Internally Bypassed
MCD 600
Normal Duty Heavy Duty
3.5 x FLC, 30s, 40 °C 4.5 x FLC, 30s, 40 °C
Current Motor Power [HP] Current Motor Power [HP]
Amps 230 V 460 V 575 V Amps 230 V 460 V 575 V
MCD6-0020B 14 3 10 10 14 3 10 10
MCD6-0034B 30 10 20 25 24 7.5 15 20
MCD6-0042B 38 10 25 30 29 10 20 25
MCD6-0063B 54 20 40 50 42 15 30 40
MCD6-0069B 68 25 50 60 50 15 30 40
MCD6-0086B 70 25 50 60 54 20 40 50
MCD6-0108B 88 30 60 75 68 25 50 60
MCD6-0129B 105 40 75 100 82 30 60 75
MCD6-0144B 125 40 100 125 96 30 75 75
MCD6-0171B 144 50 100 150 112 40 75 100
MCD6-0194B 164 60 125 150 130 50 100 125
MCD6-0244B 212 75 150 200 164 60 125 150
MCD6-0287B 248 100 200 250 192 75 150 200
MCD6-0323B 278 100 200 250 216 75 150 200
MCD6-0410B 404 150 300 400 314 125 250 300
MCD6-0527B 448 150 350 450 348 125 250 350
MCD6-0579B 495 200 400 500 385 150 300 400
MCD6-0654B 565 200 450 550 440 150 350 450
MCD6-0736B 638 250 500 600 496 200 400 500
MCD6-0950B 864 350 700 900 664 250 500 600
MCD6-1154B 1055 400 850 1000 843 350 700 800
MCD6-1250B 1249 500 1000 1300 971 400 800 1000
Continous Operation (no internal bypass)
MCD 600
Normal Duty Heavy Duty
3.5 x FLC, 30s, 40 °C, 50% Duty Cycle 4.5 x FLC, 30s, 40 °C, 50% Duty Cycle
Current Motor Power [HP] Current Motor Power [HP]
Amps 230 V 460 V 575 V Amps 230 V 460 V 575 V
MCD6-0160C 159 60 125 150 130 50 100 125
MCD6-0215C 198 75 150 200 161 60 125 150
MCD6-0275C 250 100 200 250 198 75 150 200
MCD6-0343C 331 125 250 300 266 100 200 250
MCD6-0448C 414 150 350 450 377 150 300 350
MCD6-0590C 535 200 450 500 421 150 350 450
MCD6-0667C 605 250 500 600 480 200 400 500
MCD6-0839C 775 300 600 800 618 250 500 600
MCD6-0979C 920 350 700 850 740 300 600 700
MCD6-1134C 1044 450 800 1000 864 350 700 900
Externally Bypassed
MCD 600
Normal Duty Heavy Duty
3.5 x FLC, 30s, 40 °C 4.5 x FLC, 30s, 40 °C
Current Motor Power [HP] Current Motor Power [HP]
Amps 230 V 460 V 575 V Amps 230 V 460 V 575 V
MCD6-0590C 621 250 500 600 483 200 400 500
MCD6-0667C 699 250 550 700 544 200 450 500
MCD6-0839C 960 400 800 1000 735 300 600 700
MCD6-0979C 1180 500 950 1200 916 350 700 900
MCD6-1134C 1403 550 1150 1400 1091 500 900 1100
NEMA - 3 Wire Connection (In-line) - 40°C
For different operating conditions use WinSTART rating software
AD437153353153en-010301 > VLT® Soft Starter 22
Internally Bypassed
MCD 600
Normal Duty Heavy Duty
3.5 x FLC, 30s, 50 °C 4.5 x FLC, 30s, 50 °C
Current Motor Power [HP] Current Motor Power [HP]
Amps 230 V 460 V 575 V Amps 230 V 460 V 575 V
MCD6-0020B 17 5 10 15 14 3 10 10
MCD6-0034B 28 10 20 25 22 7.5 15 20
MCD6-0042B 34 10 25 30 28 10 20 25
MCD6-0063B 52 15 30 40 40 10 25 30
MCD6-0069B 58 20 40 50 45 15 30 40
MCD6-0086B 77 25 50 60 52 15 40 50
MCD6-0108B 81 30 60 75 65 20 50 60
MCD6-0129B 99 30 75 100 77 25 60 75
MCD6-0144B 124 40 75 100 96 30 60 75
MCD6-0171B 130 50 100 125 104 40 75 100
MCD6-0194B 156 60 125 150 124 40 100 100
MCD6-0244B 194 75 150 200 156 60 125 150
MCD6-0287B 240 75 150 200 180 60 150 150
MCD6-0323B 260 100 200 250 202 75 150 200
MCD6-0410B 377 150 300 350 302 100 250 300
MCD6-0527B 414 150 350 450 319 125 250 300
MCD6-0579B 477 200 400 500 361 150 300 350
MCD6-0654B 515 200 450 500 414 150 350 450
MCD6-0736B 590 200 500 600 480 200 400 500
MCD6-0950B 796 300 600 800 619 250 500 600
MCD6-1154B 984 400 800 1000 768 300 600 800
MCD6-1250B 1130 450 900 1100 903 350 700 900
Continous Operation (no internal bypass)
MCD 600
Normal Duty Heavy Duty
3.5 x FLC, 30s, 50 °C, 50% Duty Cycle 4.5 x FLC, 30s, 50 °C, 50% Duty Cycle
