SAMSUNG TECHWIN 1 J9065256A TAPE GUIDE 44 S ASS'Y 1 SM1-MF44-019-03 (S EXCLUSIVE) J9065257A TAPE GUIDE 44 L ASS'Y 1 SM1-MF44-019-03 (L EXCLUSIVE) 2 J9065253A SPROCKET SHAFT 44 ASS'Y 1 SM1-MF44-002 3 J90652…
SAMSUNG TECHWIN
20
1
AIR CYLINDER
1 C2J016-01-IJ1420
2
AIR CYLINDER Rod
3 J7066173A CYL BLOCK 1 SM1-MF32-013-01
4 J7066171A SPACE CYLINDER 1 SM1-MF32-033-06
5 J7066172A SPACE CYLINDER WASHER 1 SM1-MF32-033-07
6
SHAFT CYLINDER
1
7 J7066314A CYL BLOCK BUSH 1 SM1-MF32-033-05
8
C RING 5
2
9 J7066170A PITCH CONTROL PLATE 1 SM1-MF32-011
10 J7066167A PITCH CONTROL PIN 1 SM1-MF32-046
22
1
J7066152A
SPROCKET BLOCK 32
1
SM1-MF32-003-01
2
J7066153A
SPROCKET BLOCK BUSH
2
SM1-MF32-003-02
23
1 J7066151A SPROCKET BUSH 1 SM1-MF32-002-03
2
J7066141A SPROCKET-40 1 SM1-MF32-002-07
3
J7066142A
RATCHET-40
1 SM1-MF32-002-01
4
J7066143A
SPROCKET RIVET PIN
3 SM1-MF32-002-06
Sprocket Block 32 Ass'y - (J9065224A)
Sprocket Bush Ass'y - (J9065223A)
32mm SM Tape Feeder Sub Ass'y
NO. PART NO. PART NAME TYPE REMARKQ'TY
Cylinder Ass'y - (J9065286A)
E - 20
SAMSUNG TECHWIN
1
J9065256A
TAPE GUIDE 44 S ASS'Y
1
SM1-MF44-019-03 (S EXCLUSIVE)
J9065257A
TAPE GUIDE 44 L ASS'Y
1
SM1-MF44-019-03 (L EXCLUSIVE)
2
J9065253A
SPROCKET SHAFT 44 ASS'Y
1
SM1-MF44-002
3
J9065222A
PUSHER LEVER RIVET ASS'Y
1
SM1-MF32-007
4
J9065226A
PUSHER LEVER LINK ASS'Y
1 SM1-MF32-007-09
5
J9065244A MAIN LEVER ASS'Y 1 SM1-MF32-033
6
J9065228A LINK MIDDLE RIVET ASS'Y 1 SM1-MF32-007-09
7
J9065242A T LINK 2 ASS'Y 1 SM1-MF32-030
8
J9065227A
SWING LEVER ASS'Y
1 SM1-MF32-008-03
9
J9065241A
VINYL LINK RIVET ASS'Y
1 SM1-MF32-029-01
10
J9065229A
FEEDING SPRING ASS'Y
1 SM1-MF32-074-01
11
J9065245A
REWIND SPRING ASS'Y
1 SM1-MF32-068-01
12
J9065237A VINYL LEVER ASS'Y 1
SM1-MF32-027-01
13
J9065233A
HANDLE LED PCB ASS'Y
1
SM1-MF32-036-01 (IT EXCLUSIVE)
J9065296A
HANDLE LED PCB ASS'Y
1
SM1-MF32-036-01 (NON IT EXCLUSIVE)
14
J9065243A
T LINK 6 ASS'Y
1
SM1-MF32-032-01
15
J9065246A
VINYL SWITEH ASS'Y
1 SM1-MF32-053
16
J9065287A
REEL ARM PLATE RIVET ASS'Y
1
SM1-MF32-015-01
17
J9065225A
STOP PAWL RIVET ASS'Y
1
SM1-MF32-004-01
18
J9065240A
UPPER I/G PLATE ASS'Y
1
SM1-MF32-075-01
19
J9065205A
REEL STOPPER ASS'Y
1 SM1-MF12-213
20
J9065297A
T LINK 5 ASS'Y
1 SM1-MF32-032-02
21
J9065286A
CYLINDER ASS'Y
1 SMS1-MF032-012
22
J9065254A
SPROCKET BLOCK 44 ASS'Y
1
SM1-MF44-003
23
J9065223A
SPROCKET BUSH ASS'Y
1 SM1-MF32-002-08
24
J9065219A
PROBER CABLE ASS'Y
1 SM1-MF32-050 (IT EXCLUSIVE)
J9065219A
PROBER CABLE ASS'Y
1 SM1-MF32-050-1(NON IT EXCLUSIVE)
44mm SM Tape Feeder (Front, Rear)
NO. PART NO. PART NAME TYPE REMARKQ'TY
F - 3
SAMSUNG TECHWIN
25
J9065219A
INDEXING SENSOR CABLE ASS'Y
1
SM1-MF32-049
26
J9065234A
CLAMP SWITEH CABLE ASS'Y
1 SM1-MF32-051
30
J7165303A
MAIN FRAME
1
SM1-MF32-001-01
31
J7066164A
SWING LEVER SHAFT
2
SM1-MF32-008-01
32
J7065978A
INSTALL GUIDE
1
SM1-MF08-040
33
J7066186A
TAPE GUIDE SHAFT
2 SM1-MF32-020
34
J7066137A T LINK STOPPER 4 SM1-MF32-030-06
35
J7066266A TAPE GUIDE MOUNT-44 1 SM1-MF44-021
36
J7065992A BOTTOM LOC PIN 1 SM1-MF08-056
37
J7065944A
V LOC PIN
1 SM1-MF08-002
38
J7065948A
LOCATION FLANGE
1 SM1-MF08-056
39
J7066159A
LIMIT SHAFT
1 SM1-MF32-007-07
40
J7066157A
STOP PAWL SPRING
1 SM1-MF32-005
41
J7066155A
STOP PAWL SPRING PIN
1
SM1-MF32-045
42
J7066158A Y ECCENTRIC PIN 1
SM1-MF32-006
43
J7066211A
T LINK SPRING
1
SM1-MF32-065
44
J7066219A
T LINK 4 SHAFT
1 SM1-MF32-030-08
45
J7066210A
T LINK 1 SHAFT
1
SM1-MF32-030-03
46
J7066208A
T LINK PIN
1
SM1-MF32-030-04
47
J7066169A
PITCH FIXED SCREW
1
SM1-MF32-009-01
48
J7066168A
PITCH SCREW
2 SM1-MF32-060
49
J7066024A
CAUPLING BRACKET-1
1 SM1-MF08-090
50
J7066138A
CABLE COVER
1 SM1-MF32-048
51
J7066272A
MAIN COVER-44
1
SM1-MF44-044
52
J7066140A
LOCKER SPRING
1 SM1-MF32-025-02
53
J7066255A
MAIN BLOCK-44
1 SM1-MF44-043
44mm SM Tape Feeder (Front, Rear)
NO. PART NO. PART NAME TYPE REMARKQ'TY
F - 4
