1-MF32-060
49
J7066024A
CAUPLING BRACKET-1
1 SM1-MF08-090
50
J7066138A
CABLE COVER
1 SM1-MF32-048
51
J7066251A
MAIN COVER-24
1
SM1-MF24-044
52
J7066140A
LOCKER SPRING
1 SM1-MF32-025-02
53
J7066233A
MAIN BLOCK-24
1 SM1-MF24-043
54
J7066230A
LOCKER SLIDE PIN-1
1
SM1-MF32-025-03
55
J7066231A
LOCKER SLIDE PIN-2
1 SM1-MF32-025-04
56
J7066234A
LOCKER-24
1 SM1-MF24-025
24mm SM-1 Tape Feeder (Front, Rear)
NO. PART NO. PART NAME TYPE REMARKQ'TY
D - 4
SAMSUNG TECHWIN
57
J7066238A
SPROCKET BLOCK-24
1
SM1-MF24-003-01
58
J7066135A
BALL PLUNGE COVER
1
SM1-MF32-072
59
J7066136A
BALL PLUNGE SPRING
1
SM1-MF32-073
60
J7066134A
BALL PLUNGE PIN
1 SM1-MF32-071
61
J7066249A GRIP ROLLER-24 1 SM1-MF24-038-01
62
J7066133A CYL BLOCK SPRING PIN 2 SM1-MF32-070
63
J7066252A MAIN COVER-1-24 1 SM1-MF24-044-01
64
J7066248A
VINTL ROLLER-24
1 SM1-MF24-038
65
POTHO SENSOR
1
66
J7066232A
PIN MOUNT-24
3 SM1-MF24-023
67
J7066166A
PITCH FIXED PLATE
1 SM1-MF32-009
68
J7066247A
ROLLER SHAFT-24
2
SM1-MF24-037
69
J7066250A TAPE LOADER-24 1
SM1-MF24-039
70
J7066326A
CABLE COVER-1
1
SM1-MF32-048-01
71
J7165308A
SUB FRAME-24
1 SM1-MF24-024
72
J7066327A
T LINK 6 SPRING
1
SM1-MF32-065-01
73
MICRO S/W
1
74
J7066182A
PAWL LEVER PIN
3
SM1-MF32-075-02
75
J7066180A
REEL PLATE
1 SM1-MF32-016
76
J7066199A
UPPER I/G PLATE SPRING
1 SM1-MF32-028-06
77
J7066183A
REWIND SPRING PIN
2 SM1-MF32-069
78
J7265171A
PCB COVER
1
SM1-MF32-077
79
PCB BOARD
1
80
J7066316A
STOPPER OUTTER PIN
1 SM1-MF32-014
81
J7066073A
REEL PLATE SHAFT
1
SM1-MF12-134
82
J7066181A
T LEVER PIN
1 SMS1-MF32-016-03
83
J7065131A
DAMPER
1 TF12-N226
24mm SM-1 Tape Feeder (Front, Rear)
NO. PART NO. PART NAME TYPE REMARKQ'TY
D - 5
