All Bondhus ® tools are made with Protanium ® High T orque Steel. Made in the U .S.A. 16938 BLX10B 10 Long 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4” 1 16936 BLX12B 12 Long .050, 1/16, 5/64, 3/32, 7/64, 1/…
Made in the U.S.A.
18
TORX® and TORX PLUS® are registered trademarks
of Acument Intellectual Properties, LLC.
All Bondhus
®
tools are made with Protanium
®
High Torque Steel.
48332 HTR8 8 Long 3/32, 1/8, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
48386 HTR6M 6 Long 2.5, 3, 4, 5, 6, 8mm 1
32431 TR-TL7S 7 Long TR7, TR8, TR9, TR10, TR15, TR20, TR25 1
32434 TR-TL8 8 Long TR9, TR10, TR15, TR20, TR25, TR27, TR30, TR40 1
PART# MODEL# PCS LENGTH CONTENTS QTY LIST
PART# MODEL# PCS LENGTH CONTENTS QTY LIST
ProGuard
™
fi nish
delivers superior
corrosion protection
48332
Sets
Sets
Metric
Inch
TORX
®
Singles
Singles
SIZE INCH MM INCH MM
3/32 3.4 86 0.65 16 48305 5
1/8 3.8 95 0.75 19 48307 5
5/32 4.2 107 0.84 21 48309 5
3/16 4.5 114 0.94 24 48310 5
7/32 4.9 124 1.03 26 48311 5
1/4 5.3 133 1.13 29 48312 5
5/16 6.0 152 1.25 32 48313 5
3/8 6.8 171 1.38 35 48314 2
2.5 3.5 88 0.69 17 48354 5
3.0 3.9 98 0.75 19 48356 5
4.0 4.3 110 0.87 22 48360 5
5.0 4.7 119 1.06 27 48364 5
6 5.5 139 1.22 31 48368 5
8 6.0 152 1.38 35 48372 5
10 6.7 171 1.54 39 48376 2
PART# QTY LIST EA
• Fits all tamper resistant hex screws
• Chamfered tool tips eliminate burrs and help tools
seat in screw head
• Sharp corners transfer more torque to the screw and
reduce stripping
• Precision machined for ease of use and superior fi t
L-Wrenches
- ProGuard
™
Finish -
Tamper Resistant Hex End L-Wrenches
LONG
Inch
LONG
TORX
®
LONG
Metric
ProGuard
™
fi nish
delivers superior
corrosion protection
Tools are in color
coded cases for easy
recognition
Green=TORX
®
TR7 2.4 61 0.65 16 33407 25 32407 2
TR8 2.6 67 0.65 16 33408 25 32408 2
TR9 2.9 74 0.65 16 33409 25 32409 2
TR10 3.2 80 0.73 19 33410 25 32410 2
TR15 3.3 84 0.78 20 33415 25 32415 2
TR20 3.6 91 0.78 20 33420 25 32420 2
TR25 3.8 98 0.88 22 33425 25 32425 2
TR27 4.2 106 0.95 24 33427 25 32427 2
TR30 4.6 116 1.03 26 33430 25 32430 2
TR40 4.9 125 1.11 28 33440 25 32440 2
SIZE INCH MM INCH MM
PART# QTY LIST EA
PART# QTY LIST EA
• Fits all TORX
®
and Star tamper resistant screws
• Burr free tool tips help tools seat fully in screw head
• Precision machined tips transfer more torque to the
screw and reduces stripping
- ProGuard
™
Finish -
Tamper Resistant TORX
®
L-Wrenches
BULK
SINGLE PACKAGING
TAGGED/BARCODED
Did y ou know...?
ProGuard
™
Dry Surface
Technology is the world’s best
corrosion protection. The tool
user does not have to work
with rusty tools. ProGuard
™
protection delivers up to 5 times
the corrosion resistance of any
other Hex or TORX
®
tool fi nish.
Tamper Resistant
TORX
®
Tips
Tamper Resistant
TORX
®
Tips
Tamper Resistant
Hex Tips
Tamper Resistant
Hex Tips
PACKAGED
SINGLE PACKAGING
All Bondhus
®
tools are made with Protanium
®
High Torque Steel.
Made in the U.S.A.
