28 OSC package The licensed OSC pack age contains functions for simpli- fied placement of odd shaped com ponents (O SC), such as connectors or sock- ets. The license is activate d via SIPLACE PRO. For detailed informatio…

SIPLACE Vision

Barcode types

Technical data

1D barcodes

QR codes

Code types Code 39

Code 93

Code 128

EAN-8 (AddOn 2, AddOn 5), EAN-13 (AddOn 2, AddOn 5)

Interleaved 2 of 5 (station software version 709.1 or higher required)

Minimum width of bar 5 pixels

If the quality of the mark is sufficient, the width can be reduced down to 3

pixels.

Minimum height of symbol 5% of length of whole symbol.

Symbol angle All symbol angles will be accepted.

Inverse symbols Light bars on a dark background will be accepted.

Mirrored symbols Mirrored symbols will be accepted.

(this corresponds to a rotation of 180 degrees for 1D codes)

Region of Interest (ROI) The area on the board, in which the barcode is searched for (ROI), should

not exceed the following values:

ROI (direction of reading)

≤ 3 * symbol width

ROI (vertical to direction of reading)

≤ 10 * symbol width

Code type QR code in accordance with ISO/IEC 18004 model 2.

Station software version 711.0 or higher required

No. rows/columns All versions still defined in the standard (i.e. number of rows/columns) are

accepted.

Minimum dot size 5 pixels.

Symbol angle All symbol angles will be accepted.

Inverse symbols Inverse symbols (light modules on a dark background) will be accepted.

Mirrored symbols Mirrored symbols will be accepted.

Ratio of column width to row

height

1/2

≤ (column width) / (row height) ≤ 2

Region of Interest (ROI) The area in which the barcode is searched for (ROI) should not exceed the

following values:

Width of ROI

≤ 6 * width of barcode symbol

Height of ROI

≤ 6 * Height of barcode symbol

OSC package

The licensed OSC package

contains functions for simpli-

fied placement of odd

shaped components (OSC),

such as connectors or sock-

ets.

The license is activated via

SIPLACE PRO.

For detailed information,

refer to the OSC package

user guide, item number

[00198374-xx].

The following functions are

contained in the OSC pack-

age:

OSC measurement options

• Customized odd shaped

component

This enables the user to

describe any abstract pat-

tern on a component e.g.

connection leads of a tri-

angular shape. This pat-

tern can then be easily

created and edited at the

station, using the wizard

function.

• Stereo measurement

Stereo measurement

means that two images

are taken of each compo-

nent, from different direc-

tions, using a stationary

camera. These images

are overlapped to show

connectors, pins etc. in 3D

to support easy and pre-

cise evaluation of struc-

tures which, due to color,

shading or background

structures, are difficult to

recognize in conventional

2D measurement.

• Special position evalua-

tion

This function supports

separate definition of posi-

tion-determining features

(x,y, angle) independent

of the features for good-

bad recognition.

Placement of snap-in com-

ponents

This function monitors

whether snap-in components

engage in the board prop-

erly, during automatic place-

ment.

Automatic calculation of

optimum acceleration

This function enables the

user to automatically calcu-

late the optimum accelera-

tion of individual axes for a

component at the station.

The acceleration values

found can then be checked in

an additional test run and

sent back to the program-

ming system if successful.

Pin in paste height check

This option extends the

"snap-in" function for CPP

heads.

Additional force levels for

CPP head

• 15 N for CPP

ASM Software Products

Overview

Workflows ASM Software Product Standard Option

Planning

ASM production planner

Fully automatic product grouping and optimization by taking deliv-

ery deadlines into account

SIPLACE SiCluster Professional / SiCluster Multiline

Fully automatic product grouping

Virtual production

SIPLACE Pro

One application for all programming tasks

SIPLACE LED Pairing

Simple placement of LEDs with multiple classes

Production

SIPLACE station software

Diverse operating system

ASM OIS

Operator Information System

ASM Command Center

Automatic operator management for all machine assistants

Material Management

ASM material manager

Control and optimization of SMD material management

ASM Line Monitor

Overview of material consumption in the lines.

Preparation

ASM Setup Center

Avoid setup errors with reliable setup verification

SIPLACE Material Setup Assistant

Optimization of offline setup preparation and of material flow

Factory monitoring

ASM EDM

Convenient data management for placement programs

ASM Traceability

Traceability of the placement processes

SIPLACE Explorer

Line monitoring system

ASM Performance Monitoring

Live KPI monitoring

Factory Integration

ASM OIB

Seamless integration of SIPLACE software solutions with third

party systems

ASM Remote Smart Factory

Professional remote service infrastructure
