All Bondhus

®

tools are made with Protanium

®

High Torque Steel.

Made in the U.S.A.

Did you know...?

- ProGuard

™

Finish -

Ball End L-Wrenches

10999

10989

• Ball End inserts into a screw at a 25° angle

• Ball End saves time by quickly funneling

tool into screw

• 25° angle allows natural hand and wrist

movement

• Superior Ball End strength and working

angle

• Works in hard to reach places

25° Working

angle

Yellow=Inch

Red=Metric

1

09

9

10946 BLX6M 6 Long 1.5, 2, 2.5, 3, 4, 5mm 1

10992 BLX7M 7 Long 1.5, 2, 2.5, 3, 4, 5, 6mm 1

10999 BLX9M 9 Long 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1

10990 BLX10M 10 Long 1.5, 2, 2.5, 3, 4, 5, 6, 7, 8, 10mm 1

10995 BLX15M 15 Long 1.27, 1.5, 2, 2.5, 3, 3.5, 4, 4.5, 5, 5.5, 6, 7, 8, 9, 10mm 1

10989 MBLX13M 13 Long 1.27, 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10, 12, 14, 17mm 1

(in metal box)

16099 BLX9MXL 9 Extra Long 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1

PART# MODEL# PCS LENGTH CONTENTS QTY LIST

ProGuard

™

ﬁ nish

delivers superior

corrosion protection

Sets

Metric

L-Wrenches

SIZE INCH MM INCH MM PART# QTY LIST EA

1.5 3.5 90 0.53 14 16050 10

2.0 3.9 100 0.61 16 16052 10

2.5 4.4 112 0.69 17 16054 10

3.0 5.0 126 0.75 19 16056 10

4.0 5.6 142 0.87 22 16060 10

5.0 6.3 160 1.06 27 16064 5

6 6.8 172 1.22 31 16068 5

8 7.7 195 1.38 35 16072 5

10 8.4 213 1.54 39 16076 5

Singles

EXTRA

LONG

Metric

SINGLE PACKAGING

PACKAGED

Bondhus’ extremely precise

manufacturing methods

create Ball End tools that

work very well, even in sizes

as small as .050”, 1.27mm,

and T6 (BallStar

™

Tip).

Ball End Tips

SIZE INCH MM INCH MM

1.27 2.8 72 0.53 13 10949 10 12949 100 15749 10

1.5 3.0 77 0.53 14 10950 10 12950 100 15750 10

2.0 3.2 82 0.61 16 10952 10 12952 100 15752 10

2.5 3.5 88 0.69 17 10954 10 12954 100 15754 10

3.0 3.9 98 0.75 19 10956 10 12956 100 15756 10

3.5 3.9 100 0.85 21 10958 1 12958 100 15758 1

4.0 4.3 110 0.87 22 10960 10 12960 100 15760 10

4.5 4.5 114 1.00 25 10962 1 12962 100 15762 1

5.0 4.7 119 1.06 27 10964 5 12964 100 15764 5

5.5 4.9 124 1.14 29 10966 1 12966 50 15766 1

6 5.5 139 1.22 31 10968 5 12968 50 15768 5

7 5.5 140 1.30 33 10970 1 12970 50 15770 1

8 6.0 152 1.38 35 10972 5 12972

50 15772 5

9 6.2 159 1.46 37 10974 1 12974 50 15774 1

10 6.7 171 1.54 39 10976 5 12976 50 15776 5

11 7.9 200 1.63 42 10978 1 12978 25 15778 1

12 8.7 220 1.73 44 10980 1 12980 25 15780 1

13 9.4 240 1.88 48 10982 1 12982 10 15782 1

14 10.2 260 2.15 55 10984 1 12984 10 15784 1

17 11.0 280 2.42 61 10986 1 12986 10 15786 1

19 11.6 295 2.70 69 10988 1 12988 5 15788 1

22 13.0 330 3.07 78 10991 1 - - - -

24 14.5 370 3.47 88 10993 1 - - - -

PART# QTY LIST EA

TAGGED/BARCODED

Singles

LONG

Metric

SINGLE PACKAGING

BULK

PACKAGED

10989

11

All Bondhus

®

tools are made with Protanium

®

High Torque Steel.Made in the U.S.A.