16938 BLX10B 10 Long 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4” 1
16936 BLX12B 12 Long .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16” 1
16937 BLX13B 13 Long .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
17046 BLX6MB 6 Extra Long 1.5, 2, 2.5, 3, 4, 5mm 1
17092 BLX7MB 7 Extra Long 1.5, 2, 2.5, 3, 4, 5, 6mm 1
17099 BLX9MB 9 Extra Long 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
17095 BLX15MB 15 Extra Long 1.27, 1.5, 2, 2.5, 3, 3.5, 4, 4.5, 5, 5.5, 6, 7, 8, 9, 10mm 1
16999 BLX9MLB 9 Long 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
PART# MODEL# PCS LENGTH CONTENTS QTY LIST
BriteGuard
™
fi nish
delivers superior
corrosion protection
Sets
Metric
Inch
SIZE INCH MM INCH MM
.050 2.8 72 0.53 13 26902 50 16902 10
1/16 3.0 76 0.56 14 26903 50 16903 10
5/64 3.2 81 0.61 15 26904 50 16904 10
3/32 3.4 86 0.65 16 26905 50 16905 10
7/64 3.6 90 0.70 18 26906 50 16906 10
1/8 3.8 95 0.75 19 26907 50 16907 10
9/64 4.0 101 0.80 20 26908 50 16908 10
5/32 4.2 107 0.84 21 26909 50 16909 10
3/16 4.5 114 0.94 24 26910 50 16910 10
7/32 4.9 124 1.03 26 26911 25 16911 5
1/4 5.6 141 1.13 29 26912 25 16912 5
5/16 6.0 152 1.25 32 26913 25 16913 5
3/8 6.8 171 1.38 35 26914 25 16914 5
7/16 7.5 191 1.50 38 - - 16915 1
1/2 7.8 198 1.63 41 - - 16916 1
9/16 9.0 229 1.75 44 - - 16917 1
5/8 9.8 248 1.88 48 - - 16918 1
3/4
11.3 286 2.13 54 - - 16919 1
1.27 2.8 72 0.53 13 27049 50 17049 10
1.5 3.5 90 0.53 14 27050 50 17050 10
2.0 3.9 100 0.61 16 27052 50 17052 10
2.5 4.4 112 0.69 17 27054 50 17054 10
3.0 5.0 126 0.75 19 27056 50 17056 10
3.5 5.2 133 0.85 21 27058 50 17058 1
4.0 5.6 142 0.87 22 27060 50 17060 10
4.5 5.9 151 1.00 25 27062 50 17062 1
5.0 6.3 160 1.06 27 27064 50 17064 5
5.5 6.8 172 1.14 29 27066 25 17066 1
6 6.8 172 1.22 31 27068 25 17068 5
7 7.2 184 1.30 33 27070 25 17070 1
8 7.7 195 1.38 35 27072 25 17072 5
9 8.0 202 1.46 37 27074 25 17074 1
10 8.4 213 1.54 39 27076 10 17076 5
11 7.9 200 1.63 42 27078 10 17078 1
12 8.7 220 1.73 44
27080 10 17080 1
14 10.2 260 2.15 55 - - 17084 1
17 11.0 280 2.42 61 - - 17086 1
19 11.6 295 2.70 69 - - 17088 1
PART# QTY LIST EA
PART# QTY LIST EA
Singles
• Ball End inserts into a screw at a 25° angle
• Ball End saves time by quickly funneling
tool into screw
• 25° angle allows natural hand and wrist
movement
• Superior Ball End strength and working
angle
• Works in hard to reach places
L-Wrenches
- BriteGuard
™
Finish -
Ball End L-Wrenches
BULK
SINGLE PACKAGING
TAGGED/BARCODED
Yellow=Inch
Red=Metric
LONG
Inch
EXTRA
LONG
Metric
17099
Ball End Tips
Precision shaped ball
Smooth surface
Sharp, clean
corners
25° Working
angle
Did y ou know...?
Bondhus Ball End tools
feature a consistent 25°
working angle. The Ball End
feature saves time and tool
users can absolutely count
on every Bondhus Ball End
tool to provide a 25° working
angle. Period!
19
All Bondhus
®
tools are made with Protanium
®
High Torque Steel.Made in the U.S.A.
16738 SBLX10B 10 Long 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4” 1
16737 SBLX13B 13 Long .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
16792 SBLX7MB 7 Extra 1.5, 2, 2.5, 3, 4, 5, 6mm 1
Long
16799 SBLX9MB 9 Extra 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
Long
PART# MODEL# PCS LENGTH CONTENTS QTY LIST
BriteGuard
™
fi nish
delivers superior
corrosion protection
16799
Sets
Metric
Inch
Singles
SIZE INCH MM INCH MM
.050 2.8 72 0.14 4 26702 50 16702 5
1/16 3.0 76 0.16 4 26703 50 16703 5
5/64 3.2 81 0.27 7 26704 50 16704 5
3/32 3.4 86 0.29 7 26705 50 16705 5
7/64 3.6 90 0.30 8 26706 50 16706 5
1/8 3.8 95 0.32 8 26707 50 16707 5
9/64 4.0 101 0.33 8 26708 50 16708 5
5/32 4.2 107 0.35 9 26709 50 16709 5
3/16 4.5 114 0.39 10 26710 50 16710 5
7/32 4.9 124 0.46 12 26711 25 16711 2
1/4 5.6 141 0.46 12 26712 25 16712 2
5/16 6.0 152 0.57 14 26713 25 16713 2
3/8 6.8 171 0.71 18 26714 25 16714 2
1.27 2.7 69 0.14 4 26749 50 16749 5
1.5 3.5 90 0.19 5 26750 50 16750 5
2.0 3.9 100 0.27 7 26752 50 16752 5
2.5 4.4 112 0.28 7 26754 50 16754
5
3.0 5.0 126 0.32 8 26756 50 16756 5
4.0 5.6 142 0.35 9 26760 50 16760 5
5.0 6.3 160 0.40 10 26764 25 16764 2
6 6.8 172 0.47 12 26768 25 16768 2
8 7.7 195 0.57 14 26772 25 16772 2
10 8.4 213 0.78 20 26776 25 16776 2
PART# QTY LIST EA
PART# QTY LIST EA
Stubby fi ts
where others
cannot
L-Wrenches
- BriteGuard
™
Finish -
Stubby Ball End L-Wrenches
BULK
TAGGED/BARCODED
Yellow=Inch
Red=Metric
LONG
Inch
EXTRA
LONG
Metric
SINGLE PACKAGING
Did y ou know...?
Stubby tools have a tighter
inside radius than standard hex
keys, which saves time because
the tight radius design reaches
screws that even a hex key with
a cut down short arm cannot.
Ball End Tips
.050" Ball End Comparison
Bondhus:
Precision machined
Competitor:
Poorly machined
• Fits into tight spaces standard hex keys
cannot
• Eliminates the need to trim and fi le the
short arm
• Tighter inside radius means full smooth
entry into screw head
• Chamfered short arm eliminates burrs
• Ball End inserts into a screw at a 25° angle
