30 Technical data Electrical ratings, energy consumption and compressed air supply Electrical ratings Supply voltage Main power supply 3 x 380 V~ to 3 x 415 V~ ± 10 %; 50/60 Hz 3 x 200 V~ to 3 x 220 V~ ± 10 % ; 50/60 Hz …
29
ASM Software Products
Overview
Workflows ASM Software Product Standard Option
Planning
ASM production planner
Fully automatic product grouping and optimization by taking deliv-
ery deadlines into account
X
SIPLACE SiCluster Professional / SiCluster Multiline
Fully automatic product grouping
X
Virtual production
SIPLACE Pro
One application for all programming tasks
X
SIPLACE LED Pairing
Simple placement of LEDs with multiple classes
X
Production
SIPLACE station software
Diverse operating system
X
ASM OIS
Operator Information System
X
ASM Command Center
Automatic operator management for all machine assistants
X
Material Management
ASM material manager
Control and optimization of SMD material management
X
ASM Line Monitor
Overview of material consumption in the lines.
X
Preparation
ASM Setup Center
Avoid setup errors with reliable setup verification
X
SIPLACE Material Setup Assistant
Optimization of offline setup preparation and of material flow
X
Factory monitoring
ASM EDM
Convenient data management for placement programs
X
ASM Traceability
Traceability of the placement processes
X
SIPLACE Explorer
Line monitoring system
X
ASM Performance Monitoring
Live KPI monitoring
X
Factory Integration
ASM OIB
Seamless integration of SIPLACE software solutions with third
party systems
X
ASM Remote Smart Factory
Professional remote service infrastructure
X
30
Technical data
Electrical ratings, energy consumption and
compressed air supply
Electrical ratings
Supply voltage
Main power supply 3 x 380 V~ to 3 x 415 V~ ± 10 %; 50/60 Hz
3 x 200 V~ to 3 x 220 V~ ± 10 %; 50/60 Hz
a
a) With options package
3 x 16A characteristic C
3 x 15A characteristic C
b
b) e.g. Siemens circuit breakers in accordance with IEC and UL 489 (order no.: 5SJ4 316-7HG42)
or
EATON Industries circuit breaker FAZ-C16/3-NA 16A 3p (UL 489, CSA C22.2 no. 5, IEC 60947-2)
Mains power connec-
tion
Without cable
Cable 5 x 2.5 mm² WITH CEE plug, red 16 A (in accordance with IEC 60309)
(3 x 380 V~ to 3 x 415 V~)
Cable 5 x 2.5 mm² WITHOUT plug (3 x 200 V~ to 3 x 220 V) or (3 x 380 V~ to 3 x 415 V~)
Short circuit rating (SCCR)
c
c) With the original mains connection cable. The marked short circuit rating (SCCR) relates to the beginning of the original
mains cable. In the case of customer modifications, the factory-set length of the mains cable to the placement machine
may not be shortened nor the factory-set conductor cross-section increased, as this would have a negative impact on
the short circuit rating (SCCR).
10 kA
Energy consumption
With a vacuum pump
d
d) Vacuum pump for C&P20 M2 head only. The vacuum pump is not approved for clean room ISO class 7 and must be
operated in the gray room.
Without a vacuum pump
Nominal apparent
power
2.6 kVA 2.3 kVA
Nominal active power 2.00 kW 1.2 kW
Compressed air supply
Compressed air pres-
sure values
p
min
p
max
0.5 MPa = 5.0 bar
1.0 MPa = 10 bar
Operating pressure 0.48 MPa ± 0.025 MPa (4.8 bar ± 0.25 bar)
Compressed air con-
nection
1/2" hose connection
Compressed air consumption
e
e) Average consumption values. Under normal atmospheric conditions at 20°C and 1013 hPa.
Placement head configuration Compressed air
consumption
with a vacuum pump
b
Compressed air consumption
without vacuum pump
SIPLACE TX micron C&P20 M2/C&P20 M2
CPP M/CPP M
120 Nl/min
No option
500 Nl/min
360 Nl/min
Compressed air specification according to ISO 8573
Particle size (ISO class 3) 0.1 µm
Particle density (ISO class 3) 0.1 mg/m³
Maximum oil content (ISO class 1) Particle density 0.01 mg/m³
Pressure dewpoint (ISO class 4) Dewpoint + 3°
PLEASE NOTE:
Also observe the document "Network and compressed air configuration for SMD systems" (German+English,
item no. 00197548-xx), which is supplied with your SIPLACE machine.
31
Technical data
Electrical ratings, energy consumption and
compressed air supply
1 = Electrical connection
2 = Compressed air connection
The connections are run into the machine from below and then connected to the power supply
or pneumatic unit terminals.
