All Bondhus ® tools are made with Protanium ® High T orque Steel. Made in the U .S.A. 11640 BRX4 4 SQ0, SQ1, SQ2, SQ3 1 P ART# MODEL# PCS CONTENTS QTY LIST SQ0 3.5 90 7.0 178 11600 2 SQ1 3.8 95 7.2 183 11601 2 SQ2 4.0 10…

Tamper Resistant

TORX

Tips

Made in the U.S.A.

33831 TR-SX7S 7 TR7, TR8, TR9, TR10, TR15, TR20, TR25 1

33834 TR-SX8 8 TR9, TR10, TR15, TR20, TR25, TR27, TR30, TR40 1

PART# MODEL# PCS CONTENTS QTY LIST

- ProGuard

™

Finish -

BallStar

™

Tip Screwdrivers

Screwdrivers

- ProGuard

™

Finish -

Tamper Resistant TORX

Screwdrivers

• Fits all TORX

and Star screws

• Ball End inserts into a screw at a 20° angle

• Ball End saves time by quickly funneling

tool into screw

• Superior Ball End strength and working

angle

• Works in hard to reach places

ProGuard

™

ﬁ nish

delivers superior

corrosion protection

BallStar

™

Tips

• Fits all TORX

and Star tamper resistant screws

• Burr free tool tips help tools seat fully in screw head

• Precision machined tips transfer more torque to the

screw and reduces stripping

Did you know...?

BallStar

™

tools work at a 20°

angle; screws can be turned

continuously without constantly

taking the tool out of the screw,

repositioning it and reinserting

it, even at angles up to 20°.

Handles are color

coded for easy

recognition

Green=TORX

Handles are color

coded for easy

recognition

Green=TORX

13546 STX6 6 T6, T7, T8, T9, T10, T15 1

13532 STX8 8 T9, T10, T15, T20, T25, T27, T30, T40 1

T6 2.6 65 4.7 119 12706 2

T7 2.6 65 4.7 119 12707 2

T8 2.6 65 5.0 126 12708 2

T9 2.6 65 5.0 126 12709 2

T10 2.8 70 5.2 132 12710 2

T15 2.9 73 6.4 161 12715 2

T20 3.2 81 7.5 191 12720 2

T25 3.4 87 7.7 197 12725 2

T27 3.8 97 8.7 220 12727 2

T30 4.2 106 9.0 229 12730 2

T40 4.6 117 9.4 240 12740 2

T45 5.2 132 10.0 255 12745 1

T50 6.0 153 10.9 276 12750 1

T55 6.8 172 11.6 295 12755 1

TR7 4.5 114 6.7 169 33807 1

TR8 4.8 121 7.2 182 33808 1

TR9 4.9 124 7.3 186 33809 1

TR10 5.0 128 7.4 189 33810 1

TR15 5.1 131 8.6 219 33815 1

TR20 5.4 138 9.8 248 33820 1

TR25 5.7 144 10.0 253 33825 1

TR27 5.8 147 10.6 270 33827 1

TR30 6.0 153 10.9 276 33830 1

TR40 6.3 159 11.1 282 33840 1

PART# QTY LIST EA

SIZE INCH MM INCH MM

BALL

STAR

™

Sets

TORX

BALL

STAR

™

TORX

Singles

PACKAGED

SINGLE PACKAGING

Did y ou know...?

Bondhus’ ergonomic handle

design greatly reduces fatigue

associated with repetitive tasks

and the application of torque.

TORX® and TORX PLUS® are registered trademarks of Acument Intellectual Properties, LLC.

All Bondhus

tools are made with Protanium

High Torque Steel.

ProGuard

™

ﬁ nish

delivers superior

corrosion protection

All Bondhus

tools are made with Protanium

High Torque Steel.Made in the U.S.A.

