Installation Manual Station Software Version 505.03 SP1
56 of 154
Information: The original partitions are displayed correctly, but to not function correctly.
Simply reformatting the disk does not solve the problem.
- Create with FDISK follwowing partitions:
Partition Status Typ Mbyte
C:1 A PRI DOS 50
2 EXT DOS 450
- Restart the computer (Press simultaneously Ctrl + Alt + Del).
- Now the 505 software can be installed in the normal manner for a new hard disk.
Note:
You find more details concerning the BIOS setting, operating system etc. in our Technical
Information that are online available via the SIEMENS DMS (
www.siplace.com ).
Installation Manual, Station Software Version 505.03 SP1 Edition 08/2005
57 of 154
4.4.1.1 Starting the BIOS Setup
To start the BIOS setup, wait for the following message to appear on the screen after the system
has been booted and then press the <F2> key.
PowerBIOS Version 1.00
Copyright(C) 1984-1995, Award Software, Inc.
12/06/96 - Intel - 82430HX
AMS-M54 V 1.00
┌────────────────────────────────────────────────────────────────────────┐
│ CPU Type...............................................Pentium xxx MHz │
│ Math CoProcessor..............................................Internal │
│ . │
│ . │
│ . │
│ . │
│ . │
│ . │
│ . │
│ . │
└────────────────────────────────────────────────────────────────────────┘
Press F2 to enter setup
Installation Manual Station Software Version 505.03 SP1
58 of 154
Main menu
The BIOS Setup has the following initial menu:
┌────────────────────────────────────┐
│ Award Software International, Inc. │
│ PowerBIOS 1.00 Setup │
│ ┌──────────────────┐ │
│ │ System Security │ │
│ │ Date and Time │ ╔══════╗ │
│ │ AT Hard Disk │ ║ OPEN ║ │
│ │ Floppy Disk │ ╚══════╝ │
│ │ Boot Features │ │
│ │ Standard Chipset │ ┌──────┐ │
│ │ Advanced Chipset │ │Cancel│ │
│ │ Peripherals │ └──────┘ │
│ │ PCI Setup │ │
│ │ IMC Interrupts │ │
│ │ COM Redirection │ │
│ │ IMC Miscellaneous│ │
│ │ │ │
│ └──────────────────┘ │
│ Press [F4] key to toggle color │
│ Press [F1] key for help │
└────────────────────────────────────┘
Keyboard operation in the BIOS Setup
Key Action
CURSOR-DOWN, CURSOR-UP Selects the next/previous Setup page.
RETURN Displays the selected Setup page (if "OPEN" is active) or
terminates Setup (if "Cancel" is active)
ESC Ends Setup
TAB, SHIFT-TAB Activates the next/previous button.
F1 Calls context-sensitive Help system: Opens a help window for
the entry that is currently selected
F4 Switches from color to black and white display in the BIOS
Setup.
The current setting is saved when Setup is ended, and remains
set the next time Setup is started.
