3 1. SPECIFICATIONS TS5000DMP-DCX- TS5000DMP- DC X-SL TS5000DMP- DCX-SR Size 5.88'' Length X 3.56'' (149.35mm X 90.42mm) 5.88'' Length X 3.56'' (149.35mm X 90.42mm) 5.88'&apos…
2
CONTENTS
Page number
1. Specifications…………………………………………………………………3
2. Unpacking and Inspection…………………………………………………….4
3. Description...…………………………………………………….….………...4
4. Theory of Operation…………………………………………….….…………5
5. Set-Up Instructions……………………….…………………….….…………6
6. Typical Set-Up…………...…………………………………….…………..…7
7. Determining Dispensing Output……………………………………………8-9
8. DMP Removal/Replacement…………….……………………….…….…….9
9. Spare Parts…………………………………………………………………...10
10. DMP Insert Options.………………………..………….…….………….......11
11. Accessories………..………………………..………….…….….……….......11
12. Trouble Shooting………..………………………..………….…….………...12
13. Warranty……………………………………………………………………..13
3
1. SPECIFICATIONS
TS5000DMP-DCX- TS5000DMP- DCX-SL TS5000DMP- DCX-SR
Size
5.88'' Length X 3.56''
(149.35mm X 90.42mm)
5.88'' Length X 3.56''
(149.35mm X 90.42mm)
5.88'' Length X 3.56''
(149.35mm X 90.42mm)
Weight 0.73 lb (331g) 0.73 lb (331g) 0.73 lb (331g)
Body width 1.56” (39.6mm) 1.30” (33mm) 1.30” (33mm)
Door open
location
Right hand side Left hand side Right hand side
Fluid Inlet
Port
Female Luer lock Female Luer lock Female Luer lock
Fluid Outlet
Port
Male Luer Lock Male Luer Lock Male Luer Lock
Maximum
Fluid Pressure
30 psi (2bar) 30 psi (2bar) 30 psi (2bar)
Operating
Frequency
Exceeds 300 cycles/min. Exceeds 300 cycles/min. Exceeds 300 cycles/min.
Mounting 1'' (25.4mm) Channel 1'' (25.4mm) Channel 1'' (25.4mm) Channel
Wetted Parts Delrin®, Nylon, Viton® Delrin®, Nylon, Viton® Delrin®, Nylon, Viton®
Viscosity
Range
30,000cps – 1,300,000cps 30,000cps – 1,300,000cps 30,000cps – 1,300,000cps
4
Encoder DMP Options
Techcon Systems can offer the TS5000DMP-DCX with an encoder fitted to the
DC motor. This configuration is available with a right hand side door opening.
Due to machine integration restrictions, the encoder option is available with the
flexibility of 3 encoder positions:
For spare parts, technical drawings, dimensional drawings, wiring diagrams or
encoder information, relating to the encoder valve option, please contact Techcon
Systems.
2. UNPACKING AND INSPECTION
Carefully unpack the valve and examine the items contained in the carton.
These will include:
Valve assembly
Valve bracket and syringe bracket
Sample syringe kit and tip kit
Sample DMP feed screw/chamber (1 each of 6, 8 and 16-pitch)
User guide
Inspect the unit for any damaged which may have occurred in transit. If such
damage has occurred, notify the carrier at once. Claim for damage must be made
by the consignee to the carrier, and should be reported to the manufacturer.
3. DESCRIPTION
The TS5000DMP-DCX Series Rotary Microvalve takes a revolutionary unique
approach to solving some of the most difficult dispensing problems. Two-
component fluids present a significant dispensing challenge, and the possibility of
destroying precision valve components, upon premature curing. Highly abrasive
fluids eventually decrease accuracy that is followed by total valve failure. With
the patented Disposable Material Path (DMP) Rotary Microvalve from Techcon
Systems, those concerns are erased.
A precision molded feed screw and chamber is captured in a “clamshell” design
valve housing. Inexpensive disposable feed screw and chamber components may
be changed quickly and easily. Cleanup is reduced to simply changing out the
disposable material path. An inexpensive stock of disposable valve components
replaces an inventory of back up valves.
The accuracy of the TS5000DMP-DCX valve meets the needs of users previously
constrained to lower accuracy of time/pressure dispensing. It also meets the
maintenance cost targets of users previously relegated to recurring, maintenance of
non-disposable path valves. Current TS5000 Rotary Microvalve customers may
find the accuracy of the TS5000DMP-DCX valve meet their current accuracy
specifications.
PART NUMBER DESCRIPTION
TS5000DMP-E DMP Valve With 105° Encoder position
TS5000DMPE-0 DMP Valve With 0° Encoder position
TS5000DMPE-15 DMP Valve With 15° Encoder position
13
13.
LIMITED WARRANTY
Manufacturer warrants this product to the original purchaser for a period of one (1)
year from date of purchase to be free from defects in material and workmanship,
but not against damages by misuse, negligence, accident, faulty installations and
instructions. Manufacturer will repair or replace (at factory’s option), free of
charge, any component of the equipment thus found to be defective, on return of
the component, “PREPAID” to the factory during the warranty period. In no event
shall any liability or obligation of the Manufacturer arising from this warranty
exceed the purchase price of the equipment. This warranty is only valid if the
defective product is returned as a complete assembly without physical damage.
The Manufacturer’s liability, as stated herein, cannot be altered or enlarged except
by a written statement signed by an officer of the company. In no event shall the
Manufacturer be liable for consequential or incidental damages. A return
authorization is required from Techcon Systems prior to shipping a defective unit
to the factory.
Manufacturer reserves the right to make engineering product modifications
without notice.
All returns must be issued with a Returns Authorization number, prior to return.
Send warranty returns to:
Americas and Asia
OK International
Garden Grove Division
12151 Monarch Street
Garden Grove, Ca 92841
Europe
OK International
Eagle Close
Chandler’s Ford Ind Est
Eastleigh
Hampshire
SO53 4NF
United Kingdom
www.techconsystems.com
Delrin®, Viton® and Teflon® are registered trademarks of E.I. DuPont.
T9000119_D
