Ref No. Remark s R 1 Q'ty 㪈㪄㪙 ᧄ ㇱ Mai n Bo dy 䍐䍵䍛䍢 㪥㫆㪅 Part No. ຠ䇭䇭ฬ ຠ⇟ ᢙ㊂ R 2 䊌䊷䉿䊥䉴䊃 Kit N o . 䉨䉾䊃ຠ ⇟ Kit Name 䉨䉾䊃ฬ⒓ N610012842AA Part Name 䇭䇭䇭⠨ 䍜䍖䍚䍌䍻㪥㫆㪅 PARTS LIST Section No. R 3 BRACKET 1 19 N210041736AA COVER…
㪈㪄㪙
ᧄ
ㇱ
Main Body
䊌䊷䉿䊧䉟䉝䉡䊃
Ki
t
N
o
.
䉨䉾䊃
ຠ⇟
Kit Name
䉨䉾䊃ฬ⒓
N610012842AA
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LAYOUT
Section No.
M3
-0##
Ref
No.
Remarks
R
1
Q'ty
㪈㪄㪙
ᧄ
ㇱ
Main Body
䍐䍵䍛䍢
㪥㫆㪅
Part No.
ຠ䇭䇭ฬຠ⇟ ᢙ㊂
R
2
䊌䊷䉿䊥䉴䊃
Kit N
o
.
䉨䉾䊃ຠ
⇟
Kit Name
䉨䉾䊃ฬ⒓
N610012842AA
Part Name
䇭䇭䇭⠨
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LIST
Section No.
R
3
BRACKET
1
19 N210041736AA
COVER
1
25 N210026088AC
GAUGE®ULATOR UNIT
1
59 N610027755AA
COVER
1
60 N210026099AC
BRACKET
1
61 N210043226AA
REGULATOR
1
63 N510016394AA AR20-02-X2232-A
REGULATOR
1
68 N510016408AA IR2010-02-DIJ00454
GAUGE
4
69 KXF0DY1DA00 G46-4-01-C
REGULATOR
1
70 N510016401AA AR20K-01-X2107-A
REGULATOR
2
71 N510022117AA AR10-M5-Y-X2121-A
GROMMET
1
72 KXF0E0QHA00 C-30-SG-48A(black)
JOINT
5
73 N431KQ2L-400 KQ2LF04-01
SCREW
4
76 N510018249AA
Cross recessed Truss head machine screw M3X4-4.8 A2J (Trivalent)
BOLT
2
77 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
WASHER
2
78 N510020099AA Thick washer for M4
SCREW
16
92 N510018300AA
Cross recessed Truss head machine screw M5X6-4.8 A2J (Trivalent)
BOLT
8
93 N510017612AA
Hexagon socket Flat head bolt M3X6-10.9 A2J (Trivalent)
BOLT
7
143 N510017419AA
Hexagon socket head cap screw M5X8-10.9 A2J (Trivalent)
BOLT
4
144 N510017386AA
Hexagon socket head cap screw M5X10-10.9 A2J (Trivalent)
BOLT
2
145 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
WASHER
11
156 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
2
164 N510020100AA Thick washer for M5
JOINT
2
174 N431KQ2H0400 KQ2H04-00
JOINT
1
175 N431KQ2H0600 KQ2H06-00
CABLE-BEAR
1
182 N510015980AA Z08.50-048-0-29-080.50.12
SWITCH
1
197 KXF0DWHDA00 ISE30-01-25-MB
BUSH
1
210 KXF0DUDAA00 CE-012
