SP18 机械Parts List.pdf - 第51页
Ref No. Remark s R 1 Q'ty 㪋㪄㪛 ၮ ᧼ ⟎ 䉄䊥䊐䊃㩷㩿㪣㪀 Bo ar d P os itio ni ng Li f t(L ) 䍐䍵䍛䍢 㪥㫆㪅 Part No. ຠ䇭䇭ฬ ຠ⇟ ᢙ㊂ R 2 䊌䊷䉿䊥䉴䊃 Kit N o . 䉨䉾䊃ຠ ⇟ Kit Name 䉨䉾䊃ฬ⒓ N610012845AA Part Name 䇭䇭䇭⠨ 䍜䍖䍚䍌䍻㪥㫆㪅 PARTS LIST Section No.…
㪋㪄㪛
ၮ
᧼
⟎
䉄䊥䊐䊃㩷㩿㪣㪀
Board Positioning Lift(L)
䊌䊷䉿䊧䉟䉝䉡䊃
Kit N
o
.
䉨䉾䊃ຠ
⇟
Kit Name
䉨䉾䊃ฬ⒓
N610012845AA
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LAYOUT
Section No.
M33
-0##
Ref
No.
Remarks
R
1
Q'ty
㪋㪄㪛
ၮ
᧼
⟎
䉄䊥䊐䊃㩷㩿㪣㪀
Board Positioning Lift(L)
䍐䍵䍛䍢
㪥㫆㪅
Part No.
ຠ䇭䇭ฬຠ⇟ ᢙ㊂
R
2
䊌䊷䉿䊥䉴䊃
Kit N
o
.
䉨䉾䊃ຠ
⇟
Kit Name
䉨䉾䊃ฬ⒓
N610012845AA
Part Name
䇭䇭䇭⠨
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LIST
Section No.
R
3
BRACKET
1
3 N210025896AC
BRACKET
1
4 N210025897AC
PLATE
1
5 N210025898AA
PLATE
1
6 N210025899AA
PLATE
1
7 N210025900AA
PLATE
1
8 N210025901AA
BRACKET
1
43 N210026244AC
BRACKET
1
44 N210026245AC
DOG
1
45 N210026246AB
COVER
1
48 N210026268AB
CONTROLLER
1
82 N310E39E10 E39-E10
BOLT
4
83 N510017254AA
Hexagon socket head cap screw M2X12-10.9 A2J (Trivalent)
WASHER
4
84 N510018324AA Spring lock washer No.2 2 S A2J (Trivalent)
WASHER
4
85 N510018477AA
Small round-plain washer 2 10H A2J (Trivalent)
AIR-SLIDE
1
87 KXF0DLFAA00 MXPJ6-5-X23
JOINT
2
88 KXF02STAA00 M-3AU-4
BOLT
4
133 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
5
137 N510017376AA
Hexagon socket head cap screw M4X6-10.9 A2J (Trivalent)
BOLT
6
139 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
4
140 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
BOLT
2
141 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
BOLT
8
142 N510017354AA
Hexagon socket head cap screw M4X20-10.9 A2J (Trivalent)
BOLT
4
145 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
8
148 N510017399AA
Hexagon socket head cap screw M5X25-10.9 A2J (Trivalent)
WASHER
9
155 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
1
158 N510018478AA
Small round-plain washer 3 10H A2J (Trivalent)
WASHER
4
160 N510020098AA Thick washer for M3
WASHER
12
161 N510020099AA Thick washer for M4
WASHER
8
162 N510020100AA Thick washer for M5
WASHER
1
166 N510018327AA Spring lock washer No.2 3 S A2J (Trivalent)
NUT
4
168 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
Sensor
1
182 N610026836AA Sensor:-B1036
BOLT
4
186 N510017730AA
Hexagon head bolt Best class M4X25-6g 4T A2J (Trivalent)
BOLT
1
192 N510017321AA
Hexagon socket head cap screw M3X25-10.9 A2J (Trivalent)
M34
-0##
㪋㪄㪜
ၮ
᧼
⟎
䉄䊥䊐䊃㩷㩿㪣㪀
Board Positioning Lift(L)
䊌䊷䉿䊧䉟䉝䉡䊃
Kit N
o
.
䉨䉾䊃ຠ
⇟
Kit Name
䉨䉾䊃ฬ⒓
N610012845AA
䍜䍖䍚䍌䍻㪥㫆㪅
PARTS LAYOUT
Section No.
M35
-0##
