SAMSUNG TECHWIN 14 1 J7265158A GRIP 1 SM1-MF08-081 2 J7066209A T LINK 6 1 SM1-MF32-031 3 J7066204A T LINK PIN 1 1 SM1-MF32-030-05 4 FLAT HEAD CAP SCREW M3X10 2 5 J7066197A PLANET LEVER PIN 1 SM1-MF32-031-02 15 1 J7066225…
SAMSUNG TECHWIN
2
J7066221A
REWIND SPRING
1
SM1-MF32-068
12
1
J9065238
VINYL MIDDLE LEVER ASS'Y
1 SM1-MF32-063-01
1-A
J7066196A VINYL MIDDLE LEVER 1 SM1-MF32-063
1-B
J7066197A PLANET LEVER PIN 1 SM1-MF32-031-02
1-C
J9065239A
IDLE GEAR PLATE ASS'Y
1 SM1-MF32-028-07
1-D
J1301023
E RING 3
1
2
J9065236A
VINYL SHAFT 32 RIVET ASSY
1
SM1-MF32-026-03
2-A
J7066194A
VINYL SHAFT BUSH
1
SM1-MF32-026-02
2-B
J7066193A
VINYL SHAFT 32
1
SM1-MF32-026-01
3
FIXED TAKE UP REEL-32 ASS'Y
1
3-A
J7265145A
FIXED TAKE UP REEL-32
1
TF32-N248R
3-B
FIXED TAKE UP REEL BUSH-32
1
4
J1301023
E RING 3
1
TF24-N248A
5
J7066224A
REMO VINYL RING 32
1
SM1-MF32-041-02
6
J7265173A
REMO TAKE UP REEL-24
1
SM1-MF24-041-01
7
C RING 17
1
8
J7165306A CLAMP BUSH 1
SM1-MF32-007-11
9 J7066198A VINYL TENSION SPRING 1 SM1-MF32-028-08
10
J7066195A
VINYL LEVER
1
SM1-MF32-027
13
1
J7165170A
HANDLE
1 SM1-MF32-033-03 (IT EXCLUSIVE)
J7165309A HANDLE 1 SM1-MF32-037 (NON IT EXCLUSIVE)
2
J9065176A
FEEDING SWITCH ASS'Y
1 SM1-MF08-220 (IT EXCLUSIVE)
J9065280A
FEEDING SWITCH ASS'Y
SM1-MF08-231 (NON IT EXCLUSIVE)
3
THD SCREW M3X6 1
Handle LED PCB Ass'y - IT(J9065233A), Non IT(J9065296A)
32mm SM Tape Feeder Sub Ass'y
NO. PART NO. PART NAME TYPE REMARKQ'TY
Vinyl Lever Ass'y - (J9065237A)
E - 17
SAMSUNG TECHWIN
14
1
J7265158A
GRIP
1 SM1-MF08-081
2
J7066209A
T LINK 6
1
SM1-MF32-031
3
J7066204A
T LINK PIN 1
1
SM1-MF32-030-05
4
FLAT HEAD CAP SCREW M3X10 2
5
J7066197A PLANET LEVER PIN 1 SM1-MF32-031-02
15
1
J7066225A
VINYL SW BOTTOM BLOCK
1 SM1-MF32-054
2
J7066227A
VINYL SW PLATE
1 SM1-MF32-056
3
RIMIT S/W
1 SM1-MF32-056
4
J7066226A
VINYL SW BLOCK
1 SM1-MF32-055
5
J7066228A
VINYL SW SHAFT
1
SM1-MF32-057
6
J7066229A VINYL SW LEVER 1
SM1-MF32-058
7
J6010300438
SET SCREW
1
8
J6006300850
FLAT HEAD CAP SCREW M3X8
2
9
J6004201050 BUTTON HEAD CAP SCREW
2
10
HEX NUT 2
16
1
J7066119A
REEL ARM PLATE
1
2
J7066239A
REEL POST-32
1
SM1-MF32-016-04
3
J7066241A
REEL BRAKE-32
1
SM1-MF32-017-01
4
J1301023
E RING 3
5
J7066121A
SPRING PIN 4T
2 SM1-MF12-136
6
FLAT HEAD CAP SCREW
1 M4X8
7
J7066240A
REEL BRAKE-32
1
SM1-MF32-017
8
J9065796A
STOPPER IN PIN2
1 TF12-N221
9
REEL BRACKET SPRING
1
SM1-MF32-017-02
T Link 6 Ass'y - (J9065243A)
Vinyl Switch Ass'y - (J9065246A)
Reel Arm Plate Rivet Ass'y - (J9065287A)
32mm SMTape Feeder Sub Ass'y
NO. PART NO. PART NAME TYPE REMARKQ'TY
E - 18
SAMSUNG TECHWIN
17
1
J7066154A
STOP PAWL
1
SM1-MF32-004
2
J7066156A
STOP PAWL PIN
1
SM1-MF32-066
18
1
J2500469A PAWL LEVER 1 TF12-150K
2
J7065786A
FORMING BRACKET BUSH
1 TF12-N210
3
J7065788A
GEAR SHAFT-1
1 TF08-103KA
4
J2500448A
PLANET GEAR
1 TF08-100K
5
J1301023
E RING 3
1
6
J6601105A
ONE WAY BEARING
1
HF0406(KFA)
19
1
STOPPER INNER
1
TF12-N218
2
J7065800A
STOPPER OUT RATCHET
1
TF12-N225
3
J7065795A
STOPPER IN PIN 1
2
TF12-N220
4
J7065798A
STOPPER OUT PIN
1 TF12-N223
5
J7065797A
STOPPER IN BUSH
1
TF12-N222
6 STOPPER OUTTER 1 TF12-N219
21
1
J7066319A
T LINK 5
1 SM1-MF32-032
2
J7066320A
SW BLOCK
1 SM1-MF32-059
3
J7066321A
SW BLOCK PIN
2
SM1-MF32-064
32mm SM Tape Feeder Sub Ass'y
NO. PART NO. PART NAME TYPE REMARKQ'TY
Upper I/G Plate Ass'y - (J9065240A)
Reel Stopper Ass'y - (J9065205A)
T Link 5 Ass'y - ( )
Stop Pawl Rivet Ass'y - (J9065225A)
E - 19
