Recommended mating shafts

HOLLOW SHAFT ENCODERS www.leinelinde.com

2.7 FSI 900 series

2.7.1 Shaft interface 20 hk

Shaft length L (mm) Min screw length L (mm)

47 17

48 16

49 15

Recommended mating shafts

HOLLOW SHAFT ENCODERS www.leinelinde.com

3 Shaft runout (all series)

Check the encoder’s radial runout with slow rotation

of complete assembly. The runout should not exceed

0.1 mm, as this may shorten the encoder’s service life

or influence the system accuracy.

4 Torque arms (800,700 and 600 series)

Fix the encoder with an insulated torque arm. It

must be fitted at 90 degrees angle to the direction of

the bracket, for optimum accuracy of measurement.

4.1 Accessory torque arms (to be ordered separately)

4.1.2 Mounting with M6 torque arm

Part number 1254632-xx (800,700 and 600 series)

4.1.3 Alt. mounting with M5 torque arm

Part number 1254627-xx (800 series)

= Part from customer = Accessories from Leine Linde

90 º
