Soft starter application guide:
Find the right product for your application
AD437153353153en-010301 > VLT® Soft Starter
7
Speed control Initial cost
AC drive
(VSD)
Soft starter
(SST)
Direct-on-line
(DOL)
Continuous
speed control
Start/stop
CAPEX OPEX
VSD
SST
DOL
SST
DOL
VSD
Step 2. Match your application, motor, and controls
If you selected an AC drive (VSD), read more about Danfoss
drives on drives.danfoss.com.
If you selected a soft starter, then read on.
Direct-on-line (DOL) drawbacks
• Wear on motor bearings
• Wear and tear on gearbox
• Water hammer
Select the size of the soft starter to
match both the motor and the
application.
1. Use the soft starter guide on p6 as a
starting point
2. Match the soft starter current rating
with motor full load current rating,
see p8
Soft starter motor and control guide
- select a soft starter to match
Select a soft starter that has a current
rating at least equal to the motor’s full
load current rating (see motor
nameplate) at the application start
duty (Light, Standard, heavy)
Soft starter current rating
The current rating of the soft starter
determines the maximum motor size it
is compatible with.
The current rating of the soft starter
depends on:
• The number of starts per hour
• The duration and current level of each
start
• The duration of time the soft starter is
turned off (not passing current)
between starts
Soft starter start performance
For Eltwin SMC, find information on
start performance here
For MCD 200, find information on start
performance in the Design Guide.
Find it here.
For MCD 600
• Refer to the Design Guide for
information on start performance in
different load situations
• Alternatively use the designer tool
“Winstart for MCD 600” to tailor the
selection to optimize your application.
Download Winstart for MCD 600 on
www.danfoss.com.
Interaction with controls
Designing your application also
includes interaction with controls.
The basic soft starters, Eltwin SMC and
MCD 201, depend on other
components for warning and alarms.
MCD 202 is able to signal overload,
either via digital I/O or fieldbus options.
Step 1. Determine what kind of speed control you need
Consider first, whether start/stop control or continuous speed control is required.
Then consider the scale of both initial investment and running costs.
Soft starter application guide:
Find the right product for your application
AD437153353153en-010301 > VLT® Soft Starter 8
Step 3. Match your needs
Find the right match between your application and the soft starter features you need.
• Eltwin SMC Soft Starter
• VLT® Compact Starter MCD 201 or 202
• VLT® Soft Starter MCD 600
Eltwin SMC MCD 201 MCD 202 MCD 600
Power size
0.1-15 kW (3-25 A) 7-110 kW (17-200 A) 7-110 kW (17-200 A) 7.5 - 1400 kW (20-1250 A)
Voltage range
3 x 400 - 480 VAC, 45-66 Hz 3 x 200 - 575 VAC, 45-66 Hz 3 x 200 - 575 VAC, 45-66 Hz 3 x 200 - 690 VAC, 45-66 Hz
Start/ Stop mode
Timed voltage ramp Timed voltage ramp
Timed voltage ramp
Current-controlled ramp
Current-controlled ramp
Adaptive-controlled ramp
Protection
None (external components) None (external components) 7 features 19 features
Inputs
1 DI 1 DI 2 DI 4 DI
Outputs
0 0 2 DO 3 DO/ 1 AO
Control
2-wire control
3 rotary switches
2-3 wire control
3 rotary switches
Remote operator
2-3 wire control
8 rotary switches
Remote operator
2-wire control
Built-in graphical display
Remote graphical display
Integrated functions
- - -
Reverse control
Pump Clean / deragging
Power Through
and many more
Options
None PROFIBUS, PROFINET, EtherNet/IP, Modbus TCP
1]
1]
For full details see Options, page 26.
Serial communication
Eltwin SMC MCD 201 MCD 202 MCD 600
Start/stop, reset
· · · ·
LED for start, run, trip
· · · ·
Trip codes
· · · ·
Current display
· ·
Motor temperature display
· ·
4 – 20 mA output
·
Programming keypad, graphical display
·
MCD 600 includes a full warning and
alarm handling system to interface
controls either via digital I/O or fieldbus
options: serial- or Ethernet-based such
as PROFINET or EtherNet/IP. Check the
specifications for more details.
VLT® Compact Starter MCD 201 and
202, and VLT® Soft Starter MCD 600
come with optional plug-in modules
for serial communication.
• DeviceNet
• EtherNet/IP
• PROFIBUS
• Modbus RTU
• USB
AD437153353153en-010301 > VLT® Soft Starter
9
