8 SS-1153 15. Environm ental Condition Temperature: 20 ± 10 ° C Humidity : 30 to 80 % (Avoid dew condensation) Note : When the ambient temp erature rises more than the surface of the machine, dew may condense under the c…
7
SS-1153
9. Placement Heads Equipped with 4 heads/4 beams
Vacuum Nozzle: Max. 12 nozzles on each head
Ref. : Maximum Number of Component Picks:
Component Size 5 × 4 mm or less 12
10 × 10 mm or less 6
12 × 12 mm or less 4
20 × 20 mm or less 2
44 × 44 mm or less 1
Note : There are two types of nozzles-one for high-speed component placement
and the other for middle-sized deformed component placement.
Nozzle for High-Speed Component Placement :
The diameter is φ6 mm or less. This nozzle is used for 0603
components (Size : 0603 to 20
× 20 mm).
Nozzle for Middle-Sized Deformed Component Placement :
The diameter is φ12 mm or less. The nozzle end is processed
according to the applicable components.
The nozzle can be used for the component size of up to 44 × 44
mm.
10. Number of
Stocked Nozzles
Up to Max. 12 nozzles can be stored for each head.
Notes : (a) When some additional stockers are purchased, up to 48 nozzles can
be stored for each head.
(b) When the vacuum nozzles for the middle-sized deformed
components are used, the nozzle stockers for them are also
required.
11. Number of
Installable Feeders
Max. 100 feeders (25 feeders × 4 feeder bases)
(When only 8 mm dual tape feeders are used)
Ref. : Up to 200 types of components can be used.
Max. 100 feeders (when only 12/16 mm tape feeders are used)
Max. 48 feeders (when only 24/32 mm tape feeders are used)
Notes : (a) The number of installable feeders varies according to the
combination of the reel width for the taping and the feeders.
(b) Use the tape feeders used prepared specially for GXH series.
The tape, dual tape and bulk feeders for the other machines cannot
be used.
Supply Pressure 0.45 to 0.69 MPa (4.6 to 7 kgf/cm ²)
Set Pressure 0.45 MPa (4.6 kgf/ cm²)
Note : Min. 0.4 MPa (4.1 kgf/ cm²) of air pressure is
necessary for operation.
12. Air Supply
Note : Use the dry and clean air as follows
Moisture : Dew Point −17°C or lower (Atmospheric Pressure)
Oil : 0.1 mg/m
3
or less (ANR)
Dust : Solid Material 0.01 µm or less
13. Air Consumption Approx. 160 L/min (Normal)
14. Vacuum Pressure
−93 kPa (70 cmHg)
0406-004 Tg0911-WO-SP
0406-004 Tg0911-WO-SP
8
SS-1153
15. Environmental
Condition
Temperature: 20
±
10
°
C
Humidity : 30 to 80 % (Avoid dew condensation)
Note : When the ambient temperature rises more than the surface of the
machine, dew may condense under the condition described below.
Note that dew condensation may cause the machine to break down.
Condition of Dew Condensation
Dew may condense when the differences (based on "Humidity (%)")
between the ambient and surface temperatures of the machine reach the
values or more in the table below.
16. Dimensions
Approx. 2,664 (width) × 2,350 (depth) × 1,400 (height) mm
Notes : (a) The width includes the conveyor.
(b) The depth becomes 2,578 mm when the Bank Feeder Change Cart
is included.
(c) The height becomes 2,100 mm when the light tower is included.
17. Mass Approx.
3,000 kg (excl. the Bank Feeder Change Carts and the tape feeders)
Humidity
(%)
Differences between Ambient and Surface
Temperatures of Machine (Ambient
Temperature > Surface Temperature)
80 3 °C or more
70 6 °C or more
60 8 °C or more
50 10 °C or more
40 14 °C or more
30 18 °C or more
0406-004 Tg0911-WO-SP
9
SS-1153
3.2 Electrical Specifications
3.2.1 Control Configuration
Comera for Component
Recognition
Camera for P.E.C.
Recognition
Recognition Processor
Main Machine
Controller
Main Machine
of GXH
Monitor can be used both as operation
and recognition
(fitted with a touch screen)
Front Side
Rear Side
L
C
D
L
C
D
1
2
3
4
1
2
3
4
Fig. 1.2
3.2.2 Electrical Specifications
1. Memory Capacity
of Pattern Program
Data
Max. Number of Steps : 20,000 steps/ model
Max. Memorized Number of Models : 500 models
Note : The above numbers may be limited according to the capacity of the
pattern program data per model.
2. Input and Output
System of Pattern
Program Data
• Pattern program data editing is possible, using the touch screen, the keyboard,
and the pointing device of the main machine.
• Pattern program data can be edited with the network terminal (Option).
• Data can be entered through the local area network (Ethernet) running from
the storage unit of the network terminal (Option).
• Data Reading Floppy Disk (Option)
• Data Transfer Storage of Network Terminal (Option)
Visual Field φ 62 mm
The dimension in Y direction must be 46.5 mm.
Photoimage Front Lighting System
(Direct Recognition of Component by Front Lighting)
Back Lighting System
(Recognition with Silhouette of Component:
Limited to certain types of components)
Note: Some limitation is imposed, depending on the types
of components.
3. Component
Recognition
Note : A proper camera is automatically selected according to the shape and
size of components.
