VL T® Compact Star ter MCD 200 Or der ing type code [1] [2] [3] [4] MCD 2 0 – – T – C V [1 ] Se ries 1 Sof t star t / stop 2 Soft star t/stop + protection [2] Nomin al moto r kW, 400 V 055 E.g. 55 kW 110 110 kW [3] Line …
VLT® Compact Starter MCD 201 VLT® Compact Starter MCD 202
Type
n
A physically compact starter providing basic soft start
and stop functionality
n Physically similar to MCD 201 but providing enhanced soft start func-
tionality and various motor protection functions
Concept
n
Soft start
n Soft stop
n 7.5-110 kW @ 400 V
n 200-575 V mains voltage
n 110-440 V AC or 24 V AC/DC control supply
n 2-phase SCR control
n Current limit start
n Soft stop
n Motor protection
n 7.5-110 kW @ 400 V
n 200-575 V mains voltage
n 110-440 V AC or 24 V AC/DC control supply
n 2-phase SCR control
Start/stop
n
Timed voltage ramp-up
n Adjustable initial torque
n Current limit start
n Initial current ramp-up
n
Timed voltage ramp-down n Timed voltage ramp-down
Protection
n
Motor overload (adjustable trip class)
n Excess start time
n Reverse phase rotation
n Motor thermistor input
n Shorted SCR – no start
n Supply fault – no start
n Instantaneous overload
Output
n
One output relay:
Line contactor control
n Two output relays:
– Line contactor control
– Run contactor or trip function
Control
n
Two- or three-wire control
Programmable via 3 rotary switches
Reset push button
Optional
n Modules for serial communication
n Remote operator kit
n PC software
n Two- or three-wire control
n Programmable via 8 rotary switches
n Reset push button
Optional
n Modules for serial communication
n Remote operator kit
n PC software
Other features
n
Integral SCR bypass for minimum physical size and
heat dissipation during nominal operation
n LED status indication
n IP20 (7.5 – 55 kW @ 400 V)
n IP00 (75 – 110 kW @ 400 V)
n Protection kit available
n Integral SCR bypass for minimum physical size and
heat dissipation during nominal operation
n LED status indication
n IP20 (7.5 – 55 kW @ 400 V)
n IP00 (75 – 110 kW @ 400 V)
n Protection kit available
Approvals
n UL
n C – UL
n CE
n CCC
n C-tick
n Lloyds
n UL
n C – UL
n CE
n CCC
n C-tick
n Lloyds
AD437153353153en-010301 > VLT® Soft Starter
15
VLT® Compact Starter MCD 200
Ordering type code
[1] [2] [3] [4]
MCD 2 0 – – T – C V
[1] Series
1 Soft start/stop
2 Soft start/stop + protection
[2] Nominal motor kW, 400 V
055 E.g. 55 kW
110 110 kW
[3] Line supply voltage
4 200-440 V
6 200-575 V
[4] Control supply voltage
1 24 V AC/DC
3 110-240 V AC and 380-440 V AC
[1] [2] [3] [4] [5] [6]
MCD 6 – – – T – G X – – C V
[4] Enclosure S1
[1] FLC
[A]
[2] Bypass
[5] Protection
rating
0020 B IP20
0034 B IP20
0042 B IP20
0063 B IP20
0069 B IP20
0086 B IP20
0108 B IP20
0129 B IP20
[4] Enclosure S2
[1] FLC
[A]
[2] Bypass
[5] Protection
rating
0144 B IP00
0171 B IP00
0194 B IP00
0244 B IP00
0287 B IP00
0323 B IP00
0410 B IP00
0527 B IP00
0579 B IP00
0160 C IP00
0215 C IP00
0275 C IP00
0343 C IP00
0448 C IP00
[4] Enclosure S3
[1] FLC
[A]
[2] Bypass
[5] Protection
rating
0654 B IP00
0736 B IP00
0950 B IP00
1154 B IP00
1250 B IP00
0590 C IP00
0667 C IP00
0839 C IP00
0979 C IP00
1134 C IP00
[6] Control voltage
1 24 V AC or 24 V DC
2 110 or 230 V AC
[5] Protection rating
00 IP00
20 IP20
[4] Enclosures
S1 Enclosure size 1
S2 Enclosure size 2
S3 Enclosure size 3
[3] Supply voltage
5 200 - 525 V AC
7 380 - 690 V AC
[2 Supply voltage
B With internal bypass contactor
C No internal bypass contactor (continuous)
[4] Enclosures
[1] Fixed Load Current (FLC) -
see tables below
VLT® Soft Starter MCD 600
AD437153353153en-010301 > VLT® Soft Starter 16
VLT® Compact Starter
MCD 201/MCD 202
Eltwin SMC Soft Starter
Power size
[kW]
Rated current
AC-53b* [A]
7.5 18 A: 4-6: 354
15 34 A: 4-6: 354
18 42 A: 4-6: 354
22 48 A: 4-6: 354
30 60 A: 4-6: 354
37 75 A: 4-6: 594
45 85 A: 4-6: 594
55 100 A: 4-6: 594
75 140 A: 4-6: 594
90 170 A: 4-6: 594
110 200 A: 4-6: 594
*
Example: AC 53b: 42 A: 4-6: 354 starting current
max. 4 times FLC (42 A)
in 6 seconds. 354 seconds minimum between
starts.
Electrical data
For electrical data, refer to
Eltwin SMC online
