7 3. Moving-axis Section 3-1. X-axis 22 19 10 18 20 1 1 13 15 12 13 18 26 24 6 5 3 2 4 3 1 8 7 27 28 25 21 14 13 18 16 17 23 12 15 14 21 25 9 22 19 10 18 20 1 1 13 15 12 13 18 26 24 6 5 3 2 4 3 1 8 7 27 28 25 21 14 13 18…
6
2. Cover Section
2-3. Operation Panel
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE3-M130A-00 CLAMP,MONITOR ASSY. 1
2 LE3-M130B-01 BASE,CLAMP-A 1
3 LE3-M130C-02 BASE,CLAMP-B 1
4 LE3-M130D-02 BASE,CLAMP-C 1
5 LE3-M130E-01 BAR,CLAMP 1
6 97002-06060 BOLT,HEXAGON 1
7 95302-06600 NUT HEXAGON 1
8 92902-06200 WASHER PLAIN 1
9 LE3-M130H-00 ROLLER,CLAMP 4
10 90933-03J126 BEARING 8
11 90990-37J006 WASHER,BELLEVILLE 8
12 90990-18J018 PIN PARALLEL 4
13 LE3-M130M-00 PIN,HINGE 1
14 90990-50J004 PLATE,MC 2
15 LE2-M1351-00 BRKT,DUCT 1
16 LE2-M1352-00 BAR,MONITOR 1
17 LE2-M1353-00 BRKT,BAR 2
18 LE3-M130S-01 PLATE,NUT 2
19 LE3-M130U-01 BASE,MONITOR 1
20 LE2-M1355-01 BASE,KEYBOARD 1
21 LE3-M13F1-00 SCREW,ALL 1
22 99712-16700 NUT,HEXAGON 5
23 LE3-M130X-01 COLLAR 1
24 LE2-M1357-01 BRKT,KEY BOARD 1
25 LE3-M131T-00 CUSION,KB 1
26 LE3-M131U-00 TAPE,DOUBLE COATED 1
27 LE3-M131J-00 BRACKET,MONITOR 1
28 90990-28J121 WASHER,PLAIN 2
29 90990-16J004 NUT,U 1
30 92907-16800 WASHER,BELLEVILLE 1
31 LE3-M130T-03 DUCT,MONITOR 1
32 LE3-M131L-00 CONNECTOR,DUCT 1
33 90990-47J014 SADDLE,DUCT 1
34 LE3-M131N-00 BRKT,DUCT 1
35 LG0-M110P-01 PAD,MOUSE 1
36 90990-47J004 GRIP, MONITOR 1
7
3. Moving-axis Section
3-1. X-axis
22
19
10
18
20
11
13
15
12
13
18
26
24
6
5
3
2
4
3
1
8
7
27
28
25
21
14
13
18
16
17
23
12
15
14
21
25
9
22
19
10
18
20
11
13
15
12
13
18
26
24
6
5
3
2
4
3
1
8
7
27
28
25
21
14
13
18
16
17
23
12
15
14
21
25
9
8
3. Moving-axis Section
3-1. X-axis
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE2-M2201-00 X-FRAME 1
2 LE2-M2202-00 BALL SCREW 1
3 LE2-M2203-00 LM GUIDE 1
4 LE2-M2204-00 HOLDER,NUT 1
5 LE2-M2205-00 DOG,X 1
6 LE2-M2206-00 BRKT,SENSOR 3
7 LE2-M2207-01 BRKT,BEAR 1
8 LE2-M22A0-00 CABLE BEAR ASSY 1
9 90990-55J002 CLAMP,CABLE 1
10 LE2-M220B-00 HOLDER,MOTOR 1
11 LC7-M2204-00 HOLDER,BRG 1
12 LC7-M2205-00 PLATE,BRG 2
13 LC7-M2206-00 COLLAR 3
14 LC7-M2211-00 DAMPER 2
15 90990-26J006 BEARING(COMB.) 2
16 LC1-M220T-00 COLLAR 1
17 90990-16J006 LOCK NUT 1
18 90990-36J004 WASHER SEAL 4
19 LE2-M22B8-00 COUPLING 1
20 90990-16J003 LOCK NUT 1
21 90990-41J118 COLLAR 8
22 LE2-M6521-00 X MOTOR ASSY. 1
23 LE2-M220C-00 HOLDER,BRG. 1
24 LC9-M26H0-00 PHOTO SENSOR 3
25 91317-05014 BOLT HEX.SOCKET HEAD 8 M5X14
26 91317-03006 BOLT HEX.SOCKET HEAD 6 M3X6
27 91317-06012 BOLT HEX.SOCKET HEAD 4 M6X12
28 92907-06200 WASHER PLAIN 4
