OIS 10.1 / Software Version Description Ausgabe 11/2012 Edition

Contents

1 General 5

1.1 OIS/SIS functionality ......................................................................................... 5

1.1.1 OIS functionality ................................................................................................ 6

1.1.2 SIS functionality ................................................................................................. 6

2 Scope of delivery 7

3 Interfaces for OIS client 8

3.1 Platform 1 machines .......................................................................................... 8

3.2 Platform 2 machines .......................................................................................... 8

3.3 Platform 2+ machines ........................................................................................ 8

3.4 Platform for 70x station software ....................................................................... 9

3.5 Compact Line machines .................................................................................... 9

4 Prerequisites 10

4.1 OIS/SIS functionality ....................................................................................... 10

4.2 OIS Client ........................................................................................................ 10

4.3 Monitoring functionality .................................................................................... 10

5 New functions 11

6 Restrictions 12

7 Installation 14

8 Troubleshooting 15

8.1 Problems and solutions ................................................................................... 15

8.1.1 Problem when installing the Monitoring Service............................................... 15

8.1.2 OIS client with foreign languages needs restart of the machine ....................... 15

8.1.3 Station software 70x sends no operation data to the Monitoring Service ......... 15

OIS 10.1 / Software Version Description Ausgabe 11/2012 Edition

1 General

1.1 OIS/SIS functionality

As of the 7.1 software version, the functionality of the Operator Information System (OIS) and the

Setup Information System (SIS) has been integrated into the Monitoring Service. Additionally, the

Monitoring Service provides OIB related functionality. This additional Monitoring functionality is only

relevant in combination with the OIB Monitoring Adapter.

The public OIS and SIS databases interfaces have not been changed. The tables and views can be

used as before.

Station 1 to n with SC 70x

Station 1 to n

OIS Database

OISBuffer

OISClient

OISBuffer

OIS-Terminal

Operating

Data

MonitoringService.exe

OIS Functionality

SIS Functionality

OISServer.exe

SIS Database

Operation

Data

SIPLACE Pro

(SpiXML adapter)

Figure 1-1: Overview Monitoring Service
