SIZE INCH MM INCH MM 1/8 3.8 97 1.10 28 88007 1 88707 1 9/64 3.8 97 1.10 28 88008 1 88708 1 5/32 4.2 108 1.20 31 88009 1 88709 1 3/16 4.6 118 1.30 33 88010 1 88710 1 7/32 5.0 128 1.40 36 88011 1 88711 1 1/4 5.4 138 1.60 …
• Fits Inch and Metric Hex, TORX
®
, and
Star screws
• Available in 25 sizes to cover most
fastener heads
• Heat treated high quality industrial
tool steel
• Long handles for extra reach
• Matte chrome fi nish to prevent corrosion
• Lifetime Warranty
Joints are engineered to be
as small as possible without
weakening the tool.
Pivot Head Hex and TORX
®
wrenches allow tool users to insert
wrench into socket head screw one
time, pivoting around obstacles.
Forged hinges provide a simple,
effective, patented design. Fewer
pieces make Pivot Head Hex and
TORX
®
wrenches stronger and less
likely to break than competitors.
Pivot Head Hex and
TORX
®
Wrenches
HexPro
™
Pivot Head Wrenches
The short arm rotates on a hinge
at the end of the long arm and
can be used at any angle from
90° to 270°. This feature makes
