All Bondhus ® tools are made with Protanium ® High T orque Steel. Made in the U .S.A. T -Handles 75146 PBTX60 6 Graduated 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1 75148 PBTX50M 5 Graduated 4, 5, 6, 8, 10mm 1 P ART# MODEL# PCS…
Made in the U.S.A.
35
Inch/
Inch/
Metric
Metric
13146 BTX60 6 Graduated 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
13190* BTX10/S 10 Graduated ✓ 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
13138* BTX10 10 Graduated 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
13148 BTX50M 5 Graduated 4, 5, 6, 8, 10mm 1
13189* BTX80M/S 8 Graduated ✓ 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
13187* BTX80M 8 Graduated 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
13199* BTX9IN/MM 9 Graduated 1/8, 5/32, 3/16, 1/4, 5/16” & 3, 4, 5, 6mm 1
PART# MODEL# PCS LENGTH W/STAND CONTENTS QTY LIST
3/32 6.1 154 3.0 76 13205 Hex* 2 53205 Hex* 2
7/64 6.8 173 3.0 76 13206 Hex* 2 53206 Hex* 2
1/8 7.6 192 3.0 76 13207 Hex* 2 53207 Hex* 2
9/64 8.3 211 3.0 76 13208 Hex* 2 53208 Hex* 2
5/32 9.1 231 3.0 76 13109 2 53109 2
3/16 9.8 250 4.0 102 13110 2 53110 2
7/32 10.3 262 4.0 102 13111 2 53111 2
1/4 10.8 275 4.0 102 13112 2 53112 2
5/16 11.4 289 5.0 127 13113 2 53113 2
3/8 11.8 300 5.0 127 13114 2 53114 2
2.0 5.9 150 3.0 76 13252 Hex* 2 53252 Hex* 2
2.5 6.8 172 3.0 76 13254 Hex* 2 53254 Hex* 2
3.0 7.7 196 3.0 76 13256 Hex* 2 53256 Hex* 2
4.0 8.7 220 3.0 76 13160 2 53160 2
5.0 9.7 246 4.0 102 13164 2 53164 2
6 10.5 266 4.0 102 13168 2 53168 2
8 11.2 285 5.0 127 13172 2 53172
2
10 12.1 307 5.0 127 13176 2 53176 2
SIZE INCH MM INCH MM
PART# QTY LIST EA PART# QTY LIST EA
Inch
Metric
*The 3/32, 7/64, 1/8, and 9/64 inch blades, and the 2, 2.5 and 3mm blades are straight hex blades to prevent breakage.
✓
Comes with stand
*The 3/32, 7/64, 1/8, and 9/64 inch blades, and the 2, 2.5 and 3mm
blades are straight hex blades to prevent breakage.
Singles
Sets
Inch
Metric
ProGuard
™
fi nish
delivers superior
corrosion protection
1319013189
Yellow=Inch
Red=Metric
13190
13189
T-Handles
- ProGuard
™
Finish -
Ball End T-Handles
Molded T-Handle Stands
PART# DESCRIPTION QTY LIST EA
Set stand on bench
or mount on wall.
• Solid steel handles
• Ergonomic handle design
• Flywheel effect saves time
• Smooth, non-porous handle coating
• Handle coating extends along blade
• Ball End inserts into screw at a 25°
angle
• Extremely durable design
• Can be used free standing or wall mounted
• Sizes are clearly marked on stand
• Available in Inch, Metric, or TORX
®
confi gurations
13148
17936 Inch Stand 1
17935 Metric Stand 1
17934 TORX
®
Stand 1
PACKAGED TAGGED/BARCODED
Handles are color
coded for easy
recognition
Ball End Tips
SINGLE PACKAGING
TORX® and TORX PLUS® are registered trademarks of Acument Intellectual Properties, LLC.
All Bondhus
®
tools are made with Protanium
®
High Torque Steel.
