SAMSUNG TECHWIN 81 J7066073A REEL PLATE SHAFT 1 SM1-MF12-134 82 J7066181A T LEVER PIN 1 SMS1-MF32-016-03 83 J7065131A DAMPER 1 TF12-N226 84 J7066317A DAMPER SHAFT 1 SM1-MF32-035 85 J7066315A DAMPER WASHER 1 SM1-MF32-034 …
SAMSUNG TECHWIN
54
J7066230A
LOCKER SLIDE PIN-1
1
SM1-MF32-025-03
55
J7066231A
LOCKER SLIDE PIN-2
1 SM1-MF32-025-04
56
J7066139A
LOCKER-32
1
SM1-MF32-025
57
J7065310A
SPROCKET FIXING SCREW
1
TF44-024
58
J7066135A
BALL PLUNGE COVER
1
SM1-MF32-072
59
J7066136A
BALL PLUNGE SPRING
1 SM1-MF32-073
60
J7066134A
BALL PLUNGE PIN
1 SM1-MF32-071
61
J7066216A GRIP ROLLER-32 1 SM1-MF32-038-01
62
J7066133A CYL BLOCK SPRING PIN 2 SM1-MF32-070
63
J7066223A
MAIN COVER-1-32
1 SM1-MF32-044-01
64
J7066215A
VINTL ROLLER-32
1 SM1-MF32-038
65
POTHO SENSOR
1
66
J7165304A
PIN MOUNT-32
3 SM1-MF32-023
67
J7066166A
PITCH FIXED PLATE
1
SM1-MF32-009
68
J7066214A ROLLER SHAFT-32 2
SM1-MF32-037
69
J7066218A
TAPE LOADER-32
1
SM1-MF32-039
70
J7066326A
CABLE COVER-1
1 SM1-MF32-048-01
71
J7165307A
SUB FRAME
1
SM1-MF32-024
72
J7066327A
T LINK 6 SPRING
1
SM1-MF32-065-01
73
MICRO S/W
1
74
J7066182A
PAWL LEVER PIN
3 SM1-MF32-075-02
75
J7066180A
REEL PLATE
1 SM1-MF32-016
76
J7066199A
UPPER I/G PLATE SPRING
1 SM1-MF32-028-06
77
J7066183A
REWIND SPRING PIN
2
SM1-MF32-069
78
J7265171A
PCB COVER
1 SM1-MF32-077
79
PCB BOARD
1
80
J7066316A
STOPPER OUTTER PIN
1
SM1-MF32-014
32mm SM Tape Feeder (Front, Rear)
NO. PART NO. PART NAME TYPE REMARKQ'TY
E - 5
SAMSUNG TECHWIN
81
J7066073A
REEL PLATE SHAFT
1 SM1-MF12-134
82
J7066181A
T LEVER PIN
1 SMS1-MF32-016-03
83
J7065131A
DAMPER
1
TF12-N226
84
J7066317A
DAMPER SHAFT
1
SM1-MF32-035
85
J7066315A
DAMPER WASHER
1
SM1-MF32-034
86
J7066184A
PCB SUPPORT PIN
4 SM1-MF32-042
87
J6711249A COUPLER PLUG 1
KS-4-M5-SA34268KR
88
J7066025A
COUPLER BKT2
1 SM1-MF08-091
90
J1301023 E-RING
5M3
91
J1301149 E-RING
2M4
92
J1301303 E-RING
6M5
93
1301226 C RING
1 M12
94
C RING
1 M17
95
J1301304
HEX NUT 2 M4
96
J6025500050
HEX NUT
2M5
97
J6044400050 STAR WASHER
3
M4
98
PLAIN WASHER
4
M3
99
J6004201050 BUTTON HEAD CAP SCREW
4
M2*10
100
J1301225 SPRING WASHER
3M4
101
J600530065
BUTTON HEAD CAP SCREW
12
M3*6
102
J6006300650 FLAT HEAD CAP SCREW
7
M3*6
103
J6007301238
FLAT HEAD CAP SCREW
3
M3*12
104
J6010300438
SET SCREW
2 M3*5
105
BUTTON HEAD SOCKET SCREW
3 M4*8
106
J1301225
SPRING WASHER
3M4
107
BUTTON HEAD SOCKET SCREW
3
M4*15
32mm SM Tape Feeder (Front, Rear)
NO. PART NO. PART NAME TYPE REMARKQ'TY
E - 6
SAMSUNG TECHWIN
108
J6005301550 BUTTON HEAD SOCKET SCREW
3 M3*15
109
BUTTON HEAD SOCKET SCREW
7 M3*10
110
THD SCREW
8
M3*10
111
J6006300850 FLAT HEAD CAP SCREW
10
M3*8
112
FLAT HEAD CAP SCREW
6
M4*8
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
32mm SM Tape Feeder (Front, Rear)
NO. PART NO. PART NAME TYPE REMARKQ'TY
E - 7
