Made in the U .S.A. 35 Inch/ Inch/ Metric Metric 13146 BTX60 6 Graduated 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1 13190* BTX10/S 10 Graduated ✓ 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1 13138* BTX10 10 Gradua…
Up to 20% stronger, with more torque and twice the wear
resistance of standard grades of steel.
High Torque Steel:
FINISH OPTIONS:
Environmentally safe, provides better tool grip, resists
solvents and is 5 times more corrosion resistant than
competitor finishes.
Corrosion-resistant finish:
Bondhus T-Handles are built to be
comfortable, strong and durable. The
form-fi tting handle fi ts the curve of
the user’s hand.
• Cushioned, curved handle
increases comfort and reduces
fatigue
• Handles are designed to match
torque capacity of blade
A Better T-Handle
T-Handles
Visit us online at www.bondhus.com for more information on Bondhus products Made in the U.S.A.
•
C
ushi
o
increa
s
f
atigu
e
•
Handl
e
torque
The Bondhus T-Handle is curved to
match the shape of the hand. This
design is ergonomically superior to
old fashioned straight handles.
Bondhus is the only company to
engineer our handles to match the
blade’s torque capacity. Tool user’s
can always feel confident in their
tool’s strength.
The Bondhus solid steel handle is
heavy duty and generates a flywheel
effect for super fast insertion and
removal of screws.
Color-Coded
Inch
Metric
TORX
®
TORX® and TORX PLUS® are trademarks
of Acument Intellectual Properties, LLC.
34
Made in the U.S.A.
35
Inch/
Inch/
Metric
Metric
13146 BTX60 6 Graduated 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
13190* BTX10/S 10 Graduated ✓ 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
13138* BTX10 10 Graduated 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
13148 BTX50M 5 Graduated 4, 5, 6, 8, 10mm 1
13189* BTX80M/S 8 Graduated ✓ 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
13187* BTX80M 8 Graduated 2, 2.5, 3, 4, 5, 6, 8, 10mm 1
13199* BTX9IN/MM 9 Graduated 1/8, 5/32, 3/16, 1/4, 5/16” & 3, 4, 5, 6mm 1
PART# MODEL# PCS LENGTH W/STAND CONTENTS QTY LIST
3/32 6.1 154 3.0 76 13205 Hex* 2 53205 Hex* 2
7/64 6.8 173 3.0 76 13206 Hex* 2 53206 Hex* 2
1/8 7.6 192 3.0 76 13207 Hex* 2 53207 Hex* 2
9/64 8.3 211 3.0 76 13208 Hex* 2 53208 Hex* 2
5/32 9.1 231 3.0 76 13109 2 53109 2
3/16 9.8 250 4.0 102 13110 2 53110 2
7/32 10.3 262 4.0 102 13111 2 53111 2
1/4 10.8 275 4.0 102 13112 2 53112 2
5/16 11.4 289 5.0 127 13113 2 53113 2
3/8 11.8 300 5.0 127 13114 2 53114 2
2.0 5.9 150 3.0 76 13252 Hex* 2 53252 Hex* 2
2.5 6.8 172 3.0 76 13254 Hex* 2 53254 Hex* 2
3.0 7.7 196 3.0 76 13256 Hex* 2 53256 Hex* 2
4.0 8.7 220 3.0 76 13160 2 53160 2
5.0 9.7 246 4.0 102 13164 2 53164 2
6 10.5 266 4.0 102 13168 2 53168 2
8 11.2 285 5.0 127 13172 2 53172
2
10 12.1 307 5.0 127 13176 2 53176 2
SIZE INCH MM INCH MM
PART# QTY LIST EA PART# QTY LIST EA
Inch
Metric
*The 3/32, 7/64, 1/8, and 9/64 inch blades, and the 2, 2.5 and 3mm blades are straight hex blades to prevent breakage.
✓
Comes with stand
*The 3/32, 7/64, 1/8, and 9/64 inch blades, and the 2, 2.5 and 3mm
blades are straight hex blades to prevent breakage.
Singles
Sets
Inch
Metric
ProGuard
™
fi nish
delivers superior
corrosion protection
1319013189
Yellow=Inch
Red=Metric
13190
13189
T-Handles
- ProGuard
™
Finish -
Ball End T-Handles
Molded T-Handle Stands
PART# DESCRIPTION QTY LIST EA
Set stand on bench
or mount on wall.
• Solid steel handles
• Ergonomic handle design
• Flywheel effect saves time
• Smooth, non-porous handle coating
• Handle coating extends along blade
• Ball End inserts into screw at a 25°
angle
• Extremely durable design
• Can be used free standing or wall mounted
• Sizes are clearly marked on stand
• Available in Inch, Metric, or TORX
®
confi gurations
13148
17936 Inch Stand 1
17935 Metric Stand 1
17934 TORX
®
Stand 1
PACKAGED TAGGED/BARCODED
Handles are color
coded for easy
recognition
Ball End Tips
SINGLE PACKAGING
TORX® and TORX PLUS® are registered trademarks of Acument Intellectual Properties, LLC.
All Bondhus
®
tools are made with Protanium
®
High Torque Steel.
All Bondhus
®
tools are made with Protanium
®
High Torque Steel.Made in the U.S.A.
T-Handles
75146 PBTX60 6 Graduated 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1
75148 PBTX50M 5 Graduated 4, 5, 6, 8, 10mm 1
PART# MODEL# PCS LENGTH CONTENTS QTY LIST
5/32 9.1 231 3.0 76 75109 2
3/16 9.8 250 4.0 102 75110 2
7/32 10.3 262 4.0 102 75111 2
1/4 10.8 275 4.0 102 75112 2
5/16 11.4 289 5.0 127 75113 2
3/8 11.8 300 5.0 127 75114 2
4.0 8.7 220 3.0 76 75160 2
5.0 9.7 246 4.0 102 75164 2
6 10.5 266 4.0 102 75168 2
8 11.2 285 5.0 127 75172 2
10 12.1 307 5.0 127 75176 2
Inch
Metric
Sets
Inch
Metric
ProGuard
™
fi nish
delivers superior
corrosion protection
- ProGuard
™
Finish -
ProHold
®
Tip Ball End T-Handles
ProHold
®
Tip holds
screws securely
• Holds screw tight on the tool EVERY TIME
• Button is non-magnetic
• Super smooth rotational action, with no
interference from the ProHold
®
button
• Tool strength is not compromised by the
ProHold® button
• Solid steel handles
• Ball End inserts into screw at a 25° angle
75148
Yellow=Inch
Red=Metric
Handles are color
coded for easy
recognition
ProHold
®
button holds screw
tight on the tool EVERY TIME
ProHold
®
buttons are non-magnetic and
safe for use in electronic applications
Singles
SIZE INCH MM INCH MM
PART# QTY LIST EA
PACKAGED
SINGLE PACKAGING
