VLT® Local Control Panel
LCP 601
Everything you can do with the
VLT® Soft Starter MCD 600 controls
is also possible via the
VLT® Local Control Panel LCP 601
Select a screen view set-up from one
user-programmable and 7 standard
views.
Language selection
English, Chinese, German, Spanish,
Portuguese, French, Italian, Russian.
The LCP 601 is connected to the
MCD 600 by using a 3 m cable using a
9-pin (D-sub) plug and 3 m cable
provided with the IP65 (NEMA 12)
door-mount kit.
Once connected, the soft starter asks
whether you want to copy parameters
from LCP to starter or starter to LCP
(if different).
100% easy connection
• The Modbus, PROFIBUS, EtherNet/IP
and DeviceNet modules use another
port on the MCD 600, located at the
side of the soft starter
• Separate LCP 601 output at the
bottom for 9 pin plug and 3 m cable
• One ordering number (LCP with
door-mount kit and cable)
• Plug & play connection, even when
the soft starter is powered up
• One cable for power and
communication
• Powered up by soft starter
• Copy of parameter set-up
Current rating
[A]
Weight
[kg]
Height
[mm]
Width
[mm]
Depth
[mm]
Enclosure
size
20 - 42 4.8
336 152 231 S163 - 69 4.9
86 - 128 5.5
144 - 215 12.7 495
216 243 S2244 - 448 15.5
523
527 - 579 19.0
590 - 736 51.0
618 447 310 S3839 - 979 62.0
1134 - 1250 65.0
Dimensions
Fieldbus communication
modules:
Starting
• AAC Adaptive Acceleration
• EtherNet/IP
• PROFINET
• Modbus TCP
• PROFIBUS
• DeviceNet
• Modbus RTU
• Remote LCP Option
• Application card
• Smart Pump
• PC software:
• WinStart
• VLT® Motion Control Tool MCT 10
0
10%
20%
30%
40%
50%
Time
60%
70%
80%
90%
100%
Speed
700%
600%
500%
300%
100%
400%
200%
10% 20% 30% 40% 50%
Rotor speed (% full speed)
60% 70% 80% 90% 1
00%
Current (% motor full load current)
Three Adaptive Acceleration Control (AAC) start
profiles; early, constant and late acceleration
Constant current/ current ramp – shown here
with kickstart
AD437153353153en-010301 > VLT® Soft Starter
11
Feature Benefit
Small footprint and compact size – Saves panel space
Built-in bypass
– Minimizes installation cost and
eliminates power loss
– Reduces heat build up. Savings in
components, cooling, wiring and labor
Advanced accessories –
Allows enhanced functionality
Advanced SCR control algorithms
balance output waveform
–
Allows more starts per hour,
at higher load
Reliable Maximum up-time
Essential motor protection (MCD 202) – Reduces overall project investment
Max. ambient temperature 60
°C
without derating
– No external cooling or oversizing necessary
User friendly Save commissioning
Easy to install and use
Easy DIN rail mounting for sizes up to 30 kW – Saves time and space
VLT® Compact Starter MCD 200
VLT® Compact Starter MCD 200 series from Danfoss
includes two soft starters in the power range 7.5-110 kW.
The series offers easy DIN rail mounting
for sizes up to 30 kW, 2-wire or 3-wire
start/stop control and excellent
starting duty (4 x Ie for 6 seconds).
Heavy starting ratings at 4x Ie
for 20 seconds.
Compatible with grounded delta
power systems.
Power range
7.5 – 110 kW
Remote operation
The dedicated remote operator
kit facilitates remote operation of
VLT® Compact Starter MCD 201 and
VLT® Compact Starter MCD 202 .
The operator (IP54/NEMA 12) is
mounted on the cabinet front and
allows remote control, status indication
and motor monitoring of an individual
VLT® Compact Starter using RS485
serial communication.
MCD 201
MCD 202
MCD 202 provides enhanced soft start functionality
and various motor protection features
M
3~
Ramp up
Initial torque
Ramp
down
U
M
3~
Ramp up
Initial current
Current
limit
I
Ramp
down
U
Power range (400 V) 7-30 kW 37-55 kW 75-110 kW
Height [mm] 203 215 240
Width [mm] 98 145 202
Depth [mm] 165 193 214
Dimensions
AD437153353153en-010301 > VLT® Soft Starter 12
Feature Benefit
Small footprint and compact size – Saves panel space
Selection can be based on motor power –
Easy selection
Universal control voltage
– Simplifies selection
– Keeps stock at a minimum
“Fit and forget” contactor design
– Simplifies installation
– Reduces required panel space
Reliable Maximum up-time
Robust semiconductor design – Reliable operation
Almost unlimited number of starts
per hour without derating
– Prevents unauthorized changes
Max. ambient temperature 50
°C
without derating
– No external cooling or oversizing necessary
User friendly Save commissioning
Easy to install and use – Saves times
Digitally controlled rotary switches – Secures precise settings and simplifies installation
Easy DIN rail mounting for sizes up to 30 kW – Saves time and space
Eltwin SMC Soft Starter
The Eltwin SMC soft starter is a cost-
effective and extremely compact soft
starter for AC motors up to 11 kW, due
to a unique semiconductor design.
For more details, visit
https://www.eltwin.com/solutions/ic-contactors/smc-3-dol
Power range 1.5 kW 7.5 kW 11 kW
Height [mm] 102 110 110
Width [mm] 22.5 45 90
Depth [mm] 123.5 128.1 128
Dimensions