Current Motor Power [HP] Current Motor Power [HP]
Amps 230 V 460 V 575 V Amps 230 V 460 V 575 V
MCD6-0160C 146 50 100 150 118 40 75 100
MCD6-0215C 176 60 125 150 144 50 100 150
MCD6-0275C 233 75 150 200 185 60 150 150
MCD6-0343C 306 100 250 300 246 75 200 250
MCD6-0448C 354 125 250 350 336 125 250 350
MCD6-0590C 480 200 400 500 382 150 300 400
MCD6-0667C 576 200 450 600 431 150 350 450
MCD6-0839C 722 300 600 700 590 200 500 600
MCD6-0979C 864 350 700 900 722 300 600 700
MCD6-1134C 966 400 800 1000 784 300 600 800
Externally Bypassed
MCD 600
Normal Duty Heavy Duty
3.5 x FLC, 30s, 50 °C 4.5 x FLC, 30s, 50 °C
Current Motor Power [HP] Current Motor Power [HP]
Amps 230 V 460 V 575 V Amps 230 V 460 V 575 V
MCD6-0590C 551 200 450 500 429 230 V 350 450
MCD6-0667C 634 250 500 600 493 150 400 500
MCD6-0839C 882 350 700 900 686 200 500 700
MCD6-0979C 1100 450 900 1100 864 250 700 900
MCD6-1134C 1320 500 1100 1300 1030 350 800 1000
NEMA - 3 Wire Connection (In-line) - 50°C
For different operating conditions use WinSTART rating software
AD437153353153en-010301 > VLT® Soft Starter
23
Internally Bypassed
MCD 600
Normal Duty Heavy Duty
3.5 x FLC, 30s, 40 °C 4.5 x FLC, 30s, 40 °C
Current Motor Power [HP] Current Motor Power [HP]
Amps 230 V 460 V 575 V Amps 230 V 460 V 575 V
MCD6-0020B 21 5 15 15 21 5 15 15
MCD6-0034B 45 15 30 40 36 10 25 30
MCD6-0042B 57 20 40 50 44 15 30 40
MCD6-0063B 81 30 60 75 63 20 40 60
MCD6-0069B 102 30 75 100 75 25 50 60
MCD6-0086B 105 40 75 100 81 30 60 75
MCD6-0108B 132 50 100 125 102 30 75 100
MCD6-0129B 158 60 125 150 123 40 75 100
MCD6-0144B 188 60 150 150 144 50 100 150
MCD6-0171B 216 75 150 200 168 60 125 150
MCD6-0194B 246 75 200 250 195 75 150 200
MCD6-0244B 318 125 250 300 246 75 200 250
MCD6-0287B 372 150 300 350 288 100 200 300
MCD6-0323B 417 150 350 450 324 125 250 300
MCD6-0410B 606 250 500 600 471 150 350 500
MCD6-0527B 672 250 550 700 522 200 450 550
MCD6-0579B 743 300 600 750 578 200 450 600
MCD6-0654B 848 350 700 800 660 250 500 650
MCD6-0736B 957 400 800 1000 744 300 600 700
MCD6-0950B 1296 500 1000 1300 996 400 800 1000
MCD6-1154B 1583 600 1300 1500 1265 500 1000 1300
MCD6-1250B 1874 700 1500 1700 1457 600 1200 1500
Continous Operation (no internal bypass)
MCD 600
Normal Duty Heavy Duty
3.5 x FLC, 30s, 40 °C, 50% Duty Cycle 4.5 x FLC, 30s, 40 °C, 50% Duty Cycle
Current Motor Power [HP] Current Motor Power [HP]
Amps 230 V 460 V 575 V Amps 230 V 460 V 575 V
MCD6-0160C 242 75 200 250 192 75 150 200
MCD6-0215C 302 100 250 300 242 75 200 250
MCD6-0275C 375 150 300 350 302 100 250 300
MCD6-0343C 497 200 400 500 399 150 300 400
MCD6-0448C 612 250 500 600 566 200 450 500
MCD6-0590C 803 300 600 800 632 250 500 600
MCD6-0667C 908 350 700 900 720 250 600 700
MCD6-0839C 1163 450 900 1200 927 350 700 900
MCD6-0979C 1380 500 1100 1400 1110 450 900 1100
MCD6-1134C 1566 600 1300 1500 1296 500 1000 1300
Externally Bypassed
MCD 600
Normal Duty Heavy Duty
3.5 x FLC, 30s, 40 °C 4.5 x FLC, 30s, 40 °C
Current Motor Power [HP] Current Motor Power [HP]
Amps 230 V 460 V 575 V Amps 230 V 460 V 575 V
MCD6-0590C 932 350 700 900 725 300 600 700
MCD6-0667C 1056 450 800 1100 816 300 600 800
MCD6-0839C 1444 550 1100 1500 1103 400 900 1100
MCD6-0979C 1767 700 1400 1600 1374 500 1100 1400
MCD6-1134C 2105 800 1500 1900 1637 600 1300 1500
NEMA - 6 Wire Connection (Inside Delta) - 40°C
For different operating conditions use WinSTART rating software
AD437153353153en-010301 > VLT® Soft Starter 24
