TECHNICAL REFERENCE APPENDIX PREVENTIVE MAINTENANCE 3.114 Appendix to Micron Technical Manuals Chapter Issue 1 June 15 Figure 3-1 1 Camera System Camera Y Linear Bearing Guide (left) Camera Y Linear Bearing Guide (right)…
TECHNICAL REFERENCE APPENDIX
PREVENTIVE MAINTENANCE
Chapter Issue 1 June 15 Appendix to Micron Technical Manuals 3.113
Figure 3-10 Print Carriage
Plan View on Machine
Print Carriage Linear Bearing Guides
TECHNICAL REFERENCE APPENDIX
PREVENTIVE MAINTENANCE
3.114 Appendix to Micron Technical Manuals Chapter Issue 1 June 15
Figure 3-11 Camera System
Camera Y Linear Bearing Guide (left)
Camera Y Linear Bearing Guide (right)
Camera Y Encoder Strip
Camera X Encoder Strip
Camera X Linear Bearing Guide
View on Underside of Camera Mechanism
Camera
Camera Y Magnet Track
Camera X Magnet Track
TECHNICAL REFERENCE APPENDIX
PREVENTIVE MAINTENANCE
Chapter Issue 1 June 15 Appendix to Micron Technical Manuals 3.115
Figure 3-12 Screen Change Mechanism
Screen at Stop Sensor
Auto Drip Tray
Actuator Piston
Auto Drip Tray
Screen Stop
Actuator Arm Lever
