Ref No. Remark s R 1 Q'ty 14-A はんだ自 動 供 給 ユニット Solder Auto-Dispensing Unit ｲﾗｽﾄ No. Part No. 品 名 品番 数量 R 2 パーツリスト Kit N o . キット品 番 Kit Name キット名称 N610012879AA Part Name 備 考 ｾｸｼｮﾝNo. PARTS LIST Section No. R 3 SLEEVE…
14-A
はんだ自
動
供
給
ユニット
Solder Auto-Dispensing Unit
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610012879AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
S29
Ref
No.
Remarks
R
1
Q'ty
14-A
はんだ自
動
供
給
ユニット
Solder Auto-Dispensing Unit
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610012879AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
SLEEVE
1
1 KXFB030GA00
BLOCK
1
2 N210021699AA
PLATE
1
3 N210038510AC
PLATE
1
4 N210043753AA
PLATE
1
5 N210043754AA
HOLDER
1
6 N610110404AA
BLOCK
1
7 N210038516AA
BRACKET
1
9 N210021702AB
BRACKET
2
10 N210038518AB
BRACKET
1
11 KXFB00FVA01
BRACKET
1
15 N210045464AB
PLUNGER
2
16 N510020806AA 87BPJ6
JOINT
1
17 KXF0DZ4ZA00 KQ2U04-00
SPEED-CONTROLLER
2
18 KXF00Z1AA00 AS1311F-M5-04
COUPLER
1
19 KXF02WSAA00 MC-04SH
COUPLER
1
20 KXF09RVAA00 MC-10PM
JOINT
1
21 KXF0DWUWA00 No.386 M-1/4X1/8 SUS
CAP
1
22 N210131551AB
PLUG
2
23 N510031309AA PCS03
PLUNGER
2
24 KXF08WKAA00 17706
CARTRIDGE
2
25 KXF08WJAA00 17758
WASHER
1
26 N510020807AA 87FWSSS-D30-V12.0-T3.0
NOZZLE
5
27 KXF08WMAA00 17635
BOLT
1
28 N510020809AA MMSB12-15
PLUNGER
1
29 N510022283AA 87SXPA12
WASHER
1
30 N510020813AA 87FWSSB-D20.0-V12.0-T3.0
BOLT
1
31 N510020814AA MMSB6.5-15
SCREW
2
33 N510018279AA
Cross recessed Truss head machine screw M4X6-4.8 A2J (Trivalent)
JOINT
1
34 KXF0A3FAA00 KQ2U06-00
BOLT
4
48 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
4
49 N510017308AA
Hexagon socket head cap screw M3X12-10.9 A2J (Trivalent)
BOLT
1
51 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
5
52 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
BOLT
1
53 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
BOLT
2
56 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
BOLT
2
57 N510017435AA
Hexagon socket head cap screw M6X20-10.9 A2J (Trivalent)
WASHER
6
58 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
8
62 N510020098AA Thick washer for M3
WASHER
3
63 N510020099AA Thick washer for M4
WASHER
4
64 N510018327AA Spring lock washer No.2 3 S A2J (Trivalent)
WASHER
1
65 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
NUT
2
66 N510017867AA
Hexagon nut Type-1 Best class M6-6H-4T A2J (Trivalent)
Sensor
1
85 N610026802AF Sensor:-B1A02
STOPPER
1
86 N210055843AA
JOINT
1
88 KXF0DXLBA00 KQ2E04-00
RUBBER
1
93 N210133078AA
S30
14-B
はんだ自
動
供
給
ユニット
Solder Auto-Dispensing Unit
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610012879AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
S31