All Bondhus
®
tools are made with Protanium
®
High Torque Steel.Made in the U.S.A.
T-Handles
75146 PBTX60 6 Graduated 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
75148 PBTX50M 5 Graduated 4, 5, 6, 8, 10mm 1
PART# MODEL# PCS LENGTH CONTENTS QTY LIST
5/32 9.1 231 3.0 76 75109 2
3/16 9.8 250 4.0 102 75110 2
7/32 10.3 262 4.0 102 75111 2
1/4 10.8 275 4.0 102 75112 2
5/16 11.4 289 5.0 127 75113 2
3/8 11.8 300 5.0 127 75114 2
4.0 8.7 220 3.0 76 75160 2
5.0 9.7 246 4.0 102 75164 2
6 10.5 266 4.0 102 75168 2
8 11.2 285 5.0 127 75172 2
10 12.1 307 5.0 127 75176 2
Inch
Metric
Sets
Inch
Metric
ProGuard
™
fi nish
delivers superior
corrosion protection
- ProGuard
™
Finish -
ProHold
®
Tip Ball End T-Handles
ProHold
®
Tip holds
screws securely
• Holds screw tight on the tool EVERY TIME
• Button is non-magnetic
• Super smooth rotational action, with no
interference from the ProHold
®
button
• Tool strength is not compromised by the
ProHold® button
• Solid steel handles
• Ball End inserts into screw at a 25° angle
75148
Yellow=Inch
Red=Metric
Handles are color
coded for easy
recognition
ProHold
®
button holds screw
tight on the tool EVERY TIME
ProHold
®
buttons are non-magnetic and
safe for use in electronic applications
Singles
SIZE INCH MM INCH MM
PART# QTY LIST EA
PACKAGED
SINGLE PACKAGING
36
All Bondhus
®
tools are made with Protanium
®
High Torque Steel.
Made in the U.S.A.
Inch/
Inch/
Metric
Metric
T-Handles
ProGuard
™
fi nish
delivers superior
corrosion protection
- ProGuard
™
Finish -
Hex End T-Handle Sets
13332 HTX80 8 Graduated 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4” 1
15232 HTX80-6 8 6 inch 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4” 1
15332 HTX80-9 8 9 inch 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4” 1
13390 HTX10/S 10 Graduated ✓ 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
13338 HTX10 10 Graduated 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
15290 HTX10/S-6 10 6 inch ✓ 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
15238 HTX10-6 10 6 inch 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
15390 HTX10/S-9 10 9 inch ✓ 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
15338 HTX10-9 10 9 inch 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
13348 HTX60M 6 Graduated 2, 2.5, 3, 4, 5, 6mm 1
15248 HTX60M-6 6 6 inch 2, 2.5, 3, 4, 5, 6mm 1
15348 HTX60M-9 6 9 inch 2, 2.5, 3, 4, 5, 6mm 1
13389 HTX80M/S 8 Graduated ✓ 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
13387 HTX80M 8 Graduated 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
15289 HTX80M/S-6 8 6 inch ✓ 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
15287 HTX80M-6 8 6 inch 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
15389 HTX80M/S-9 8 9 inch ✓ 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
15387 HTX80M-9 8 9 inch 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
15299 HTX9-6IN/MM 9 6 inch 1/8, 5/32, 3/16, 1/4, 5/16” & 3, 4, 5, 6mm 1
PART# MODEL# PCS LENGTH W/STAND CONTENTS QTY LIST
Inch
Metric
✓
Comes with stand 17936 Inch or 17935 Metric
Sets
• Solid steel handles
• Ergonomic handle design
• Flywheel effect saves time
• Smooth, non-porous handle coating
• Handle coating extends along blade
13348
13390
13389
For singles see page 38
Yellow=Inch
Red=Metric
Handles are color
coded for easy
recognition
Chamfered Hex
Tips fi t tighter and
eliminate burrs
