28 8. Controller Section 8-1. Control Box M4008 17 2 2 16 12 10 1 1 6 25 7 8 9 5 23 4 21 1 20 15 13 22 14 24 19 3 18 3 17 2 2 16 12 10 1 1 6 25 7 8 9 5 23 4 4 21 1 20 15 13 22 14 24 19 3 18 3 No. Part No. Part Name Q&apo…
27
7. Marker Pen Unit Section (Option)
7-1. Marker Pen Unit Section (Option)
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE2-M7401-00 ANGLE,BASE 1
2 LE2-M7402-00 BLOCK,BASE 1
3 LE2-M7403-02 PLATE,SUPPORT 1
4 LE2-M7404-01 PLATE,JOINT 1
5 LE2-M7405-01 BLOCK,GUIDE 1
6 LE2-M7406-02 ANGLE,DOG 1
7 LE2-M7408-00 BRACKET,PEN(L) 1
8 LE2-M7409-00 HOLDER,PEN(L) 1
9 LE2-M740A-00 PIN,HINGE 1
10 90990-47J008 KNURLED KNOB 1
11 LE2-M740D-01 BASE,CAP 1
12 LE2-M740G-00 BRACKET,CYL. 1
13 LE2-M740H-00 ANGLE,DOG 1
14 LE2-M740J-00 AIR CYLINDER 1
15 LE2-M740N-00 BRACKET,VALVE 1
16 LE2-M740P-00 AIR CYLINDER 1
17 LE3-M5105-01 ROD,CYLINDER 1
18 LE3-M51A0-A0 MANIFOLD ASSY 1
19 LE3-M51A1-00 LINEAR GUIDE 1
20 LE3-M51A3-00 JOINT,FLEXIBLE 1
21 90990-53J001 BEARING(OILLESS) 2
22 $SC4-M5A SPEED CONTROLLER 4
23 $TS4-M5M JOINT 4
24 99001-05600 CIRCLIP(E) 1
25 LG0-M90AK-00 MUFFLER 1
26 $TL6-01 JOINT 1
27 LG0-M90AP-00 PLUG 2
28 LE2-M740W-00 BLOCK,STOPPER 1
29 LE2-M74A2-00 SHOCK ABSORBER 1
30 90990-48J001 BALL PLUNGER 1
31 LE2-M7411-010 JIG,PEN 1
32 LE1-M5107-00 ADPTER 1
33 LC9-M26H0-00 PHOTO SENSOR 4
34 LE3-M51A0-B0 MANIFOLD 1
35 LE3-M51A0-C0 SOLENOID VALVE 2
36 LE3-M51D1-20 PEN MARKER(LR) 1 RED
37 LE3-M51D1-30 PEN MARKER(LB) 1 BLUE
38 LE3-M51D2-20 PEN MARKER(SR) 1 RED
39 LE3-M51D2-30 PEN MARKER(SB) 1 BLUE
40 90200-00J11A O-RING 1 (L)
41 90200-00J050 O-RING 1 (S)
42 LE2-M740S-00 CAP(L) 1
43 LE2-M740S-01 CAP(S) 1
28
8. Controller Section
8-1. Control Box
M4008
17
2
2
16
12
10
11
6
25
7
8
9
5
23
4
21
1
20
15
13
22
14
24
19
3
18
3
17
2
2
16
12
10
11
6
25
7
8
9
5
23
4
4
21
1
20
15
13
22
14
24
19
3
18
3
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE2-M410G-00 BRKT, ATX 1
2 LE3-M400H-00 GOM, CTRL BOX 2
3 LE3-M400A-01 BRKT, BOARD 1 2
4 LE3-M400B-01 BRKT, BOARD 2 1
5 LE3-M400P-00 BRKT, PORT 1
6 LE3-M400E-01 PLATE 1 1
7 LE3-M400C-00 GOM, BOARD 1
8 LE3-M400M-00 COVER, BOX 1 1
9 LC1-M4006-01 PANEL, HDD (2) 1
10 LC1-M40A3-00 H.E.D. 4
11 LC1-M40A2-00 SPACER, HED 4
12 90990-28J126 WASHER,PLAIN 4
13 LE1-M40H7-00 MOTHER BOARD1 1
14 LE3-M65E2-00 CPU 1
15 LE3-M65E3-00 MEMORY 1
16 LE3-M65E4-00 SERIAL ATA HDD 1
17 LE3-M65E5-00 ATX POWER SUPPLY 1
18 LC3-M40HJ-00 BOARD, VM7 1
19 LE3-M40H0-00 BOARD, MCB 1
20 LG0-M11HC-00 GAURD, FINGER 1
21 LE3-M6515-00 FAN ASSY. 1
22 LE3-M4006-01 PLATE,BOX 1 1
23 LE2-M4007-01 PLATE,BOX 2 1
24 LE3-M4008-02 PLATE,BOX 3 1
25 90990-05J025 SPACER BOLT 9
29
9. Exterior, etc Section
9-1. Exterior,etc
11
12,13 2
3
1
16,17 22
7 26,27 28
30
32 3129
6 5 4
18,19 201415
23,24 25
8910
11
12,13
2
3
1
16,17
22
7
26,27
28
30
32
31
29
6
5
4
18,19
20
14
15
23,24
25
8
9
10