11640 BRX4 4 SQ0, SQ1, SQ2, SQ3 1

PART# MODEL# PCS CONTENTS QTY LIST

SQ0 3.5 90 7.0 178 11600 2

SQ1 3.8 95 7.2 183 11601 2

SQ2 4.0 102 8.3 212 11602 2

SQ3 4.0 102 8.3 212 11603 2

SQ4 4.5 115 8.8 225 11604 2

PART# QTY LIST EA

SIZE INCH MM INCH MM

Set

Singles

• Ball End inserts into a screw at a 25° angle

• Ball End saves time by quickly funneling

tool into screw

• Two component handle with tough inner

core and cushioned rubber exterior

• Non-slip grip

• Anti-roll design

- ProGuard

™

Finish -

Square Ball End Screwdrivers

ProGuard

™

ﬁ nish

delivers superior

corrosion protection

Square

Ball Tips

PACKAGED

Screwdrivers

Ergonomic handle

design

SINGLE PACKAGING

For Ball End and Hex Tip L-Wrenches

About the Bondhex

™

Case

18032 .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32” 10

18036 .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16” 10

18037 .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 10

18038 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4” 10

18045 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16” 10

18046 1.5, 2, 2.5, 3, 4, 5mm 10

18099 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 10

PART# FITS SIZES QTY LIST

18037

Metric

Inch

• Provides a convenient means of keeping L-Wrenches

neat and organized

• Sizes are printed on the case for quick tool selection

• Case can be used in conjunction with the tool to

increase torque

Bondhex

™

Cases

Bondhus Ball End and Hex key sets are packed in a color-coded Bondhex

™

case to keep tools neat and sorted. A simple 60 degree turn locks keys in place

to eliminate loose, spilled and lost keys. Tool sizes are clearly printed beneath

each tool for quick size selection. A Bondhex

™

case can also be used with a

hex key to increase grip and comfortably generate additional torque.

Most Bondhus L-Wrench sets come standard with our Bondhex

™

case.

Yellow=Inch

Red=Metric

18099

48445 BNX7 7 3/16, 1/4, 5/16, 11/32, 3/8, 7/16, 1/2” 1

48492 BNX7M 7 6, 7, 8, 9, 10, 11, 12mm 1

48496 BNX7ML 7 6, 7, 8, 9, 10, 11, 13mm 1

PART# MODEL# PCS CONTENTS QTY LIST

PART# QTY LIST EA PART# QTY LIST EA

SIZE INCH MM INCH MM

Inch

Metric

Sets

Singles

Hollow Shaft Nut Drivers

Nut Drivers

• Hexagonal upper shaft for use with a wrench for

increased torque

• Ergonomic handle design

• Non-slip grip

• Anti-roll handle

• High strength chrome plated shaft

5/32 3 76 7.3 186 38409 1 48409 1

3/16 3 76 7.3 186 38410 1 48410 1

7/32 3 76 7.3 186 38411 1 48411 1

1/4 3 76 7.3 186 38412 1 48412 1

9/32 3 76 7.3 186 38432 1 48432 1

5/16 3 76 7.3 186 38413 1 48413 1

11/32 3 76 7.3 186 38435 1 48435 1

3/8 3 76 7.3 186 38414 1 48414 1

7/16 3 76 7.3 186 38415 1 48415 1

1/2 3 76 7.3 186 38416 1 48416 1

4.0 3 76 7.3 186 38460 1 48460 1

5.0 3 76 7.3 186 38464 1 48464 1

5.5 3 76 7.3 186 38466 1 48466 1

6 3 76 7.3 186 38468 1 48468 1

7 3 76 7.3 186

38470 1 48470 1

8 3 76 7.3 186 38472 1 48472 1

9 3 76 7.3 186 38474 1 48474 1

10 3 76 7.3 186 38476 1 48476 1

11 3 76 7.3 186 38478 1 48478 1

12 3 76 7.3 186 38480 1 48480 1

13 3 76 7.3 186 38482 1 48482 1

48492

PACKAGED TAGGED/BARCODED

Yellow=Inch

Red=Metric

Handles are color

coded for easy

recognition

SINGLE PACKAGING

Assembled in the US from globally sourced components.