74938 PBLX10 10 Long 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4” 1

74937 PBLX13 13 Long .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1

74992 PBLX7M 7 Long 1.5, 2, 2.5, 3, 4, 5, 6mm 1

74999 PBLX9M 9 Long 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1

PART# MODEL# PCS LENGTH CONTENTS QTY LIST

Inch

Sets

• Holds screw tight on the tool EVERY TIME

• Button is non-magnetic

• Super smooth rotational action, with no

interference from the ProHold

®

button

• Tool strength is not compromised by the

ProHold

®

button

ProGuard

™

ﬁ nish

delivers superior

corrosion protection

74999

Metric

SIZE INCH MM INCH MM

.050 2.8 72 0.53 13 75902 25 75702 5

1/16 3.0 76 0.56 14 75903 25 75703 5

5/64 3.2 81 0.61 15 75904 25 75704 5

3/32 3.4 86 0.65 16 75905 25 75705 5

7/64 3.6 90 0.70 18 75906 25 75706 5

1/8 3.8 95 0.75 19 75907 25 75707 5

9/64 4.0 101 0.80 20 75908 25 75708 5

5/32 4.2 107 0.84 21 75909 25 75709 5

3/16 4.5 114 0.94 24 75910 25 75710 5

7/32 4.9 124 1.03 26 75911 10 75711 2

1/4 5.6 141 1.13 29 75912 10 75712 2

5/16 6.0 152 1.25 32 75913 10 75713 2

3/8 6.8 171 1.38 35 75914 10 75714 2

1.27 2.8 72 0.53 13 75949 25 75749 5

1.5 3.0 77 0.53 14 75950 25 75750 5

2.0 3.2 82 0.61 16 75952 25 75752 5

2.5 3.5 88 0.69 17 75954 25 75754

5

3.0 3.9 98 0.75 19 75956 25 75756 5

4.0 4.3 110 0.87 22 75960 25 75760 5

5.0 4.7 119 1.06 27 75964 25 75764 2

6 5.5 139 1.22 31 75968 10 75768 2

8 6.0 152 1.38 35 75972 10 75772 2

10 6.7 171 1.54 39 75976 10 75776 2

PART# QTY LIST EA

Singles

L-Wrenches

- ProGuard

™

Finish -

ProHold

®

Tip Ball End L-Wrenches

BULK

SINGLE PACKAGING

TAGGED/BARCODED

Yellow=Inch

Red=Metric

LONG

Inch

LONG

Metric

Did you know...?

ProHold

®

buttons are non-

magnetic and work on all

fasteners. They are safe to use

on sensitive equipment. They

will not rust and will hold non-

magnetic screws (aluminum,

stainless and plastic).

ProHold

®

Tip holds

screws securely

ProHold

®

button holds screw

tight on the tool EVERY TIME

ProHold

®

buttons are non-magnetic and

safe for use in electronic applications

12

All Bondhus

®

tools are made with Protanium

®

High Torque Steel.

Made in the U.S.A.

Inch

Sets

Metric

16538 SBLX10 10 Long 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4” 1

16537 SBLX13 13 Long .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1

16592 SBLX7M 7 Long 1.5, 2, 2.5, 3, 4, 5, 6mm 1

16599 SBLX9M 9 Long 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1

PART# MODEL# PCS LENGTH CONTENTS QTY LIST

ProGuard

™

ﬁ nish

delivers superior

corrosion protection

• Fits into tight spaces standard hex keys

cannot

• Eliminates the need to trim and ﬁ le the

short arm

• Tighter inside radius means full smooth

entry into screw head

• Chamfered short arm eliminates burrs

• Ball End inserts into a screw at a 25° angle

Stubby tools ﬁ t in tight spaces where

there is not enough overhead clearance

for a standard hex key

Stubby ﬁ ts

where others

cannot

SIZE INCH MM INCH MM

.050 2.8 72 0.14 4 26502 50 16502 5

1/16 3.0 76 0.16 4 26503 50 16503 5

5/64 3.2 81 0.27 7 26504 50 16504 5

3/32 3.4 86 0.29 7 26505 50 16505 5

7/64 3.6 90 0.30 8 26506 50 16506 5

1/8 3.8 95 0.32 8 26507 50 16507 5

9/64 4.0 101 0.33 8 26508 50 16508 5

5/32 4.2 107 0.35 9 26509 50 16509 5

3/16 4.5 114 0.39 10 26510 50 16510 5

7/32 4.9 124 0.46 12 26511 25 16511 2

1/4 5.6 141 0.46 12 26512 25 16512 2

5/16 6.0 152 0.57 14 26513 25 16513 2

3/8 6.8 171 0.71 18 26514 25 16514 2

1.27 2.8 72 0.14 4 26549 50 16549 5

1.5 3.0 77 0.22 5 26550 50 16550 5

2.0 3.2 82 0.32 7 26552 50 16552 5

2.5 3.5 88 0.35 7 26554 50 16554

5

3.0 3.9 98 0.41 8 26556 50 16556 5

4.0 4.3 110 0.48 9 26560 50 16560 5

5.0 4.7 119 0.57 10 26564 25 16564 2

6 5.5 139 0.68 12 26568 25 16568 2

8 6.0 152 0.85 14 26572 25 16572 2

10 6.7 171 1.15 20 26576 25 16576 2

PART# QTY LIST EA

Singles

L-Wrenches

- ProGuard

™

Finish -

Stubby Ball End L-Wrenches

BULK

SINGLE PACKAGING

TAGGED/BARCODED

Yellow=Inch

Red=Metric

LONG

Inch

LONG

Metric

16599

Ball End Tips
